Vex Protobot Manual page 32

[M29] [M29]
MOTOR CONTROLLER 29
(not shown to scale)
OPTIONAL [NOT INCLUDED]
[BP]
7.2V RECHARGEABLE BATTERY
(optional accessory, not shown to scale)
[AH]
ANTENNA HOLDER
(optional accessory, not shown to scale)
[BST]
BATTERY TIE DOWN
(optional accessory, not shown to scale)
32
[MOT]
MOTOR
(not shown to scale)
[CTX]
CORTEX
(optional accessory, not shown to scale)
[BB]
7.2V AA BATTERY BOX
(optional accessory, not shown to scale)
[AT]
ANTENNA TUBE
(optional accessory, not shown to scale)
[W5]
WHEELS, LARGE 5", KNOBBY
(not shown to scale)
[VMC]
MICRO CONTROLLER
(optional accessory, not shown to scale)
[RX75]
RF RECEIVER & CABLE
(optional accessory, not shown to scale)
