  • Page 1 V-Rex Build Instructions Instructions de Construction de V-Rex 228-4444-752...
  • Page 2 V-Rex Do you like dinosaurs? I sure do, and had a great time building this one out of a VEX IQ Starter Kit! V-Rex can stand up and walk on its own two legs while also moving its arms, tail, and jaws. The amazing part, though, is that the V-Rex does all of that using just ONE Smart Motor, through some unique linkages and gear trains that you’ll...
  • Page 3 Sensors, or Robot Brains using a 1x Beam. Put the 1x Beam onto the pin and twist the Beam while pulling outward. Use a 1x Beam for extra leverage when mounting small VEX IQ Les connecteurs peuvent être facilement retirés des moteurs elements on shafts.
  • Page 4 V-Rex Required parts Pièces requises 228-2500-060 228-2500-062 228-2500-007 228-2500-060 228-2500-061 228-2500-009 228-2500-065 228-2500-170 Look for Quey for build tips Recherche Quey pour les conseils de construction Completed build step Étape de construction fini 228-2500-005...
  • Page 5 228-2500-082 228-2500-112 228-2500-143 228-2500-141 228-2500-120 228-2500-060 228-2500-114 228-2500-045...
  • Page 6 228-2500-112 228-2500-215 Assurez-vous d’aligner les Make sure to line up the trous de 228-2500-141 holes of 228-2500-141 and et 228-2500-215 comme 228-2500-215 as shown montré 228-2500-060 228-2500-061 228-2500-112 228-2500-011 228-2500-026 228-2500-170 228-2500-065...
  • Page 7 228-2500-067 228-2500-143 228-2500-164 228-2500-070 228-2500-060 228-2500-060 228-2500-061 228-2500-170 228-2500-019 228-2500-151...
  • Page 8 228-2500-060 228-2500-060 228-2500-061 228-2500-145 228-2500-150 228-2500-060 228-2500-070 228-2500-060 228-2500-170 228-2500-017 228-2500-134...
  • Page 9 228-2500-060 228-2500-061 228-2500-060 228-2500-061 228-2500-019 228-2500-145 228-2500-151 228-2500-060 228-2500-150 White gears reference previous steps L’ e ngrenage blanc fait référence à une étape précédente...
  • Page 10 228-2500-060 228-2500-003 228-2500-127 228-2500-021 228-2500-134 228-2500-060 228-2500-060 228-2500-061 228-2500-067 228-2500-019 228-2500-134 228-2500-040...
  • Page 11 228-2500-060 228-2500-060 228-2500-021 228-2500-127 228-2500-003 228-2500-128 228-2500-060 228-2500-021 228-2500-017...
  • Page 12 228-2500-061 228-2500-060 228-2500-130 228-2500-127...
  • Page 13 228-2500-084 228-2500-127 228-2500-127 228-2500-040 228-2500-067 228-2500-163 228-2500-002 228-2500-130...
  • Page 14 228-2500-060 228-2500-145 228-2500-127 228-2500-127...
  • Page 15 228-2500-084 228-2500-002 228-2500-130 228-2500-127 228-2500-040 228-2500-067 228-2500-163...
  • Page 16 228-2500-060 228-2500-060 228-2500-019 228-2500-145 228-2500-040 228-2500-060 228-2500-130...
  • Page 17 228-2500-060 228-2500-003 228-2500-084 228-2500-165 228-2500-224...
  • Page 18 228-2500-060 228-2500-060 228-2500-030 228-2500-025 228-2500-062 228-2500-060 228-2500-135...
  • Page 19 228-2500-060 228-2500-060 228-2500-025 228-2500-131 228-2500-135 228-2500-060 228-2500-062 228-2500-172 228-2500-148 45° 228-2500-149 60° 45° 60° 228-2500-149 228-2500-148...
  • Page 20 228-2500-114 228-2500-061 228-2500-060 228-2500-148 45° 228-2500-149 60° 228-2500-150 45° 60° 228-2500-148 228-2500-149 228-2500-009 228-2500-060 228-2500-065 228-2500-170...
  • Page 21 228-2500-061 228-2500-062 228-2500-005 228-2500-007 228-2500-060 228-2500-082 228-2500-112 228-2500-143 228-2500-141 228-2500-120...
  • Page 22 228-2500-060 228-2500-114 228-2500-045 228-2500-112 228-2500-215 Assurez-vous d’aligner les Make sure to line up the trous de 228-2500-141 holes of 228-2500-141 and et 228-2500-215 comme 228-2500-215 as shown montré...
  • Page 23 228-2500-060 228-2500-061 228-2500-112 228-2500-011 228-2500-026 228-2500-065 228-2500-170 228-2500-143 228-2500-112 228-2500-078 228-2500-213...
  • Page 24 228-2500-124 228-2500-064 228-2560 L’arbre est The shaft is uniquement pour only to help you vous aider à tenir keep gear holes le pignon trous alligned. alignés. 228-2500-122 228-2500-143 228-2500-112 228-2500-213 Remove shaft. Déposer l’arbre Make sure gears are exactly like step 6 and 68 Assurez-vous que les engrenages sont...
  • Page 25 228-2500-060 228-2500-023 228-2500-021 228-2500-023 228-2500-060 228-2500-060 228-2500-023 228-2500-026...
  • Page 26 228-2500-124 228-2500-060 228-2500-127 228-2500-143 228-2500-147 30° 228-2500-132 30° 228-2500-133...
  • Page 27 228-2500-060 228-2500-023 228-2500-021 228-2500-023 228-2500-060 228-2500-060 228-2500-023 228-2500-026...
  • Page 28 228-2500-124 228-2500-060 228-2500-127 228-2500-143 228-2500-147 30° 228-2500-132 30° 228-2500-133...
  • Page 29 228-2500-009 228-2500-060 228-2500-003 228-2500-060 228-2500-064 228-2500-007 228-2500-208 228-2500-209...
  • Page 30 228-2500-060 228-2500-028 228-2500-080 228-2500-143 228-2500-114 228-2500-127 228-2500-007 228-2500-064 228-2500-130...
  • Page 31 228-2500-009 228-2500-060 228-2500-003 228-2500-060 228-2500-064 228-2500-007 228-2500-208 228-2500-209...
  • Page 32 228-2500-060 228-2500-028 228-2500-080 228-2500-143 228-2500-114 228-2500-127 228-2500-007 228-2500-064 228-2500-130...
  • Page 33 228-2500-060 228-2500-064 228-2500-114 228-2500-060 228-2500-149 45° 228-2500-157 60° 228-2500-148 228-2500-151 45° 60° 228-2500-148 228-2500-149 228-2500-221...
  • Page 34 228-2500-060 228-2500-060 228-2500-064 228-2500-114 228-2500-149 45° 228-2500-148 60° 228-2500-157 228-2500-151 45° 60° 228-2500-149 228-2500-148 228-2500-221...
  • Page 35 228-2500-060 228-2500-060 228-2500-144 228-2500-144 228-2540 228-2780-001 200mm Forward/ Backward Marche Avant/ Marche Arrière...
  • Page 36 Ans 8+ 228-4444-752 Rev2 Custom manufactured in China for Innovation First Trading SARL. Distributed in the U.S.A. by VEX Robotics, Inc., 1519 Interstate 30 West, Greenville, Texas 75402, U.S.A. Distributed in Europe by Innovation First Trading SARL, 21b rue Gabriel Lippmann, L-5365 Munsbach, Luxembourg +352 27 86 04 87. Distributed in Canada by Innovation First Trading, Inc., 1519 Interstate 30 West, Greenville, Texas 75402, U.S.A.
