- Page 1 The Completed Look of the Build Completed VEX EDR Speed Build This robot is designed so that it can be built quickly and driven around either autonomously or with the V5 Controller.
- Page 2 Parts Needed Can be built with: VEX EDR V5 Classroom Starter Kit...
- Page 3 Build Instructions...
- Page 24 Build Instruction Tips Check the Appendix for info on how to use the new Hex Nut Retainers. Step 4: The green icon indicates that the build needs to be flipped over (upside down). Step 6: Only one of the two sub-assemblies made in this step is used right now. The other will be used later in step 9.
- Page 25 Step 22: The green call outs indicate which port on the Robot Brain to plug each device into using their respective cable.
