Samsung DV10K6500EV User Manual

Hide thumbs Also See for DV10K6500EV:
Table of Contents

Advertisement

Quick Links

Dryer
User manual
DV10K6500EV
DV6500K_DC68-03381E-01_EN.indd 1
11/1/2017 2:56:21 PM

Advertisement

Table of Contents
loading

Related Manuals for Samsung DV10K6500EV

Summary of Contents for Samsung DV10K6500EV

  • Page 1 Dryer User manual DV10K6500EV DV6500K_DC68-03381E-01_EN.indd 1 11/1/2017 2:56:21 PM...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Installation requirements Key installation requirements Location considerations Alcove or closet installations Ducting requirements Exhausting requirements Electrical requirements Installation What’s included Step-by-step installation Vent blockage test Exhaust ducting guide Door reversal...
  • Page 3 Maintenance Vent sensor Cleaning Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Specification sheet Cycle chart Consumption data Sheet of household tumble driers English 3 DV6500K_DC68-03381E-01_EN.indd 3 11/1/2017 2:56:21 PM...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung dryer. This manual contains important information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 Safety information 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
  • Page 7 18. Remove all objects from pockets such as lighters and matches. 19. WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. 20.
  • Page 8 Safety information • Ensure that the power voltage, frequency and current are the same as those of the product specifications. Failure to do so may result in electric shock or fire. Failure Plug the power plug into the wall socket firmly. Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis.
  • Page 9 This appliance should be positioned so that the power plug, the water supply taps, and the drain pipes are accessible. Critical usage warnings WARNING Do not let children or pets on or into the product. In addition, when disposing of this product, disassemble the door lock (lever).
  • Page 10 The use for business purposes qualifies as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 11 • This may result in damage to the laundry. Do not use the dryer near dangerous powders such as coal dust, wheat flour, etc. • This may result in electric shock, fire or an explosion. Do not place inflammable materials near the product. •...

  • Page 12: Installation Requirements

    Installation requirements Read through the following instructions before installing the dryer and keep this manual for future reference. WARNING The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact these parts while the appliance is energized.

  • Page 13: Alcove Or Closet Installations

    Alcove or closet installations WARNING • No other fuel-burning appliance should be installed in the same closet as the • The dryer must be exhausted to the dryer. outside to reduce the risk of fire when installed in an alcove or closet. Minimum clearances between the dryer and adjacent walls or other surfaces: Sides 1 in.
  • Page 14 Installation requirements Installation with pedestal 38.7 in. (984 mm) 53 in. (1345 mm) 53.3 in. (1355 mm) 32.4 in. (823 mm) 27 in. (686 mm) 5 in. (127 mm) English DV6500K_DC68-03381E-01_EN.indd 14 11/1/2017 2:56:23 PM...
  • Page 15 External exhaust elbow requires additional space (L). • Stacking (MODEL NO: SKK-7A) Samsung’s Washer and Dryer can be stacked to maximize usable space. You can purchase an optional stacking kit from your Samsung retailer. For details about stacking and compatible models, refer to the user manual included in the stacking kit you purchase.

  • Page 16: Ducting Requirements

    Installation requirements Ducting requirements Recommended Use only for short-run installation Weather hood type 4” (10.2 cm) 2.5” (6.4 cm) No. of 90° Metallic Metallic Rigid Rigid elbows flexible* flexible* 80 ft. (24.4 m) 41 ft. (12.4 m) 74 ft. (22.6 m) 33 ft.

  • Page 17: Exhausting Requirements

    Exhausting requirements The dryer must not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a building. Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the room.

  • Page 18: Electrical Requirements

    Installation requirements Electrical requirements The wiring diagram is located on the plate • Do not connect the ground wire to under the control panel or rear frame. plastic plumbing lines, gas lines, or hot water pipes. WARNING Electric models • Improperly connecting the equipment grounding conductor can result in a WARNING risk of electric shock.

  • Page 19: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the dryer or the accessories, contact a local Samsung service center or the retailer. Dryer at a glance 01 Worktop...
  • Page 20 Installation Accessories & tools Provided accessories Rack Dry Required tools Pliers Cutting knife Nut screwdriver Level Philips screwdriver Duct tape Wrench WARNING Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.) out of children’s reach. English DV6500K_DC68-03381E-01_EN.indd 20 11/1/2017 2:56:27 PM...

  • Page 21: Step-By-Step Installation

    Step-by-step installation Make sure you have a qualified technician install the dryer. Step by step installation instructions start below. STEP 1 Install the exhaust system Select a location and move the dryer to the site. For easy access, we recommend you install the dryer in the same location as your washer.
  • Page 22 Installation STEP 2 3-WIRE system connections First, read through the “Electrical requirements” section, and then follow these steps. Center silver-colored terminal block Neutral screw. Earth Live Strain relief. a. Loosen the terminal block screws. b. Connect the earth wire (Green/ Yellow Striped wire) of the power cord to the center terminal block screw.
  • Page 23 STEP 3 Level the dryer To ensure optimal performance, the dryer must be level. Using a level (A), check if the dryer is level side to side and then front to back. If the dryer is not level, adjust the leveling feet (B) at the bottom of the dryer.
  • Page 24 Installation STEP 4 Power on Make sure, the exhaust line, and all wiring is connected correctly. Then, plug the power cord into a power source and check the dryer’s installation and operation using the final checklist in Step 6 below. STEP 5 Final check When installation is complete, confirm that: •...

  • Page 25: Vent Blockage Test

    Vent blockage test After the dryer is installed, start the Vent Blockage Test to check if the duct system is properly installed. The Vent Blockage Test automatically detects the status of the ducts and reports any blockage or problems. Proper ducting can reduce drying time and save energy.

  • Page 26: Exhaust Ducting Guide

    Installation NOTE • During or after the test, the internal drum is hot. Use caution to prevent burns. The Vent Blockage Test is used to check for problems to the current duct system when the dryer is installed for the first time. •...

  • Page 27: Door Reversal

    Door reversal Unplug the power cord. Remove two door hinge screws. Lift the door and remove it. NOTE There is a screw on the back side of the hinge that will support the door as you unscrew the hinge screws. Remove the two screws that are above and below the cut-out in the frame front.
  • Page 28 Installation Re-insert the two screws that held the lever holder into the same screw holes, and then tighten. Remove the single screw from the back of the door hinge. NOTE This is the screw that supports the door against the frame so you can unscrew or screw in the hinge without needing to support the door yourself.
  • Page 29 11. Push the lever holder into the cut out on the other side of the door opening. Insert screws, and then tighten as shown. 12. Re-attach the remaining screws to the remaining holes above and below the lever holder, and then tighten. English 29 DV6500K_DC68-03381E-01_EN.indd 29 11/1/2017 2:56:30 PM...

  • Page 30: Before You Start

    Before you start Here are a few things you should know before starting your dryer. Sort and load • Put one wash load in the dryer at a • Overloading reduces the tumbling time. action, resulting in uneven drying and •...

  • Page 31: Rack Dry

    Remove the drying rack from its packaging and store the rack for later use. If a drying rack is not provided, you can purchase it at a local Samsung service center. (Part Code : DC61-02705A) To use the drying rack, follow these steps:...
  • Page 32 Before you start Drying rack drying suggestions Item Cycle settings Washable sweaters (block to shape and lay flat on rack) TIME DRY with the Extra Low temperature setting Stuffed toys (cotton or polyester fiber-filled) Stuffed toys (foam or rubber-filled) Foam rubber pillows AIR FLUFF Sneakers WARNING...

  • Page 33: Operations

    Operations WARNING To reduce the risk of fire, electric shock, or injury, read the “Safety information“ before operating this appliance. Feature panel Turn the Cycle Selector to select the desired cycle. The indicator by the cycle name lights up. 01 Cycle Selector •...
  • Page 34 Operations Press Dry Level to select a dry level. This is available only with the Sensor Dry cycles. • Larger or bulkier loads may require Very Dry or More Dry for complete dryness. • Less Dry is best suited for lightweight fabrics or for leaving some moisture in the clothing at the end of the cycle.
  • Page 35 The Mixed Load Bell notifies you when the average dry level in a load is damp dry (80 % dried). This lets you take items that you don’t want fully dried or that dry quickly out of the dryer early while letting others continue to dry.

  • Page 36: Simple Steps To Start

    Operations Simple steps to start To change the cycle during operation Press POWER to turn on the dryer. Press START/PAUSE to stop operation. Turn the Cycle Selector to select a cycle. Select a different cycle. Change the cycle settings (Dry Level, Press START/PAUSE to start new cycle.

  • Page 37: Cycle Overview

    Cycle overview Cycle Description QUICK DRY A quick drying cycle that runs for 30 minutes TIME DRY You can specify a cycle time in minutes. AIR FLUFF Tumbles the load in room temperature air. The WRINKLE RELEASE cycle will remove wrinkles from Manual Dry items that are clean, dry, and only slightly wrinkled, such WRINKLE...

  • Page 38: Drying Guide

    Operations Drying guide The best way to dry items is to follow the instructions on the care label. If no drying instructions are provided, see the following table for reference. Cycle Description Follow the care label instructions or dry using BEDDING. Bedspreads &...

  • Page 39: Special Features

    To use Smart Care, you must have the code. For best results, hold the Samsung Smart Care app installed on your smartphone so that the front of the smartphone. panel and the smartphone are parallel NOTE or nearly parallel.
  • Page 40 Maintenance Keep the dryer clean to prevent decreased performance and to lengthen its life. WARNING The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact these parts while the dryer is energized. Vent sensor The dryer features a vent sensor that detects and notifies you when it is time to clean the ductwork.
  • Page 41 Cleaning Feature panel Dryer exterior • Clean with a soft, damp cloth. Do not • Clean with a soft, damp cloth. Do not use abrasive substances. use abrasive substances. • Do not spray liquid cleaning agents • Protect the surface from sharp objects. directly on the display of the dryer.
  • Page 42 Troubleshooting Checkpoints If the dryer operates abnormally, first check the list of problems in the table below and try the suggested actions. Problem Action • Make sure the door is latched shut. • Make sure the power cord is plugged into a live electrical outlet.
  • Page 43 Problem Action • Check the load for objects such as coins, loose buttons, nails, etc. Remove promptly. • It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle. Is noisy. •...
  • Page 44 Extended time. reached. The drying time can change according to the type and amount of laundry. See the cycle chart for reference. If a problem persists, contact a local Samsung service center. English DV6500K_DC68-03381E-01_EN.indd 44 11/1/2017 2:56:34 PM...
  • Page 45 • If this information code remains, contact a Samsung service center. Incorrect door switch. • Contact a Samsung service center. If any information code keeps appearing on the screen, contact a Samsung service center. English 45 DV6500K_DC68-03381E-01_EN.indd 45 11/1/2017 2:56:34 PM...
  • Page 46 Specifications Fabric care chart Bleach The following symbols provide garment care direction. The clothing care labels Any bleach (when needed) include symbols for drying, bleaching, Only non-chlorine (color-safe) ironing, and dry cleaning. The use of bleach (when needed) symbols ensures consistency among garment manufacturers of domestic Tumble dry and imported items.
  • Page 47 Iron dry or steam temperatures Dry-clean High Dry-clean Medium Do not dry-clean Line dry / Hang to dry Drip dry Warning symbols for laundering Dry flat Do not wash Do not wring Do not bleach Do not tumble dry No steam (added to iron) Do not iron Protecting the environment This appliance is manufactured from...
  • Page 48 NOTE “A. Height” Spec can vary from 42.4 to 43.3 inches (107.7 - 108.9 cm) depending on the leveling feet adjustments. Front loading dryer Type DV10K6500EV Product - inches (cm) 38.7 (98.4) A. Height Required for Installation - inches 40.7 Product - inches (cm) 27.0 (68.6)
  • Page 49 Cycle chart NOTE For best results, follow the load size recommendations for each dry cycle. • Large load: Fill the drum to about ¾ full. Do not add items over this level as they need to tumble freely. • Medium load : Fill the drum to about ½ full. •...
  • Page 50 Program Load (kg)* Energy (kWh) (Minutes) 6.13 Cotton + Normal Dry ** 3.23 DV10K6500EV Cotton + Damp Dry ** 5.81 Perm Press + Normal Dry 2.95 * : Weight of dry laundry **: EN 61121:2013 test program All data without a “star” against it was calculated using EN 61121:2013...
  • Page 51 (A) re 1 pW Built in Dimensions Height Unit dimensions (mm) Width Depth Net weight Electrical connection Voltage 220-240 Power consumption 4500-5500 Current 20-30 Frequency Name and address of company Samsung Electronics Co., Ltd. English 51 DV6500K_DC68-03381E-01_EN.indd 51 11/1/2017 2:56:42 PM...
  • Page 52 Specifications NOTE Energy consumption 721.0 kWh per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
  • Page 53 Memo DV6500K_DC68-03381E-01_EN.indd 53 11/1/2017 2:56:42 PM...
  • Page 54 Memo DV6500K_DC68-03381E-01_EN.indd 54 11/1/2017 2:56:42 PM...
  • Page 55 Memo DV6500K_DC68-03381E-01_EN.indd 55 11/1/2017 2:56:42 PM...
  • Page 56 SAMSUNG ELECTRONICS Co.,Ltd. (Maetan-dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea Original instructions QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 0330 SAMSUNG (7267864) www.samsung.com/uk/support IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support DC68-03381E-01 DV6500K_DC68-03381E-01_EN.indd 56 11/1/2017 2:56:43 PM...
