- Page 1 OLT-55 Intelligent Optical Loss Tester User’s Manual Shineway Technologies, Inc. All rights reserved.
- Page 2 The NOTE sign information that may be beneficial during the use and maintenance of the instrument. OLT-55 series Optical Loss Tester is a laser device, user should always avoid direct eye exposure to the laser output. Using microscope or magnifier to observe the laser output should also be avoided: laser beam may converge on the retina and cause permanent eye injury.
- Page 3 OLT-55 User’s Manual Laser Radiation: To avoid serious eye injury, never look directly into the optical outputs of fiber optic network equipment, test equipment, Always avoid looking directly into the optical output port, when the instrument is working ...
-
Page 4: Table Of Contents
OLT-55 User’s Manual Contents SAFETY INSTRUCTIONS ................2 SAFETY TERMS USED IN THIS MANUAL ..........2 1. GENERAL INFORMATION ................. 3 1.1 S ....................3 COPE OF THIS ANUAL 1.2 U ..................3 NPACKING AND NSPECTION 1.3 I ......................4 NTRODUCTION 2. -
Page 5: Safety Instructions
OLT-55 User’s Manual 3.5.4 ORL-Setup ......................25 4. MAINTENANCE AND CALIBRATION ............ 25 4.1 C .................. 25 LEANING OF THE CONNECTORS 4.2 C ..................26 ALIBRATION EQUIREMENT 5. WARRANTY INFORMATION ..............27 5.1 T ....................27 ERMS OF ARRANTY 5.2 E ......................... -
Page 6: General Information
OLT-55 User’s Manual 1. General Information 1.1 Scope of this Manual Thank you for purchasing ShinewayTech instrument. Please read this manual carefully before using ShinewayTech fiber optic instrument. Always be aware of the Warning and Caution sign appearing throughout this manual. -
Page 7: Introduction
Pass/Fail assessment to offer user-friendly operation and avoid potential operational mistake. The rugged and easy-to-use OLT-55 is the ideal optical loss tester for FTTx, LAN and CATV application. - Page 8 Automatic Bidirectional Loss Test on Single Fiber Two OLT-55 at both ends of a single optical fiber can perform bidirectional loss test by just pressing one and can automatically measure and display the entire fiber attenuation to help users acquire complete and accurate optical fiber loss information.
-
Page 9: Basic Operation
2. Basic Operation 2.1 Foreword This part introduces the basic operation on OLT-55. Specific operations are elaborated in Chapter 3 of this manual. Please read this manual carefully for optimal operation. If you encounter any problems during operation, you are welcome to contact the technical staff of our company or representatives. -
Page 10: Keypad Operation
OLT-55 User’s Manual 2. USB Power /Data Port OLT-55 can be charged by external power adapter (5V DC, 750mA). 2.2.2 Keypad Operation Power on/off. Toggle between wavelengths. Toggle between setup items; Adjust value in setup mode. Toggle between sub-interfaces in working mode;... -
Page 11: Use Of Battery
OLT-55 works on lithium battery. Please make sure battery is mounted properly before use. When battery is low, low battery indicator will appear on LCD. You can still use OLT-55 as long as its display on LCD is identifiable. When LCD display becomes dim, laser source output will become unstable and power meter measurement will be inaccurate. -
Page 12: Operation
OLT-55 User’s Manual 3. Operation 3.1 Power On Press and loading screen appears, see Figure 3.1. 2011-09-15 17:41 OLT-55ACR Figure 3.1 Then it enters functional interface (The last interface before last shutdown), see Figure 3.2. Auto Power-off Battery Display Time and Date... - Page 13 OLT-55 User’s Manual 2011-09-15 17:41 Optical Power Meter Stabilized Laser Source Optical Return Loss Optical Loss Tester System Setting USB config Version info Figure 3.3 Press to toggle the following function interface: Optical Power Meter Stabilized Laser Source Optical Return Loss...
-
Page 14: Stabilized Laser Source (Sls)
OLT-55 User’s Manual to toggle the following interfaces: Set ref. BiDirTest Save Recall Threshold Setup Optical Return Loss Under [ ]function interface, press to toggle the following interfaces: Test Save Recall Setup The system setup System Setting to enter [... -
Page 15: Sls-Laser On/Off
OLT-55 User’s Manual 2011-09-15 17:41 Unit:dBm 1310nm -55. 73 MOD: 270Hz Display the OPM Status:OFF LaserOff Display the laser source 1310 Display the wavelength Laser Source LaserOnOff Reference Setup Figure 3.4 3.2.1 SLS-Laser On/Off Press to [LaserOnOff] sub-interface, see Figure 3.4;... -
Page 16: Sls-Setup
OLT-55 User’s Manual Press to [Reference] sub-interface, see Figure 3.6; 2011-09-15 17:41 Set reference 1310nm -55. 73 Get from OPM LaserOff 1310 Ref.Power:-10.00dBm Laser Source Reference LaserOnOff Setup Figure 3.6 to select “ Set reference ” and “ Get from OPM ” : Press “... -
Page 17: Optical Power Meter (Opm)
Set reference refers to manual reference value setup; if the laser source (ShinewayTech laser source with AutoID function) on the other side of the tested fiber enables AutoID, the OPM will automatically set the reference value sent from the laser source as reference (“AutoID”... -
Page 18: Opm-Save Record
OLT-55 User’s Manual 3.3.2 OPM-Save Record Press to [Save] sub-interface, see Figure 3.9. 2011-09-15 17:41 1310 Cable:CABLE001 Fiber:FIBER001 Save -57. 43 Power Meter Save Reference Recall Figure 3.9 Press to select item: Cable: and Fiber:, press to edit the information, and then press to confirm. -
Page 19: Opm-Trace
OLT-55 User’s Manual 3.3.3 OPM-Trace Press to [Trace] sub-interface, see Figure 3.11. 2011-09-15 17:41 1310 Draw Trace Scale: 2.0dB Timer: 15min Status:Stop -57. 43 Power Meter Trace Recall Setup Figure 3.11 Press to select item: Draw Trace, Scale, Timer and Status. -
Page 20: Optical Loss Test (Olt)
OLT-55 User’s Manual 2011-09-15 17:41 1310 Zero Unit:dBm -57. 43 Power Meter Setup Recall Trace Figure 3.13 Press to select item: Zero and Unit. Zero: Screw on the dust cap, press the twice, the instrument will be automatically calibrate zero;... -
Page 21: Olt-Reference Setting
OLT-55 User’s Manual 2011-09-15 17:41 Ref.Type:twin Save Start 1310 1550 -3.02 -2.96 Ref.(dBm) Loss Meter Set ref. BiDirTest Save Figure 3.14 3.4.1 OLT-Reference Setting Press to [Set ref.] sub-interface, as shown in Figure 3.14. Press to select Ref. Type, and press to toggle between single and twin, see Figure 3.15. -
Page 22: Olt-Bi-Directional Test
OLT-55 User’s Manual 3.4.2 OLT-Bi-directional Test Press to [BiDirTest] sub-interface, as shown in Figure 3.16. Figure 3.16 Press to select Start, and press to start the test. Press to select Save, and press to save the result. Please also refer to 3.4.3 to save the result. -
Page 23: Olt-Recall
OLT-55 User’s Manual adjustment, press to confirm. Press to select Save, and press to save current record. 3.4.4 OLT-Recall Press to [Recall] sub-interface, as shown in Figure 3.18. 2011-09-15 17:41 Cable CABLE001 Date 2011-09-08 Fiber FIBER012 Time 14:32:13 Del all... -
Page 24: Olt-Setup
OLT-55 User’s Manual adjustment, and press to confirm. Thres: In bi-directional test, OLT-55 determines test result PASS or FAIL according to the thresholds setting. 3.4.6 OLT-Setup Press to [Setup] sub-interface, as shown in Figure 3.19. 2011-09-15 17:41 Zero Auto save to:... - Page 25 OLT-55 User’s Manual with two reference patch cords. See Figure 3.20: Figure 3.20 Under [Set. Ref] sub-interface, select Start and then press , it will display the reference power value on the interface. Toggle to [ BiDirTest ] sub-interface, connect measured fiber link as shown Figure 3.21,...
-
Page 26: Optical Return Loss Test (Orl)-Option
OLT-55 User’s Manual 3.5 Optical Return Loss Test (ORL)-Option Press to [Optical Return Loss] sub-interface, as shown in Figure 3.22. 2011-09-15 17:41 1310 Default ORL Zero ORL Ref(14.7dB) 31. 52 sensitivity:62.53dB ORL Meter Test Save Recall Figure 3.22 3.5.1 ORL-ORL Test Press to [Test] sub-interface, as shown in Figure 3.22. -
Page 27: Orl-Save Record
OLT-55 User’s Manual 3.5.2 ORL-Save Record Press to [Save] sub-interface, as shown in Figure 3.23. 2011-09-15 17:41 1310 Cable:CABLE001 Fiber:FIBER001 Save 31. 52 sensitivity:62.53dB ORL Meter Save Test Recall Figure 3.23 Press to select item: Cable and Fiber, press to enable digit adjustment, press to confirm. -
Page 28: Orl-Setup
OLT-55 User’s Manual 3.5.4 ORL-Setup Press to [Setup] sub-interface, as shown in Figure 3.25. 2011-09-15 17:41 Zero ORL Meter Setup Save Recall Figure 3.25 Screw on the dust cap, press the twice, the instrument will be automatically calibrate zero; Operation Procedure about Optical Return Loss Test:... -
Page 29: Calibration Requirement
OLT-55 User’s Manual 4.2 Calibration Requirement Calibration of OLT-55 is recommended every three years. Please contact Shineway Technologies Inc. or our agent for proper calibration. Shineway Technologies, Inc. - 26 -... -
Page 30: Warranty Information
A warranty registration card is included with the original shipment of equipment. Please take a few moments to fill out the card and mail or fax it to ShinewayTech’s local Customer Service Center to ensure proper initiation of your warranty term and scope of your warranty. -
Page 31: Contact Customer Service
3 cm soft material around the instrument. 5.5 Contact Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service. - Page 32 OLT-55 User’s Manual Shineway Technologies, Inc. - 29 -...
