  • Page 1 OFI-60 Optical Cable Identifier User’s Manual Shineway Technologies, Inc. All rights reserved.
  • Page 2 The NOTE sign information that may be beneficial during the use and maintenance of the instrument. OFI-60 Optical Cable Identifier is a laser device, user should always avoid direct eye exposure to the laser output. Using microscope or magnifier to observe the laser output should also be avoided: laser beam may converge on the retina and cause permanent eye injury.
  • Page 3 OFI-60 User’s Manual into the optical outputs of fiber optic network equipment, test equipment,  Always avoid looking directly into the optical output port, when the instrument is working  Always replace protective dust cap on the detector port when the instrument is not in use.

  • Page 4: Table Of Contents

    OFI-60 User’s Manual Contents SAFETY INSTRUCTIONS ................2 SAFETY TERMS USED IN THIS MANUAL ..........2 1. GENERAL INFORMATION ................. 2 1.1 S ....................2 COPE OF THIS ANUAL 1.2 U ..................2 NPACKING AND NSPECTION 1.3 I ......................3 NTRODUCTION 2.

  • Page 5: Safety Instructions

    OFI-60 User’s Manual 1. General Information 1.1 Scope of this Manual  Thank you for purchasing ShinewayTech instrument. Please read this manual carefully  before using ShinewayTech fiber optic instrument. Always be aware of the Warning and Caution sign appearing throughout this manual.

  • Page 6: Introduction

    Users only need gently knock on cable, when knocking to the target cable, OFI-60 can clearly hear the knock from earphone, which can accurately identify the target cable.

  • Page 7: Basic Operation

    2. Basic Operation 2.1 Foreword This part introduces the basic operation on OFI-60. Specific operations are elaborated in Chapter 3 of this manual. Please read this manual carefully for optimal operation. If you encounter any problems during operation, you are welcome to contact the technical staff of our company or representatives.

  • Page 8: Keypad Instruction To Instrument Panel And Functions

    OFI-60 User’s Manual 2.2.2 Keypad Instruction to Instrument Panel and Functions As shown in the above figure, the keys and touch screen are introduced as follows: represents the power on/off button, which is used to turn on or off the power supply of OCID;...
  • Page 9 OFI-60 User’s Manual represents the noise calibration button, the press of which may activate the automatic calibration of environmental noise, and filter the noise in the bad environment, so as to truly reflect the tapping strength of the optical cable, thus more accurately distinguishing the target optical cable;...

  • Page 10: Use Of Battery

    OFI-60 works on lithium battery. Please make sure battery is mounted properly before use. When battery is low, low battery indicator will appear on LCD. You can still use OFI-60 as long as its display on LCD is identifiable. When LCD display becomes dim, laser source output will become unstable and power meter measurement will be inaccurate.

  • Page 11: Operation

    OFI-60 User’s Manual 3. Operation 1. Determine the head end of cable to be identified, and pick out the one (or two, depending on the testing mode adopted) from the target optical cables to connect the testing equipment; 2. Connect the optical fiber to open testing equipment at the head end of the target cable. It...

  • Page 12: Maintenance And Calibration

    Keep the cleanness of connectors and dust caps. The detector needs to be cleaned timely. 4.2 Calibration Requirement Calibration of OFI-60 is recommended every three years. Please contact Shineway Technologies Inc. or our agent for proper calibration. Shineway Technologies, Inc.

  • Page 13: Warranty Information

    A warranty registration card is included with the original shipment of equipment. Please take a few moments to fill out the card and mail or fax it to ShinewayTech’s local Customer Service Center to ensure proper initiation of your warranty term and scope of your warranty.

  • Page 14: Contact Customer Service

    3 cm soft material around the instrument. 5.5 Contact Customer Service Please check our web site (www.shinewaytech.com) for updates to this manual and additional application information. If you need technical or sales support, please contact local Shineway Technologies Customer Service.
