ANI-F-VX
Multi-Format ANI Encoder
Manual Revision: 2011-04-06
This manual & product supports the following radios:
Portables: VX-350, VX-410, VX-420, VX-450-VX-460, VX-600, VX-800, VX-820, VX-900, VX-920
Mobiles: VX-2100, VX-2200, VX-4000, VX-4100, VX-4200, VX-4500, VX-4600, VX-5500, VX-6000
Covers Software Revisions:
ANI-F: 1.0 & Higher
American Communication Systems
Discover the Power of Communications
™
http://www.ameradio.com
TO ORDER – VISIT
1
Advertisement
Table of Contents
Related Manuals for Midian ANI-F-VX Series
Summary of Contents for Midian ANI-F-VX Series
- Page 1 ANI-F-VX Multi-Format ANI Encoder Manual Revision: 2011-04-06 This manual & product supports the following radios: Portables: VX-350, VX-410, VX-420, VX-450-VX-460, VX-600, VX-800, VX-820, VX-900, VX-920 Mobiles: VX-2100, VX-2200, VX-4000, VX-4100, VX-4200, VX-4500, VX-4600, VX-5500, VX-6000 Covers Software Revisions: ANI-F: 1.0 & Higher American Communication Systems Discover the Power of Communications ™...
-
Page 2: Hardware Specifications
Assign calls fairly. The ANI-F-VX offers ANI & Emergency ANI in Motorola’s MDC-1200, Kenwood’s FleetSync, Harris’ G-Star (aka GE-Star), DTMF and 5-tone. The ANI-F can be used with Midian’s ADD, CAD, DDU and TRC Series products for monitoring ANI and ENI transmissions. -
Page 3: Product Programming
PRODUCT PROGRAMMING Midian’s ANI-F-VX is programmed via Midian’s KL-3 and VPI-1 or the new KL-4 programmer. Please reference the KL-4 manual or the KL-3 and VPI-1 manuals for setup instructions. From the product selection screen on the KL-3 software, select the ANI-F-VX from the list and the desired ANI format and click OK. If 2-tone or custom tones will be used in the ANI-F-VX, you will need to select “Enable Advanced ANI Tone Definitions”... -
Page 4: Hardware Installation
HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. VX-350: Remove the battery, exposing the option board cover and remove the cover. Plug the module onto the options connector. Replace the option board cover and battery. The ANI-F-VX requires this radio have firmware version 1.0 or higher. -
Page 5: Hardware Alignment
VX-4000, VX-5500 & VX-6000: Remove the cover of the radio exposing the options connector. Plug the FIF-7 (from Vertex) onto the options connector. Then plug the ANI-F-VX onto the FIF-7. It may be necessary, for PTT control, to either jumper pins 6 &... -
Page 6: Radio Programming
RADIO PROGRAMMING VX-350: For the VX-350 radio programming software CE-86 v1.01 or higher must be used. Read the radio with the option board installed. Select “Common” from the menu and then “Option”. The “Option Unit” should be read as “FVP-35”. Under the “Common”... - Page 7 VX-800: This radio requires programming software CE-31 v1.20 or higher. Read the radio with the option board installed. Select “Signaling” from the menu and then “ANI”. Set the “ANI Type” as “Option ANI”. To set a button for control of the Emergency ANI, select “Common” from the menu and then “Key Function”. Set “(Sel 1) Key”...
- Page 8 VX-4500 & VX-4600: For the VX-4500 & VX-4600 radio programming software CE-115 v1.01 or higher must be used. Read the radio with the option board installed. Select “Common” from the menu and then “Option”. The “Option Unit” should be read as “FVP-35”. Emergency ANI is not supported in this radio.
-
Page 9: Operation
In Frame 3, Frequency 1 type in the frequency of the second tone and type the length of the second tone in Frame 3 msec. RMK-4000: Go-Ahead beeps are not supported in this radio. MIDIAN CONTACT INFORMATION Midian Electronics, Inc. 2302 East 22... - Page 10 This page intentionally left blank...
