- Page 1 Welch Allyn Braun ThermoScan® PRO 4000 Inservice MC12687...
-
Page 2: Table Of Contents
Table of Contents Overview Cleaning Cleaning the Electrical Contacts Probe Covers Tympanic Measurements Interferences Contraindications Error Messages and Solutions Base Station and Anti-Theft Function 10. Memory Mode 11. Temperature Scale 12. Batteries 13. Resources MC12687... -
Page 3: Overview
Overview Probe Displayed Temperature Range: 68–108 °F (20–42.2 °C) Probe cover detector Probe cover ejector Age Range: Full-term newborn, pediatric, and adult patients Display “mem” button Fast and Accurate: Preheated probe for more accurate and faster readings. ExacTemp light to ensure proper, steady positioning Safe: Probe cover eject button designed to reduce the risk of cross-contamination... -
Page 4: Cleaning
Cleaning Speculum tip Clean with 70% or stronger isopropyl alcohol only, using a Q-tip® or equivalent Lens Window Gently wipe its surface with a cotton swab or cloth slightly moistened with alcohol and immediately wipe dry with a clean cotton swab or cloth. -
Page 5: Cleaning The Electrical Contacts
Cleaning the Electrical Contacts Clean charging dock, rechargeable battery and thermometer electrical contacts regularly. • Every 3 months OR • Any time the charging or communication performance between the thermometer and dock becomes erratic. • Ex. Incomplete charging or thermometer fails to transfer a reading To clean electrical contacts Use a cotton swab slightly dampened with isopropyl alcohol ONLY. -
Page 6: Probe Covers
• Always use PRO 4000 disposable probe covers. • The new PRO 4000 probe covers can be used with all models of Braun ear thermometers. • Older version probe covers (i.e. those purchased for the PRO 3000) cannot be used with the PRO 4000. The result will be inaccurate readings. -
Page 7: Tympanic Measurements
Tympanic Measurements Proper Probe Placement Guide MC12687... -
Page 8: Interferences
Interferences DOES affect temperature accuracy • A used probe cover • Wet/dirty/damaged probe lens • Hearing aid • Lying on a pillow For persons wearing hearing aids or in extreme ambient temperatures, remove the hearing aid or the individual from the situation and wait 20 minutes prior to taking a temperature. -
Page 9: Contraindications
Contraindications • Do not use if there is blood or drainage in the external ear canal. • Do not use if a patient exhibits symptoms of an acute or chronic inflammatory condition of the external ear canal. • Not intended for pre-term babies small-for-gestational age babies. -
Page 10: Error Messages And Solutions
Error Messages and Solutions MC12687... -
Page 11: Base Station And Anti-Theft Function
Base Station and Anti-Theft Function Base Station • Can be purchased separately • Automatically recharges thermometer when using rechargeable batteries (included with base station) • Has configurable anti-theft function • Can be wall-mounted for convenient storage Anti-Theft Function • Requires returning the thermometer to the station within an individually pre-selected time •... -
Page 12: Memory Mode
Memory Mode The last temperature taken before the thermometer is turned off is stored in its memory and will be automatically displayed when it is turned on again. The display will show MEM. After taking a new temperature, press the mem button to recall the last reading. MC12687... -
Page 13: Temperature Scale
Temperature Scale The PRO 4000 is shipped with the Fahrenheit temperature scale activated. To switch to Celsius Make sure the thermometer is turned off Press and hold the mem button. After approximately 3 seconds, the display will show: °F/SET/°C/SET… Release the mem button when °C is shown. A short beep will confirm the new setting, and then it will automatically turn off. -
Page 14: Batteries
Batteries • Operates using two (2) AA batteries or optional rechargeable battery pack • Rechargeable batteries come with separately purchased base station • Average battery life is 6 months or 1000 measurements Rechargeable batteries Standard AA batteries Battery Replacement 1. Open battery compartment using a pen 2. -
Page 15: Resources
Resources Thank you for choosing Welch Allyn Customer Care: 1-800-535-6663 Website: www.welchallyn.com MC12687...
