Controls and Indicators
12 S&C Instruction Sheet 658-500
Table 4. PureWave CES Warning Alarms—continued
Alarm
BatteryCellUnderTemperature
BatteryCellUnderVoltage
BatteryDetectedWater
BatteryMaintenanceRequired
BatteryOverCurrent
BatteryRequestsShutdown
ConserveEnergyModeActive
DcLinkDissipatorInstalled
EmergencyVoltageRegulation
IgbtOverTempWarningLine1
IgbtOverTempWarningLine2
InverterCurrentLimitLine1
InverterCurrentLimitLine2
IoDeviceCommsLoss
MaintenanceChargeOrDischarge
McuMediaInitFailure
McuMediaOperationFailure
McuMediaUnavailable
MisconfiguredSchedule
ScadaCommError
TotalSystemShutdownImminent
Description
Indicates that the battery cell has gotten too
cold .
Indicates that the battery cell has drained to a
very low level .
Indicates that the battery detected water in the
container .
Indicates that the battery requires
maintenance . Please contact S&C Electric
Company .
Indicates that more current was flowing into or
out of the battery than the battery allowed .
Indicates that the battery is requesting to shut
down .
Indicates that the PureWave CES is in
conserve energy mode .
Indicates that the DC jumper is installed .
When safe to do so, remove it from the control
panel .
Indicates that the inverter is generating
reactive power to correct the line voltage .
Indicates that IGBT on line 1 is too hot .
Indicates that IGBT on line 2 is too hot .
Indicates that the inverter is working at its limit
on line 1 .
Indicates that the inverter is working at its limit
on line 2 .
Indicates that the PureWave CES is
experiencing loss of communications .
Indicates that the PureWave CES is providing
a maintenance charge or discharge to the
battery .
Indicates that the internal compact flash card
did not initialize properly . Please contact S&C
Electric Company .
Indicates that the internal flash card had an
internal anomaly . Please contact S&C Electric
Company .
Indicates that the internal flash card is not
available for logging . Please contact S&C
Electric Company .
Indicates that the PureWave CES has an
improper schedule configuration .
Indicates that there is a problem with the radio
or hardwired SCADA communications .
Indicates that the PureWave CES is about
to enter system shutdown after being in the
Conserve Energy state too long .
Reset Type
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
