Table 3. PureWave CES Information Statuses—continued
Alarm
DcContactorOpenCmd
EmergencyVoltageRegEnabled
InverterLimitedByBatteryLimits
InverterLimitedByLocalLoadControl
InverterOutputLimited
IslandingInhibited
IslandingRequested
LocalLoadControlEnabled
ManualReset
McuExecutionInterrupted
McuMediaStorageCapacity
PowerOverVarsMode
PowerScheduleMode
PowerSetpointRegulationMode
PowerSmoothingMode
VarSetpointRegulationMode
VoltageSetpointRegulationMode
VsReturnDelayActive
Warning Alarms
This type of alarm indicates a problem that may need attention but will not affect the
proper operation of the system. The system will continue to operate when a "warning"
is being displayed. See Table 4 for the listed warning alarms.
Table 4. PureWave CES Warning Alarms
Alarm
AutoResetLockout
BatteryCellOverTemperature
BatteryCellOverVoltage
Controls and Indicators
Description
Indicates that the DC breaker has been
commanded open .
Indicates that the autonomous voltage
regulation using reactive power is enabled on
the unit . The PureWave CES may generate
reactive power based on the measured
voltage .
Indicates that the inverter is limited by the
battery output .
Indicates that the inverter is controlled by the
local load .
Indicates that the inverter output is limited .
Reduce the load .
Indicates that the PureWave CES been
inhibited to island .
Indicates that the PureWave CES has been
requested to island .
Indicates that the PureWave CES is in SCADA
DISABLE mode .
Indicates that the inverter has been reset
manually .
Indicates an issue occurred in the execution
on the communication processor .
Indicates that the internal compact flash card
is at its capacity .
Indicates that the PureWave CES is
configured to give preference to power over
VARs, when approaching the system rating .
Indicates that the PureWave CES is operating
in a power scheduling mode .
Indicates that the PureWave CES is operating
in a power setpoint regulation mode .
Indicates that the PureWave CES is operating
in a power smoothing mode .
Indicates that the PureWave CES is operating
in a reactive power setpoint regulation mode .
Indicates that the PureWave CES is operating
in a voltage regulation mode .
Indicates that the PureWave CES is in the
process of returning to a grid connected mode
of operation .
Description
Indicates that the Auto Reset counter has
been exceeded .
Indicates that the battery cell has gotten too
hot .
Indicates that the battery cell has over-
charged .
S&C Instruction Sheet 658-500
Reset Type
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
MANUAL
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
Reset Type
MANUAL
SELF
SELF
TABLE CONTINUED ▶
