  • Page 1 VIPA Accessories 306-1UE00 | Manual HB37E_IM | RE_306-1UE00 | Rev. 15/22 May 2015...
  • Page 2 Copyright © VIPA GmbH. All Rights Reserved. This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agreements. This material is protected by the copyright laws. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to VIPA), except in accordance with applicable agreements, contracts or licensing, without the express written consent of VIPA and the business management owner of the material.

  • Page 3: Table Of Contents

    Manual VIPA Accessories Contents Contents About this manual ..................1 Safety information ..................2 Chapter 1 Basics ................1-1 Safety information for users ..............1-2 System conception ................1-3 Basics PROFIBUS ................1-5 Chapter 2 Assembly and installation guidelines......2-1 Assembly possibilities................
  • Page 4 Manual VIPA Accessories Contents HB37E - IM - RE_306-1UE00 - Rev. 15/22...

  • Page 5: About This Manual

    Manual VIPA Accessories About this manual About this manual This manual describes the VIPA IM 306-1UE00 DP-Slave for the AG-135U/155U. Here you may find every information for commissioning and operation. Overview Chapter 1: Basics With this basics you get hints for the usage of the module. After the description of the system conception you get basics concerning PROFIBUS DP-V1.
  • Page 6 Manual VIPA Accessories About this manual This manual describes the VIPA IM 306-1UE00 DP-Slave for the AG- Objective and 135U/155U. It contains a description of the construction, project contents implementation and usage. This manual is part of the documentation package with order number...

  • Page 7: Safety Information

    Manual VIPA Accessories Safety information Safety information The IM 306-1UE00 DP slave is constructed and produced for: Applications conforming with • deployment at the IM slot of an AG-135U/155U specifications • communication and process control • general control and automation applications •...
  • Page 8 Manual VIPA Accessories Safety information HB37E - IM - RE_306-1UE00 - Rev. 15/22...

  • Page 9: Chapter 1 Basics

    Manual VIPA Accessories Chapter 1 Basics Chapter 1 Basics With this basics you get hints for the usage of the module. Overview After the description of the system conception you get basics concerning PROFIBUS DP-V1. Content Topic Page Chapter 1 Basics ................

  • Page 10: Safety Information For Users

    Manual VIPA Accessories Chapter 1 Basics Safety information for users VIPA modules make use of highly integrated components in MOS- Handling of technology. These components are extremely sensitive to over-voltages electrostatic that can occur during electrostatic discharges. sensitive modules The following symbol is attached to modules that can be destroyed by...

  • Page 11: System Conception

    Since you have to replace your CPU respectively IM interface connection by the IM 306 DP slave, a new wiring of the I/O periphery is not necessary. For the AG-135U/155U the following IM 306 DP slaves from VIPA are possible: Order number Deployment at ...
  • Page 12 Manual VIPA Accessories Chapter 1 Basics If you want the support of modules with interrupt capability, this structure is Deployment to be used: IM 306-1UZ00 IM 306-1UE00 (interrupt capability) Master system IM 306-1UZ00 CPU CP IM 306-1UE00 IM 306-1UE00 HB37E - IM - RE_306-1UE00 - Rev. 15/22...

  • Page 13: Basics Profibus

    Manual VIPA Accessories Chapter 1 Basics Basics PROFIBUS PROFIBUS is an international standard applicable to an open field bus for General building, manufacturing and process automation. PROFIBUS defines the technical and functional characteristics of a serial field bus system that can be used to create a low (sensor-/actuator level) or medium (process level) performance network of programmable logic controllers.
  • Page 14 Manual VIPA Accessories Chapter 1 Basics PROFIBUS distinguishes between active stations (master) and passive Master and slaves stations (slave). Master devices Master devices control the data traffic at the bus. It is also possible to operate with multiple masters on a PROFIBUS. This is referred to as multi- master operation.
  • Page 15 Manual VIPA Accessories Chapter 1 Basics The bus transfer protocol provides two alternatives for the access to the Communication bus: Master communication is also referred to as token-passing procedure. The Master with token-passing procedure guarantees the accessibility of the bus. The...
  • Page 16 Manual VIPA Accessories Chapter 1 Basics • Max. 125 DP slaves at one DP master - max. 32 slaves/segment. Restrictions • You can only install or remove peripheral modules when you have turned the power off! • The max. distance for RS485 cables between two stations is 1200m (depending on the baud rate).
  • Page 17 Manual VIPA Accessories Chapter 1 Basics The key feature of version DP-V1 is the extended function for acyclic data Function communication. This forms the requirement for parameterization and Acyclic data calibration of the field devices over the bus during runtime and for the communication introduction of confirmed alarm messages.
  • Page 18 Manual VIPA Accessories Chapter 1 Basics When addressing data, PROFIBUS assumes that the physical structure of Addressing with the slaves is modular or it can be structured internally in logical functional Slot and Index units, so-called modules. This model is also used in the basic DP functions...
  • Page 19 Manual VIPA Accessories Chapter 1 Basics Additional available services are shown in following table. Services Acyclic data More detailed information to the services and the DP-V0/1 communication - principles is to find in the PROFIBUS norm IEC 61158. communication DPM 1 (MSAC-C1)
  • Page 20 For the IM 306 DP slave there are GSD files available from VIPA. These GSD file may be downloaded from the "Service" area of www.vipa.com.

  • Page 21: Chapter 2 Assembly And Installation Guidelines

    Manual VIPA Accessories Chapter 2 Assembly and installation guidelines Chapter 2 Assembly and installation guidelines In this chapter you will find all information, required for the installation and Overview the PROFIBUS cabling. Content Topic Page Chapter 2 Assembly and installation guidelines......2-1 Assembly possibilities................

  • Page 22: Assembly Possibilities

    CPU CP IM 306-1UE00 IM 306-1UE00 Slots in the In the following for the IM 306-1UE00 DP slave the possible slots at the AG-135U/155U racks are shown. Possible positions are identified by X . Slot 11 19 27 35 43 51 59 67 75 83 91 99 107 115 123 131 139 147 155 163...

  • Page 23: Installation Guidelines

    Manual VIPA Accessories Chapter 2 Assembly and installation guidelines Installation guidelines The installation guidelines contain information about the interference free General deployment of System SLIO. There is the description of the ways, interference may occur in your control, how you can make sure the electromagnetic digestibility (EMC), and how you manage the isolation.
  • Page 24 Manual VIPA Accessories Chapter 2 Assembly and installation guidelines In the most times it is enough to take care of some elementary rules to Basic rules for guarantee the EMC. Please regard the following basic rules when installing your PLC.
  • Page 25 Manual VIPA Accessories Chapter 2 Assembly and installation guidelines Electrical, magnetically and electromagnetic interference fields are Isolation of weakened by means of an isolation, one talks of absorption. conductors Via the isolation rail, that is connected conductive with the rack, interference currents are shunt via cable isolation to the ground.

  • Page 26: Profibus Installation Guidelines

    Manual VIPA Accessories Chapter 2 Assembly and installation guidelines PROFIBUS installation guidelines • A PROFIBUS DP network may only be built up in linear structure. PROFIBUS in general • PROFIBUS DP consists of minimum one segment with at least one master and one slave.
  • Page 27 In PROFIBUS all participants are wired parallel. For that purpose, the bus bus connector cable must be feed-through. Via the order number VIPA 972-0DP10 you may order the bus connector "EasyConn". This is a bus connector with switchable terminating resistor and integrated bus diagnostic.
  • Page 28 A (EN50170). Starting with release 5 you also can use highly flexible bus cable: Lapp Kabel order no.: 2170222, 2170822, 2170322. Under the order no. 905-6AA00 VIPA offers the "EasyStrip" de-isolating tool that makes the connection of the EasyConn much easier.

  • Page 29: Chapter 3 Hardware Description

    Manual VIPA Accessories Chapter 3 Hardware description Chapter 3 Hardware description Here the hardware components of the IM 306 DP slave are more Overview described. The technical data may be found at the end of this chapter. Content Topic Page Chapter 3 Hardware description .............

  • Page 30: Properties

    • Integrated DC 24V power supply to supply the back plane bus if necessary Ordering data Type Order number Description IM 306 VIPA 306-1UE00 DP slave for IM slots in the AG-135U/155U HB37E - IM - RE_306-1UE00 - Rev. 15/22...

  • Page 31: Structure

    Manual VIPA Accessories Chapter 3 Hardware description Structure LED status display IM 306-1UE00 Address switch RS485 interface Jack for DC 24V power supply The IM 306 DP slave has a number of LEDs, which are available for LEDs diagnostic purposes on the bus and for displaying the local state. With the...
  • Page 32 The PROFIBUS address of the slave may be adjusted by this address switch. Permitted addresses are 2 to 125. Please regard with VIPA components the address 1 is system- dependently reserved. Each address may only once be assigned at the bus. Before the startup the PROFIBUS address is to be preset.

  • Page 33: Technical Data

    Manual VIPA Accessories Chapter 3 Hardware description Technical data Order no. 306-1UE00 Type IM 306 DP slave 135U/155U Technical data power supply Power supply (rated value) DC 24 V Power supply (permitted range) DC 20.4...28.8 V Reverse polarity protection Current consumption (no-load operation) 0.1 A...
  • Page 34 Manual VIPA Accessories Chapter 3 Hardware description Order no. 306-1UE00 Certifications UL508 certification If the module is power supplied by backplane bus, the module has a current consumption of 400mA. HB37E - IM - RE_306-1UE00 - Rev. 15/22...

  • Page 35: Chapter 4 Deployment

    Manual VIPA Accessories Chapter 4 Deployment Chapter 4 Deployment This chapter describes the deployment of the IM 306 DP Slave. With the Overview fast introduction you get a fast overview of the approach to convert your Siemens S5 PLC to S7. The steps of the fast introduction are more described at the following pages.

  • Page 36: Fast Introduction

    Manual VIPA Accessories Chapter 4 Deployment Fast introduction • The module 306-1UE00 may only be used at the IM slot of the AG- In principle is valid 135U/155U. Here the module is to be connected via PROFIBUS to a master system.
  • Page 37 Configuration master engineering tool by assigning the IM 306 DP slave module. VIPA serves GSD files for the IM 306 DP slave. These may be downloaded from the "Service area" of www.vipa.com. The IM 306 DP slave may be configured as DP-V0 or as DP-V1 slave. There is a GSD file for each type.

  • Page 38: Power Supply

    Manual VIPA Accessories Chapter 4 Deployment Power supply Depending on the used Siemens S5 rack the power supply happens via Overview backplane bus or with the integrated DC 24V power supply via front jack. If your rack may power supply your module via backplane bus, the module automatically starts-up when snapped to the rack.

  • Page 39: Installation

    Manual VIPA Accessories Chapter 4 Deployment Installation • The module 306-1UE00 may only be used at the IM slot of the AG- In principle is valid 135U/155U. Here the module is to be connected via PROFIBUS to a master system.

  • Page 40: Project Engineering Dp Slave

    "VIPA_306-1UE00 [DPV...]": PROFIBUS DP > Additional Field devices > I/O VIPA_306_1XX00 VIPA serves GSD files for the IM 306 DP slave. Depending on the installed DP-V0/DP-V1 GSD file the following modules are embedded to the hardware catalog:...

  • Page 41: Dp-V0 Slave Parameterization

    The SYNC- and FREEZE control commands of the master are supported capabilities by the IM 306 DP slave from VIPA. The DP master sends the SYNC control command to a group of DP slaves causing the DP slaves to freeze the states of their outputs at their current value.
  • Page 42 Manual VIPA Accessories Chapter 4 Deployment If activated the DP slave may react on a master failure or an interruption at Watchdog the bus. Default value: activated After the Watchdog expires, the DP slave leaves the state of Data Exchange (DE) and the outputs switch to "0".

  • Page 43: Dp-V1 Slave Parameterization

    The SYNC- and FREEZE control commands of the master are supported capabilities by the IM 306 DP slave from VIPA. The DP master sends the SYNC control command to a group of DP slaves causing the DP slaves to freeze the states of their outputs at their current value.
  • Page 44 Manual VIPA Accessories Chapter 4 Deployment If activated the DP slave may react on a master failure or an interruption at Watchdog the bus. Default value: activated After the Watchdog expires, the DP slave leaves the state of Data Exchange (DE) and the outputs switch to "0".
  • Page 45 Manual VIPA Accessories Chapter 4 Deployment Behavior at QVZ Here you may define, how the DP slave will behave on failure respectively on missing a module at the back plane bus. There are the following setting options: Software reset, WaitPrm The DP slave executes a reset and waits for parameter of the master.

  • Page 46: Configure Dp Slave

    1. slot. For this go to the Siemens hardware catalog, click at Additional field devices > I/O > VIPA_306_1XX00 > VIPA 306-1... at the corresponding DP slave and pull it from the hardware catalog to the corresponding slot. The module is placed at the corresponding slot and is assigned to a periphery address.
  • Page 47 Manual VIPA Accessories Chapter 4 Deployment If your module is not listed at the Siemens hardware catalog there is the Configuration via possibility to use a substitution module, which corresponds to the I/O area I/O area of your module. Please consider that you may only use 1 slot for each module! A combination of these areas for one module is not possible.

  • Page 48: Determine Rack Periphery Address

    Manual VIPA Accessories Chapter 4 Deployment Determine rack periphery address To get access with your master system to a module in the rack, the Rack Overview Periphery Address of the module is to be determined and entered to the properties dialog of this module, during hardware configuration.
  • Page 49 Manual VIPA Accessories Chapter 4 Deployment Variables table of the function: "Show 135U process image" Example Containing ED 0: DI 4: address 4 address bytes ED 16: AI 4: address 128 ED 32: DO 4: address 0 ED 68: DI 4: address 32...

  • Page 50: Hardware Configuration - S5 Modules

    Manual VIPA Accessories Chapter 4 Deployment Hardware configuration - S5 modules After placing the IM 306 slaves place the S5 modules in the plugged Hardware sequence. configuration of the modules Note! Please consider that the hardware configuration contains no gaps. Gaps...
  • Page 51 Manual VIPA Accessories Chapter 4 Deployment If you can not find your module in the hardware catalog, you have the X-Byte DI/DO possibility to reproduce the module by means of the X-Byte DI/DO Modules according to its address assignment. Please consider that you may only use 1 slot for each module! A combination of these areas for one module is not possible.
  • Page 52 Manual VIPA Accessories Chapter 4 Deployment Parameter For parameterization double-click at the slot overview on the module you want to parameterize. In the appearing dialog window you may set the wanted parameters. Parameterize in the properties dialog at Device-specific parameters the module type "S5-135U/155U"...
  • Page 53 Manual VIPA Accessories Chapter 4 Deployment Data conversion analog input module: 27648 ⋅ ⋅ 27648 16384 ⋅ ⋅ 16384 Data conversion 27648 ⋅ ⋅ S5 > S7: 16384 DS7: Decimal value S7 format DS5: Decimal value S5 format U: Voltage value...

  • Page 54: Dp-V1 - Services

    Using the following record set no. as Index you get access for reading (R) to the listed DP slave elements: Index Access Description Device name as ASCII code (VIPA 306-1...) Hardware Version as ASCII code (V1.00) Software Version as ASCII code (V1.00) Serial number of the device as ASCII code (e.g.

  • Page 55: Diagnostic Functions

    Manual VIPA Accessories Chapter 4 Deployment Diagnostic functions PROFIBUS DP provides an extensive set of diagnostic functions for quick Overview error localization. Diagnostic messages are transferred via the bus and collected by the master. In the case of a diagnostic with DP-V1 the DP slave gets a feedback from the DP master.
  • Page 56 Manual VIPA Accessories Chapter 4 Deployment Via the Identifier related diagnostic you gain information at which slot Identifier related (module) an error has occurred. diagnostic More detailed information about the error is available via the Module state and the Channel related diagnostic.
  • Page 57 Manual VIPA Accessories Chapter 4 Deployment The Module status gives you detailed information about the error that Module status occurred at a module. The Module status may be activated via the parameterization and has the following structure: Module status Byte Bit 7 ...
  • Page 58 Manual VIPA Accessories Chapter 4 Deployment With the Channel related diagnostic you gain detailed information about the Channel-related channel error within a module. For the usage of the Channel related Diagnostic diagnostic you have to release the diagnostic interrupt for every module via the parameterization.
  • Page 59 Manual VIPA Accessories Chapter 4 Deployment The interrupt section of the slave diagnostic shows information about Interrupts interrupt type and cause. It consists of max. 12bytes. For every slave diagnostic max. 1 interrupt may be sent. The interrupt section is always the last part of the diagnostic telegram if activated in the parameterization.

  • Page 60: Firmware Update

    • Transfer firmware The most recent firmware for the IM 306 DP slave may be found at Supply firmware www.vipa.com in the service area at "Firmware for system components" as file header.upd IM306_135U.zip. Within the ZIP file the package file Px000096_Vxxx.zip with xxx=version may be found.
