Page 1: Table Of Contents
CITY LITE Model Version 1.0 CITY LITE Model Quick Start Guide 1. Setting Up Pg. 2 2. Charging Pg. 4 3. Controller Pg. 5 4. Basics Pg. 6 5. Folding & Unfolding Pg. 7 6. Freewheel Operation Pg. 8 7. Troubleshooting & Diagnostics Pg. -
Page 2: Setting Up
CITY LITE Model Version 1.0 Setting Up Your CITY LITE Your CITY LITE portable wheelchair will arrive with the following components: Main Assembly Battery (will already be installed in main assembly; additional battery extra) Controller 1. Raise the backrest until it snaps into place 2. - Page 3 CITY LITE on an airplane, be sure to examine the entire frame and all screws and bolts for any damage during baggage handling. NOTE: Keep your CITY LITE clean and dry and you will ensure that you have a long life of use from your wheelchair.
-
Page 4: Charging
CITY LITE Model Version 1.0 Charging the Battery Your CITY LITE will arrive with a fully charged battery, which should last a maximum of 20 km or 12 miles under normal running conditions. A second battery can be purchased by contacting The Travel Buggy, which will extend the run time. -
Page 5: Controller
CITY LITE Model Version 1.0 Controller The Controller on your CITY LITE features a full joystick style control, horn, speed control, battery indicator and power buttons as shown: Increase speed Power ON (go faster) Horn Speed Indicator Battery Power Indicator... -
Page 6: Basics
CITY LITE Model Version 1.0 Basic Operation Be certain that the power is OFF before sitting in the seat of your CITY LITE, with no GET IN lights on the controller. POWER ON Press the Power button, you will hear a beep and a light will indicate power is on. -
Page 7: Folding & Unfolding
3. Store cushion 4. Squeeze levers and fold back rest down 5. Pull cable 6. Fold up For instructions how to unfold the CITY LITE, follow the steps above in reverse order or see Page 2 of this Quick Start Guide. -
Page 8: Freewheel Operation
In Freewheel mode, your caregiver or family member can manually move the CITY LITE, pushing you without aid of the battery power. Placing your CITY LITE in Freewheel mode disengages the wheel from the motor assembly so that the chair can easily be pushed. -
Page 9: Troubleshooting & Diagnostics
CITY LITE Model Version 1.0 Troubleshooting & Diagnostics The following represents the most common questions asked about the CITY LITE with regard to everyday use; check this helpful guide or the operator’s manual for more information if you have a question about... - Page 10 CITY LITE may use to indicate problems. It is important to pay attention to these diagnostics in case the CITY LITE must be put out of use for safety reasons until maintenance can be performed.
-
Page 11: Specifications & Precautions
Do not operate the CITY LITE while on a moving vehicle such as a bus. Do not lean your body to reach out of the CITY LITE, causing a balance issue. Do not exceed the weight limit total of 120 kg (265 lbs.) for rider plus any items. - Page 12 CITY LITE Model Version 1.0 1-888-56-BUGGY contact@thetravelbuggy.com...
