Page 1: Table Of Contents
CITY Model Version 1.0 CITY Model Quick Start Guide 1. Setting Up Pg. 2 2. Charging Pg. 4 3. Controller Pg. 5 4. Basics Pg. 6 5. Folding & Unfolding Pg. 7 6. Freewheel Operation Pg. 8 7. Troubleshooting & Diagnostics Pg. -
Page 2: Setting Up
Main Assembly Controller Grasp the padded bar and pull up while pushing down on the seat to expand the CITY and complete the assembly: Grasp top bar and push down seat to expand. Push down to lock seat latch. - Page 3 Setting Up Your CITY Slide the Controller into the open slot on the arm of the CITY on the right side (unless pre-ordered for left- handed users). Tighten knob to secure controller and connect controller wire harness to controller CPU wire harness that runs from the chair itself.
-
Page 4: Charging
3. Plug the charger power harness into the charger and then into a grounded wall outlet. 4. Allow your CITY to charge for 6 to 8 hours or when the light on the charger turns green, which means your batteries are fully charged. -
Page 5: Controller
CITY Model Version 1.0 Controller The Controller on your CITY features a full joystick style control, horn, speed control, battery indicator and power buttons as shown: Increase speed Power ON (go faster) Horn Speed Indicator Battery Power Indicator Reduce Speed... -
Page 6: Basics
Make sure you understand the appropriate environment in which to operate your CITY and how to use all controls safely. Practice controlling your CITY and understand how fast or slow it goes by operating it in a controlled, private environment until you are aware how it operates. -
Page 7: Folding & Unfolding
CITY. Alternatively, push the top frame toward the ground with one hand to fold. 5. When folded, the footrest can be used as a hand-hold to move the CITY easily. For instructions how to unfold the CITY, follow the steps above in reverse order or see Page 2 of this Quick Start Guide... -
Page 8: Freewheel Operation
In Freewheel mode, your caregiver or family member can manually move the CITY, pushing you without aid of the battery power. Placing your CITY in Freewheel mode disengages the wheel from the motor assembly so that the chair can easily be pushed. -
Page 9: Troubleshooting & Diagnostics
CITY Model Version 1.0 Troubleshooting & Diagnostics The following represents the most common questions asked about the CITY with regard to everyday use; check this helpful guide or the operator’s manual for more information if you have a question about using... - Page 10 The following is a chart of the diagnostic light codes that your CITY may use to indicate problems. It is important to pay attention to these diagnostics in case the CITY must be put out of use for safety reasons until maintenance can be performed.
-
Page 11: Specifications & Precautions
Do not operate the CITY while on a moving vehicle such as a bus. Do not lean your body to reach out of the CITY, causing a balance issue. Do not exceed the weight limit total of 180 kg (395 lbs.) for rider plus any items. - Page 12 CITY Model Version 1.0 1-888-56-BUGGY contact@thetravelbuggy.com...
