Summary of Contents for The Travel Buggy City Lite
- Page 1 CITY LITE Model Operating Manual 1-888-56-BUGGY contact@thetravelbuggy.com The Travel Buggy 1.888.56.BUGGY CITY LITE Model V1...
-
Page 2: Table Of Contents
Electromagnetic Interference (EMI) ......................8 Setup ................................9 Controller ..............................11 Basic Operation ............................12 Charging Batteries ............................13 Free Wheel Mode ............................15 Transporting Your City Lite ......................... 16 Troubleshooting ............................17 Diagnostics ..............................18 Limited Warranty ............................19 The Travel Buggy 1.888.56.BUGGY... -
Page 3: Introduction
It is important to read through this manual before operating your CITY LITE to become familiar with its features as well as its limitations and safety information. You will find the operation and care of your CITY LITE very simple and easy, but should you have any questions please contact us at The Travel Buggy at our customer hotline, 1.888.56.BUGGY or by email contact@thetravelbuggy.com. -
Page 4: Specifications
89 x 61 x 94 cm Unfolded (Lx W x H ): (35 x 24 x 37 inches) 61 x 33 x 78.75 cm Folded (L x W x H ): (24 x 13 x 31 inches) The Travel Buggy 1.888.56.BUGGY CITY LITE Model V1... -
Page 5: Specification Diagram
Specification Diagram The Travel Buggy 1.888.56.BUGGY CITY LITE Model V1... -
Page 6: Safe Operation
Safe Operation We think this is the most important section of the manual; how to safely operate the CITY LITE portable wheelchair. Please review this section thoroughly and contact us if you have any questions. General Safety… Adjust the CITY LITE to your personal comfort level as much as possible. -
Page 7: Precautions
When transporting the CITY LITE… Never sit in the CITY LITE while in a moving vehicle; an accident or sudden stop may cause you to be thrown from the power chair. Never transport the CITY LITE in the front seat of a vehicle where it may shift and interfere with the driver. -
Page 8: Maintenance
Please be sure to keep a log of the service and maintenance performed. Your shop or technician may require parts, which The Travel Buggy has available. We recommend you inspect your CITY LITE two to three times per year for in the following areas: ... -
Page 9: Setup
CITY LITE for the first time. 1. The CITY LITE ships upright; carefully open the top of the box then turn the box on the side for easier removal of the contents. - Page 10 NOT force the wire harness connections together or you will bend or break the pins. Connect CPU to Controller wire harness 8. Connect battery harness located near the rear wheel of the CITY LITE. The Travel Buggy 1.888.56.BUGGY CITY LITE Model V1...
-
Page 11: Controller
To stop, just bring the joystick back to the initial position. Use extra care when you drive the CITY LITE in reverse. You may lose control or fall if one of the rear wheels hits an object. When operating in reverse: ... -
Page 12: Basic Operation
Operate only in the appropriate environment after you have practiced operating the CITY LITE and know how to work the controller. Be certain that the power is OFF before sitting in the seat of your CITY LITE, with no GET IN lights on the controller. -
Page 13: Charging Batteries
Charging Batteries Your CITY LITE will arrive with a fully charged battery, which should last a maximum of 20 km or 12 miles under normal operating conditions. A second battery can be purchased by contacting The Travel Buggy, which will extend the run time. We recommend that you run the CITY LITE until the battery is completely dead in order to get the most out of the battery life. - Page 14 If the battery needs to be disposed of, locate the nearest hazardous materials disposal facility, and call them for instructions. ● The CITY LITE is equipped with one lithium battery and will go up to approximately 20 km or 12 miles. This maximum operating time per charge can be affected by: ○...
-
Page 15: Free Wheel Mode
OFF the power to the CITY LITE when in this mode, both for safety and to save battery power. 1. To put the CITY LITE in Free Wheel Mode, come to a full stop and turn OFF the power on the controller. -
Page 16: Transporting Your City Lite
NOTE: Never transport the CITY LITE in a tie down system, as the CITY LITE is not compatible with them. Never sit in the CITY LITE and be transported in a moving vehicle. Do not place the folded CITY LITE in the front seat with the driver where it could move or slide. -
Page 17: Troubleshooting
Troubleshooting The following represents the most common questions asked about the CITY LITE with regard to everyday use; check this helpful guide or the operator’s manual for more information if you have a question about using your CITY LITE: Question... -
Page 18: Diagnostics
CITY LITE may use to indicate problems. It is important to pay attention to these diagnostics in case the CITY LITE must be put out of use for safety reasons until maintenance can be performed. -
Page 19: Limited Warranty
Limited Warranty The purchaser of this product is entitled to a limited warranty as offered by The Travel Buggy and its affiliates on the following components and timeframes: ● Frame - 5 Years ● Motor - 2 years ● Battery - 1 year ●...
