3.1 PRIOR TO SETUP

1. Insure all structural members of the hoist are free of defects and damage that may affect the integrity of the unit.
2. Insure the hoisting area is secured from all unauthorized personnel.
WARNING:
INSURE THAT OSHA COMPLIANT FALL PROTECTION IS IN PLACE.
WARNING:
PRIOR TO SETTING UP THE HOIST THERE MUST BE A PLAN OF ACTION OUTLINING
THE WORK TO BE ACCOMPLISHED, INDIVIDUAL RESPONSIBILITIES, PERSONAL
PROTECTIVE EQUIPMENT, AND THE METHOD OF COMMUNICATION. FAILURE TO DO
THIS CAN RESULT IN DEATH, SERIOUS PERSONAL INJURY OR EQUIPMENT FAILURE.
WARNING:
INSURE THAT ALL BOLTS AND NUTS ARE TIGHTENED SECURELY TO PREVENT
EQUIPMENT DAMAGE AND/OR SERIOUS INJURY.

3.2 COMPLETING THE PLATFORM ASSEMBLY

1. Your PRO400 Platform Lift has an optional unload feature that can be easily added by the installation of the sixteen
2" diameter wheels (#19) using the mounting hardware included in P/N 0401450 Platform Wheel Bag Of Bolts.
2. Refer to Figure 3-1 (Wheel placement Guide) for correct placement of wheels on platform frame (#17) and pivot
bracket (#7).
3. Making sure that all locknuts are facing the inside of the frame members, securely tighten all sixteen 1/4 x 1-1/2"
long hex head bolts.
4. FAILURE TO FOLLOW WHEEL PLACEMENT GUIDE MAY CAUSE DAMAGE TO THE MATERIAL BEING
LIFTED.
5. If the optional equipment PRO400 Roller Angle Guide is to be used then the platform wheels MUST be installed to
allow for proper operation of Roller Angle Guide and automatic off load feature of your PRO400 Platform Lift.
