OPTION: Digital I/O and Pulse Counters

1

OVERVIEW

The PC-Logger 3150 can, in addition to the analog inputs, be fitted with a
digital I/O-interface.
This digital board is mainly used in event-counting applications but can also be
used where status or on/off signals must be detected.
The relay outputs of the PC-Logger 3150 are not supported by existing
software.
This card is available in two versions: with or without counters.
A fully equipped card has the following I/O's:
counters.
1.1

Digital Outputs

Four digital outputs in the form of (relay) contact closures are available. They
find their use as alarms and in simple regulating functions and, in the case of
the "f", are as such not supported by the software.
The relay coils are, to prolong battery life, powered directly by the mains
adapter and not by the internal batteries.
- 4 digital outputs (relays)
- 8 digital inputs, 6 of which can be used as inputs to the
