SONANCE VISUAL PERFORMANCE
Painting The Grilles
Visual Performance speaker grilles completely cover the speaker
frame, so only the grilles (not the speakers themselves) require
painting. The speakers are fitted with paint plugs to protect them
if the ceiling is painted after the speakers are installed.
To paint the grilles, first remove the scrim cloth that is attached
to the backs of the grilles. (The adhesive that holds the cloth in
place is reusable.) Paint the grilles with very thin paint (5 parts
thinner to 1 part paint), being careful not to plug the holes.
When the paint has fully dried, re-attach the scrim cloths to the
backs of the grilles and re-install the grilles on the speakers.
Speaker Adjustments
Pivoting Woofer and Midrange/Tweeter
All Visual Performance Series 8" in-ceiling speakers have a
pivoting woofer and a pivoting midrange/tweeter assembly. If
you're using the speakers in stereo or as the front left/center/
right speakers in a home theater, pivot the drivers directly
towards the listening area. If you're using the speakers as
surround channel speakers in a home theater, pivot the drivers
towards a wall or window, away from the listeners.
To pivot the midrange/tweeter assembly, apply light pressure to
the ring around the outside edge of the midrange cone, as shown
in Figure 7 , left. Take care not to touch or apply pressure to the
midrange cone itself. To Pivot the woofer, apply pressure on the
outer edge of one of the tweeter support brackets, as shown in
Figure 7, right. Do not touch or apply pressure to the woofer cone.
F
7: P
M
IGURE
IVOTING THE
AND THE
Tweeter and Midrange Level Switches
The VP89R and VP87R have midrange and tweeter level switches
(see Figure 8 )
that boost or
cut those driv-
ers' levels by
3dB. This lets
you tailor the
speaker's per-
formance
to
better
match
the
room's
acoustics
or
the
listener's
F
IGURE
preferences.
®
8" IN-CEILING
/T
A
IDRANGE
WEETER
SSEMBLY
W
(
)
OOFER
RIGHT
Midrange Level
Tweeter Level
Switch
Switch
8: M
T
IDRANGE AND
WEETER
L
S
EVEL
WITCHES
Specifications
VP89R
Tweeter:
Midrange:
Woofer:
Frequency Response:
Impedance:
Power Handling:
Sensitivity:
Grille Material:
Adjustments:
Dimensions (Dia. x D):
Cutout Dimensions (Dia):
Shipping Weight:
VP87R
Tweeter:
Midrange:
Woofer:
Frequency Response:
Impedance:
Power Handling:
Sensitivity:
Grille Material:
Adjustments:
Dimensions (Dia. x D):
Cutout Dimensions (Dia):
Shipping Weight:
VP85R/VP85S
Tweeter:
Midrange:
Woofer:
(
)
LEFT
Frequency Response:
Impedance:
Power Handling:
Sensitivity:
Grille Material:
Dimensions
VP85R (Dia. x D):
VP85S (H x W x D):
Cutout Dimensions
VP85R (Dia):
VP85S (W x H):
Shipping Weight:
1" (25mm) Ber yllium dome, Ferrofluid-
cooled, pivoting
4" (102mm) Ber yllium cone with a rubber
surround, pivoting
8" (203mm) Beryllium cone with a rubber
surround, pivoting
30Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum; 175 watts maximum
91dB SPL (2.83V/1 meter)
Per forated steel
Tweeter and midrange level (±3dB)
11
5
" x 5
7
" (295mm x 149mm)
/
/
8
8
1
10
/
" (257mm)
8
22 lbs (10.0kg) pair
1" (25mm) Aluminum dome, Ferrofluid-
cooled, pivoting
4" (102mm) Coated carbon giber cone with
a rubber surround, pivoting
8" (203mm) Coated carbon fiber cone with a
rubber surround, pivoting
31Hz – 20kHz ±3dB
6 ohms nominal; 4 ohms minimum
5 watts minimum; 165 watts maximum
91dB SPL (2.83V/1 meter)
Per forated steel
Tweeter and midrange level (±3dB)
11
5
" x 5
7
" (295mm x 149mm)
/
/
8
8
10
1
/
" (257mm)
8
22 lbs (10.0kg) pair
1" (25mm) Silk dome, Ferrofluid-cooled,
pivoting
4" (102mm) Carbon fiber cone with a rubber
surround, pivoting
8" (203mm) Carbon fiber cone with a
rubber surround, pivoting
36Hz – 20kHz ±3dB
8 ohms nominal; 6 ohms minimum
5 watts minimum; 140 watts maximum
91dB SPL (2.83V/1 meter)
Per forated Steel
11
5
" x 5
7
" (295mm x 149mm)
/
/
8
8
11¼" x 11¼" x 6"
(286mm x 186mm x 152mm)
1
10
/
" (257mm)
8
10
1
/
" x 10
1
/
" (257mm x 257mm)
8
8
20 lbs (9.0kg) pair
3
