Spear & Jackson S4042X2CR Original Instruction Manual

40v 42cm cordless mower with 2 batteries
Hide thumbs

Advertisement

Table of Contents

40V
42CM CORDLESS
MOWER WITH
2 BATTERIES
S4042X2CR
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled
correctly and safely. If you need help or have any missing parts
call After Sales Support on 0345 605 2068
ORIGINAL
INSTRUCTION
MANUAL
AFTER SALES SUPPORT
0345 605 2068

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S4042X2CR and is the answer not in the manual?

Questions and answers

MUSTAFA KEMAL YAHYA
May 17, 2025

I purchased what I thought to be a like for like lawn mower S4042XCR The batteries of my old machine are too big Can I buy new batteries and a charger

0

Related Manuals for Spear & Jackson S4042X2CR

Summary of Contents for Spear & Jackson S4042X2CR

  • Page 1 ORIGINAL INSTRUCTION MANUAL 42CM CORDLESS MOWER WITH 2 BATTERIES S4042X2CR Important - Please read these instructions fully before starting assembly AFTER SALES SUPPORT 0345 605 2068 These instructions contain important information that will help you get the best from your mower, ensuring it is assembled correctly and safely.
  • Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance, comfort and durability firmly in mind, which has earned Spear &...

  • Page 3: Table Of Contents

    CONTENTS Warning Symbols ........................4 General Safety Information....................... 6 Specific Safety Information ....................12 Battery Safety Information ....................... 12 Charger Safety Information ......................14 In the Box ............................17 Parts ..............................17 Assembly ........................... 18 Preparation ..........................21 Operation ..........................24 Maintenance ..........................

  • Page 4: Warning Symbols

    WARNING SYMBOLS The following warning symbols appear throughout this manual and on the product. They indicate the appropriate safety measures you should take when assembling and operating the machine. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
  • Page 5 WARNING SYMBOLS CAUTION: Indicates a Do not subject the battery to direct potentially hazardous sunlight over long situation, which, if not periods and do not avoided, may result leave it on or near a in minor or moderate heat source (max. injury.

  • Page 6: General Safety Information

    GENERAL SAFETY INFORMATION responsible for safety or are IMPORTANT! being instructed to operate When using equipment, the the appliance by such a following safety precautions person. Children should be must be followed to avoid supervised to ensure that injuries and damage: they do not play with the appliance.
  • Page 7 GENERAL SAFETY INFORMATION • Keep in mind that the • Operate the mower only in operator or user is daylight or in good artificial responsible for accidents light. or hazards occurring • Do not use the lawn to other people or their mower in damp or wet property.
  • Page 8 GENERAL SAFETY INFORMATION crossing surfaces other near or under rotating than grass, and when parts. Keep clear of the transporting the machine discharge opening at all to and from areas to be times. mowed. • Never pick up or carry the •...
  • Page 9 GENERAL SAFETY INFORMATION − After striking a foreign mower if you are falling. object. Inspect the Release the handle mower for damage and immediately. make repairs before • Do not use the mower for restarting and operating any job except that for the mower.
  • Page 10 GENERAL SAFETY INFORMATION frequently for wear or is not installed when the deterioration. mower is not in use. This prevents accidental starting • Be careful during of the machine. adjustment of the mower to prevent entrapment of • Replace worn or damaged fingers between moving parts for safety.
  • Page 11 GENERAL SAFETY INFORMATION from vibration emission if the machine is being used over long periods of time or not adequately managed and properly maintained. - Injuries and damage to property due to broken application tools or sudden impact of hidden objects during use.

  • Page 12: Specific Safety Information

    SPECIFIC SAFETY INFOMRATION BATTERY SAFETY INFOMRATION from the machine while not in operation. This will reduce CAUTION the risk of electric shock, fire Use only Spear & Jackson or serious personal injury. ® approved replacement • Do not place appliances or batteries;...
  • Page 13 SPECIFIC SAFETY INFOMRATION reduce the risk of electric assistance in the event of shock. discomfort. • For best results, your battery • Always remove battery tool should be charged pack from your tool when in a location where the you are assembling parts, temperature is more than making adjustments, 4°C but less than 40°C.

  • Page 14: Charger Safety Information

    SPECIFIC SAFETY INFOMRATION CHARGER SAFTEY INFORMATION battery packs other than those supplied. CAUTION The charger and battery Use only Spear & Jackson ® pack supplied with it are approved replacement specifically designed to batteries; other batteries may work together. cause injury or damage to •...
  • Page 15 SPECIFIC SAFETY INFOMRATION during the charging process the charger rating plate could pose a fire hazard. must correspond to the voltage of the power • Do not abuse the cord of source. the charger. Never use the cord for carrying, pulling or •...
  • Page 16 SPECIFIC SAFETY INFOMRATION INTENDED USE given supervision or instruction concerning use This lawn mower is designed of the charger by a person for domestic use only: responsible for their safety. • This cordless lawnmower • Children should be is intended for mowing supervised to ensure that lawns in domestic and they do not play with the...

  • Page 17: In The Box

    IN THE BOX PARTS Upper handle Upper Cover of Rear Wheel Cable Clip Grass Collection Bag Switch Lever Front Wheel Safety Button Deflector Guard Quick Release Lever Deck Charger Lower Cover of (x4) Battery Battery (x2) Grass Collection Bag Cable Guide Compartment Cover Mulching Plug Carry Handle...

  • Page 18: Assembly

    ASSEMBLY Unpacking i. Unpack all parts and lay them on a flat, stable surface. ii. Remove all packing materials and shipping devices if applicable. iii. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact the after sales helpline within 28 days of purchase.
  • Page 19 ASSEMBLY Fix the upper handle Fit the upper handle and lower handle together with the quick release levers. Before fitting the quick lever, check and ensure the cable guide is attached on the upper handle. If not, attach the cable guide on the upper handle as shown. Ensure the hole on the cable guide is aligned with the hole on the upper handle.
  • Page 20 ASSEMBLY Assemble the grass collection bag i. Insert the handle in the slots on the upper cover of grass collection bag. Ensure this securely ‘clicks’ into place. ii. Secure the metal support rods into the fixing position on either side of the grass collection base. Ensure the side clamping sleeves are properly fixed onto the metal support frame.

  • Page 21: Preparation

    PREPARATION Check battery capacity Push and hold the power indicator located on the battery pack to show the remaining battery capacity. The battery is equipped with a charge-level indicator panel which indicates its current charge condition. This charge-level indicator panel consists of 4 LEDs.
  • Page 22 PREPARATION iii. The indicator lights on the charger show the charger status: Symbol Indicator lights Status Charging paused Red, see instructions flashing below. Red, Connected to continuous power supply Green, Charging flashing Green, Fully charged continuous The intelligent charger measures the charge level of the battery and charges the battery accordingly with the required current and voltage based on battery temperature and voltage.
  • Page 23 PREPARATION Continuous runtime i. This lawn mower is supplied with two battery packs for your convenience and to increase the run time during operation providing an almost unlimited run time to cut over 1200m . To utilise the continuous runtime feature, ensure both batteries are fully charged before first operation.

  • Page 24: Operation

    OPERATION Setting the cutting heights IMPORTANT! Set the cutting height only when the motor is switched off and the battery pack has been removed. Stop the machine, release the switch lever, remove the isolator key and wait until the blade stops before adjusting the cutting height.
  • Page 25 OPERATION Switching on i. Press and hold the safety button (1). ii. Pull the switch lever towards the handle and hold in position (2). iii. Release the safety button. Switching off Release the switch lever. Grass collection full indicator i. If the grass collection bag is empty or it is not full with grass, the grass full indicator flap will remain open.
  • Page 26 OPERATION Battery indicator panel • A battery indicator panel is located on the switch box, and can be used to indicate the current battery status. Battery • Push the indicator button to check the battery status, 4 indicator lights indicate a fully charged battery, 1 light indicates the Mode indicator battery needs to be charged.
  • Page 27 OPERATION Using as a mulcher Do not attach the grass collection bag and the mulching plug at the same time. The mulching plug allows the grass clippings to be deposited back on the lawn during cutting. To install the mulching plug: i.

  • Page 28: Maintenance

    MAINTENANCE WARNING! Always switch the product off, remove the battery pack and isolator key and let the product cool down before performing inspection, maintenance and cleaning work! i. Keep the underbody and cutting blade clean and free of debris. Remove clippings from the discharge chute. ii.
  • Page 29 MAINTENANCE Storage WARNING! To avoid damage to the cable, ensure thepower cable is not caught between the folding sections. i. Switch the product off and remove the battery and isolator key. ii. Clean the product as described in the above maintenance section.

  • Page 30: Technical Data

    TECHNICAL DATA Model S4042X2CR Max Voltage No load speed 3100-3300-3500 /min Cutting width 42cm Height of cut 22/32/42/52/62/72mm Grass collector capacity Net weight 15.4Kg Charger Model no. 40LFC01 Charger input 220-240V 50/60Hz 145W Charger output 3.0A Charging period (battery fully discharged)
  • Page 31 TECHNICAL DATA Sound values Sound pressure level L : 82dB(A) Sound power level L : 92.6dB(A) Uncertainty K: 2.12dB(A) Guaranteed sound power level L : 96dB(A) Vibration values Hand arm vibration a : 2.5m/s² The sound values have been determined according to noise test code given in EN 60335-2-77, using the basic standards EN ISO 11201 and EN ISO 3744.

  • Page 32: Troubleshooting

    TROUBLESHOOTING Suspected malfunctions are often due to causes that the user can fix by themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by a qualified specialist.
  • Page 33 TROUBLESHOOTING Fault Possible Cause Solution Increase the height of cut and Height of cut is too low. walk slower. Increase the height of cut and The grass is too high. walk slower. Area of cut (battery duration) is not large enough. Wait until the grass is dry and The grass is wet or damp.

  • Page 34: Guarantee

    GUARANTEE If your device develops a fault, please don’t hesitate to contact our after sales support on 0345 605 2068, the majority of problems can be solved directly on the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights.
