SPSDEVK1-PCB: User Manual
Introduction;
The SPSDEVK1 Predictive Maintenance Turnkey Solution kit enables
fast installation of full Smart Passive Sensor
This evaluation kit includes:
•
1 SPSDEVR1-8
•
1 SPS1DEVA1-W
A 12V DC power supply is suggested and recommended
for use with the SPSDEVR1-8.
Software Tools
ON Semiconductor has developed a web based application specifically
for reading Smart Passive Sensors that unlocks the full functionality of
the tags. This application utilizes a REST API that includes advanced
reader settings, graphing/logging of sensor data, and a Certification mode.
© Semiconductor Components Industries, LLC, 2015
September 2018- Rev. P0
NON-CONTROLLED, PRE-PUBLICATION COPY – PROPRIETARY, NOT FOR DISTRIBUTION TO CUSTOMERS
TM
systems.
UHF SPS Reader
UHF Antenna
Figure 1. SPSDEVK1 Hardware Setup
1
www.onsemi.com
Publication Order Number:
XXXXXEVBUM/D
