1 Safety
Special safety symbols
Some special symbols represent particular types of danger:
Order number
The cart symbol
Handling instructions
• Handling instructions are given in the form of bullet points. Handling sequences where a particular order must be followed
are given in the form of a numbered list.
1.3

Avoid danger

The ROTEX E-SolarUnit is state-of-the-art and is built to meet all recognised technical requirements. However, improper use can
lead to serious injuries or death, as well as cause material damage.
To avoid such risks, only install and operate the ROTEX E-SolarUnit:
– as stipulated and in perfect condition,
– with an awareness of the safety and hazards involved.
This assumes knowledge and use of the contents of this manual, the relevant accident prevention regulations and the recognised
safety-related and occupational medical rules.
1.4

Proper use

The ROTEX E-SolarUnit must only be used as a hot water heating system. The ROTEX E-SolarUnit must be set up, connected and
operated in accordance with the stipulations contained in these instructions.
Any other use outside the above-mentioned use is considered as improper. Any resulting damages will be borne by the user/owner
alone.
Proper use also includes observing the relevant maintenance and servicing conditions. Spare parts must at least satisfy the
technical requirements defined by the manufacturer. This is the case, for example, with original spare parts.
1.5

Instructions for operating safety

Before starting up the heating system
• Only authorised and trained heating engineers should work on the heating system (e. g. installation, connection and initial
start-up).
• When carrying out any work on the heating system, switch off the main switch and secure it against being switched on
unintentionally.
• Seals must not be damaged or removed.
Electrical installation
• Electrical installations may only be carried out by qualified electrical technicians under observance of the relevant electrical
guidelines and the regulations of the electric utilities company.
• Compare the mains voltage (400 V, 50 Hz 3-phase current) indicated on the type plate with the supply voltage before
connecting to the mains.
Open or closed heating system
• Install the heating system as an open or closed system in accordance with the safety-related requirements of EN 12828.
• Note that the safety valves must comply with DIN EN ISO 4126-1 and be type tested. They must be installed in the
safety flow.
6
Danger of explosion
indicates information on order numbers.
Results of actions are identified with an arrow.
Electrical current Danger of burning or scalding
