Page 3 Have a great read, and many outstanding hours flying USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 4 2. Download FreeFlight 6 on your iOS or Android smartphone: requires FreeFlight 6 to fly. The app will enable you to update Parrot Skycontroller 3 and when you power them on for the first time. Android QR code...
Page 5 4. When updates are done, the screen displays “Your drone is ready” and a “CONTINUE” box. Tap this “CONTINUE” box to come back to FreeFlight 6 homepage. 5. All systems are ready for flight! USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 6: Table Of Contents
Regulations ............................15 Flight conditions..........................15 ............................16 ..............................17 Ground take-off ..........................17 Hand take-off ............................. 17 ..............................18 ............................19 ..............................19 ............................. 20 Battery removal ..........................20 Battery installation ..........................21 USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 7 White balance (WB) ........................... 35 Style ..............................35 ..............................35 360° ..............................35 Reveal ..............................35 Rise ..............................35 Epic..............................36 ............................36 Cameraman ............................36 SmartDronies ............................. 36 Touch & Fly ............................36 USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 8: About 4K Video Formats
’s 4K videos into a more manageable format (like 1080p) if they do not read properly on your equipment. This is especially true for Parrot’s 4K Cinema format, which can only be handled by professional editing equipment. About the smart battery ’s smart battery is preinstalled on your drone.
Page 9 PERSONAL INJURY, OR BOTH, which could result in serious harm or death. 3. Be aware that videos and photos that are promoted and advertised by Parrot Drones SAS and its affiliates have been made by and with experienced professionals and drone pilots.
Page 10 - Max transmission range: 4km - Live streaming resolution: HD 720p - Battery capacity: 2,500mAh 3.6V - Supported mobile devices: screen size up to 6.2’’ - USB ports: USB-C (charge), USB-A (connection) USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 11 16GB microSD card, preinstalled in a microSD to SD card adapter a Parrot Skycontroller 3 8 spare propeller blades a mounting tool a Flight Safety Guide a Super Quick Start Guide (SQSG) a Wi-Fi settings card USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 12: Ready To Store Or Carry
© Parrot, June 2018 Ready to store or carry Foldable arms and propellers Ready to fly Charge level LED indicators Power button Smart battery Battery extraction button USB-C charging port 180° tilt 4K camera gimbal USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 13: Ready To Store Or Carry
© Parrot, June 2018 Ready to store or carry Left control stick Right control stick Power-on foldable arm and device holder Ready to pilot LED status indicator Wi-Fi antenna RTH (return home) button Take-off/landing button USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 14: Camera And Gimbal Controls
Tilt trigger Zoom trigger (down: tilt (down: zoom in; down; up: zoom out) up: tilt up) Charging light USB-C charging port (red: charging; green: charged) USB-A device port USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 15: Equipment
14 meters per second or 50 km/h. Due to the operating mode of its vertical camera and ultrasound sensor, Parrot recommends you do not fly over water and other reflective surfaces (mirrors, glass, and so on).
Page 16 Wi-Fi settings card located inside the drone’s carrying case - SSID format: Anafi-xxxxx. If you use Parrot Skycontroller 3, unfold the central part of the controller to power it on, wait for the steady dark blue light, then plug your device to the controller using a USB cable.
Page 17: Ground Take-Off
Position on a flat, even, and clear surface. Press the [TO/land icon] button on your Parrot Skycontroller 3, or tap the green “TAKE-OFF” box, on the screen of your device. takes off and stabilizes at 1 meter from the ground, waiting for commands from the pilot.
Page 18 © Parrot, June 2018 Left control stick (default mode) Right control stick (default mode) Rise Forward Descend Reverse Turn right Move to the right Turn left Move to the left USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 19 [RTH icon] button on your Parrot Skycontroller 3, or tap the [RTH icon] icon on the screen of your device. rises to 20 meters over its take-off point – if it was flying lower than this altitude –...
Page 20: Battery Removal
Gently slide your thumb and the battery toward the back of . When the hook of the push-button is disengaged from the body of the drone, lift the battery away from : battery removal USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 21: Battery Installation
50 and 75% charged; LEDs 1, 2 and 3 steady & LED 4 flashing: battery is between 75 and 100% charged; battery is plugged and all LEDs are off: battery is full. USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 22: Battery Care And Safety
20°C; always carry your battery in a fire-retardant bag or case (unless it is installed on : it can then be transported with the drone, inside its carrying case). USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 23: Extracting The Microsd Card
/!\ The enclosed 16GB microSD card enables you to record just over 20 minutes of 4K video. For this reason, Parrot recommends you backup your photos and videos, and you empty your 16GB microSD card after each flight, to ensure you always have available memory space to capture new still or moving images.
Page 24 HUD (iOS and Android). Access the HUD by taping “FLY” on the bottom right of the homepage of FreeFlight 6. iOS FreeFlight 6 homepage Android FreeFlight 6 homepage USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 25: Presentation Of The Ios Hud (Video Mode View)
Reveal (30 & 60m) Follow Me (in-app purchase) Rise (30 & 60m) Smartdronies Epic (30 & 60m) Touch & Fly Flight Plan (in-app purchase) Video modes: Standard Cinema Hyperlapse High-Framerate Slow Motion USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 26: Presentation Of The Android Hud (Photo Mode View)
GPS and Glonass satellites to optimize the stability of the drone, especially at higher altitudes. Parrot therefore recommends you always check both your FreeFlight 6 HUD’s GPS icons are green (and not red), before you make your take off.
Page 27 NO / YES Tap “RESET ALL INTERFACE PREFERENCES” on the bottom of the page to reset preferences. Piloting Piloting preferences set the way ANAFI behaves, in each individual speed mode. Tap “FILM” – “SPORT” bold & italic default values in bold – or –...
Page 28 ’s Wi-Fi network name, password, and band. Network’s name Tap the field to change your ’s network name Password Tap the box to change your network’s password Wi-Fi band ALL / 2.4 GHz / 5 GHz / MANUAL USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 29: Making Videos
4K or 1080p filming, at 24, 25 or 30fps. Cinema: spectacular 4K cinema filming at 24fps only. Hyperlapse: accelerated rendering 4K or 1080p filming, at 24, 25 or 30fps. Slow-Motion High-Framerate: slow-motion rendering 1080p filming, at 48, 50 or 60fps. USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 30 Standard video format menu When you are happy with your settings and your framing, press the hard shutter button on the right of the Parrot Skycontroller 3 (or tap the soft shutter button of the HUD) to start filming.
Page 31: Taking Photos
JPEG formats – which are compressed and processed renderings of this comprehensive information. In consequence, RAW pictures such as ’s DNG are heavy files, but they offer the very best post-processing and retouching possibilities. USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 32 Android photo formats: DNG+JPEG When you are happy with your settings and your framing, press the hard shutter button on the right of the Parrot Skycontroller 3 (or tap the soft shutter button of the HUD) to take a photo.
Page 33: Gimbal Tilt Control
To aim the gimbal toward the sky, pull the tilt control trigger up. To reset the gimbal tilt to a horizontal position, press the optics reset button on the left of Parrot Skycontroller 3 (this action also resets the zoom factor of the lens to x1). Zoom control ’s zoom control is activated through the right trigger of Parrot Skycontroller 3.
Page 34 4K UHD (x1.4) and 1080p (X2.8) videos. Note that when you leave the lossless envelope of the zoom, the zoom indicator, on the middle left of the HUD, turns orange instead of white. USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 35: Exposure Value (Ev)
On iPhones, the 360° box progressively fills with green as the Cineshot unfolds. Rise The 360° Cineshot is self-explanatory: when activated, rotates slowly and completely around its axis to uncover a full panorama. USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 36: Epic
On iPhones, the 360° box progressively fills with green as the Cineshot unfolds. Cameraman SmartDronies Touch & Fly For questions, comments, or feedback about v0.9.2 of ’s user guide, reach out to technical.writer@parrot.com USER GUIDE v0.9.2 – send feedback to technical.writer©parrot.com...
Page 37 (2) the user of the device must accept any radio interference encountered, even if the interference is likely to compromise operations. The Anafi and the Parrot Skycontroller 3 are category B digital devices and are compliant with the NMB-003 standard of Canada. A minimum distance of 80 mm between the user's hands and the antenna must be kept in order to comply with IC SAR requirement.
