- Page 1 50LPM QUIET INFLATOR Quiet portable infl ator for general light duty tasks around the home MODEL NO. BRS50 For service, spare parts or product information, please contact Smart Marketing Group Pty. Ltd. Recyclable AUST. 1300 660 457 N.Z. 0800 474 876...
-
Page 2: Table Of Contents
SUGGESTED APPLICATIONS CONTENTS You may use most light duty air tools with this infl ator. Some Section Page examples of light duty tools are: • Ball Infl ator Contents • Toy Infl ator Suggested Applications • Tyre Infl ator Introduction •... -
Page 3: Introduction
What is covered. INTRODUCTION • Manufacturing fault or defect. Dear Customer, How to claim under this warranty. Thank you for purchasing this infl ator which has passed through our extensive quality assurance processes. Every • Call customer service, phone number at the top. care has been taken to ensure that it reaches you in perfect •... -
Page 4: Guarantee
COMPLETE WARRANTY STATEMENT – INFLATOR GROUP As soon as you have purchased the infl ator, we recommend Rust and corrosion are not covered under this warranty. that you check to make sure it is intact and that you read If a warranty fault is found the freight cost will be credited to the operating instructions carefully before using it. - Page 5 LUBRICATION OF INFLATOR WORK AREA This infl ator is OIL FREE. Therefore there is NO oil used for Work areas and benches should be kept tidy. Cluttered lubrication. benches and work areas can cause accidents. Floors should be kept clean and free from rubbish. Special care should be taken when the fl...
- Page 6 DO NOT ABUSE THE POWER CORD REMOVE ADJUSTING KEYS AND WRENCHES Never yank or pull on the power cord to disconnect it from the mains supply socket. Never carry or pull your infl ator Form the habit of always checking to see that any adjusting by its power cord.
- Page 7 CHECK DAMAGED PARTS PERSONAL SAFETY Clothing Before using the infl ator it should be carefully checked to determine that it will operate properly and perform its Do not wear loose clothing, jewellery or anything that could intended function. get caught in moving machinery. Check for the correct alignment of moving parts ensuring Hair that they do not bind.
- Page 8 IMPORTANT ELECTRICAL DATA This infl ator is fi tted with a sealed electrical connection plug that is compatible with the mains power supply for Australia / New Zealand and meets the requirements of Australian Standards. This infl ator must be connected to a supply voltage that is equal to that stated on the rating label.
-
Page 9: Components And Controls
PIC. 1 COMPONENTS AND CONTROLS Pic. 1 1. Pressure switch 2. On / Off button - red colour 3. Handle 4. Outlet pressure regulator 5. Pump 6. Tank 7. Rubber feet 8. Tank drain tap 9. Tank pressure gauge 10. Air fi lter 11. -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS PIC. 2 Unpacking Carefully unpack your infl ator. Dispose of all packing material in an environmentally responsible manner. Assembly Your infl ator requires minor assembly before initial operation. Check that you have all required components required for assembly and initial use. Rubber Stopper To attach the rubber stopper to the bracket located on the bottom of the tank;... - Page 11 STARTING AND STOPPING YOUR INFLATOR PIC. 5 Pic. 4 NOTE: Always ensure that you plug your infl ator into a Lift button Push button standard 240V AC power point. Never use an extension cord up for on down for off as this can lead to a voltage drop which may cause power loss and over heating.
- Page 12 USING THE INFLATOR TOOL CONFIGURATION The confi guration of tools and accessories can be varied to Before starting run through this simple list; suit your particular requirements. A basic recommended set Fully assembled. up is shown in Pic. 6 (accessories not included). Drain tap –...
-
Page 13: Maintenance
ADJUSTING THE PRESSURE PIC. 8 To adjust the outlet air pressure, use the red coloured regulator knob and check the pressure on the outlet pressure gauge, Pic. 7. If the pressure needs to be lower, Pull to check turn anti clockwise. operation If the pressure needs to be higher, turn clockwise. -
Page 14: Trouble Shooting
REPAIRS Repairs to your infl ator should only be carried out by an authorised service agent. Call BLACKRIDGE for your closest centre, Aust. Aust. 1300 660 457 N.Z. 0800 474 876. TROUBLE SHOOTING Infl ator will not start Check that you have plugged the power lead into a standard 240V 10Amp PIC. - Page 15 Part Description SMG Part No. Part Description SMG Part No. Air fi lter 95 BRS50AF One Way Valve 95 BRC95OWV Air fi lter tube 95 BRS50AFT Rubber Handle Grip 95 BRS50TH Exhaust Elbow 95 BRS50ET Drain Tap 95 BRC95DT Safety valve 95 BRC95SPV Cushion Foot, Nut, Washer &...
-
