- Page 1 INSTRUCTION MANUAL 1HP AIR INFLATOR MODEL NO. BR500 - PLU: 590729 1HP Direct drive motor 8 Litre tank size Includes Nitto style fitting L/MIN TANK CAPACITY FREE AIR DELIVERY 8 BAR PRESSURE WARRANTY NO REGULATOR...
-
Page 2: Technical Information
MOTOR / PUMP KICKS IN 85 PSI PRESSURE CYCLE STOPS For service, spare parts or product information, 115 PSI please contact: SMART MARKETING GROUP PTY. LTD. NUMBER OF OUTLETS AUSTRALIA: 1300 660 457 NEW ZEALAND: 0800 474 876 BLACKRIDGE 1HP AIR INFLATOR... - Page 3 1HP AIR INFLATOR MODEL NO. BR500 KNOW YOUR INFLATOR 1. Carry Handle 6. Rubber Stopper 2. On/Off Button 7. Tank Drain Tap (red colour) 3. Pressure Switch 8. Tank 4. Tank Pressure Gauge 9. Air Filter 5. Safety Valve 10. Air outlet fitting Nitto style...
-
Page 4: Pre Setup Checks
For this air inflator, the handle is already assembled. Air Filter Carefully screw supplied air filter into the threaded hole on the top of the pump head. This only needs to be done up by hand. Pic. 1. BLACKRIDGE 1HP AIR INFLATOR... -
Page 5: You're In Control
Lift up the red ON / OFF button on top of the pressure switch. Pic 2. To turn your air inflator OFF Push down the red ON / OFF button on top of the pressure switch. Pic 3. BLACKRIDGE 1HP AIR INFLATOR... -
Page 6: Using Your Product
6. Slowly open the tank drain tap. This allows excess air and moisture, water, to vent. 7. Leave the tank drain tap open. This allows any moisture to drain while the air inflator is stored. BLACKRIDGE 1HP AIR INFLATOR... -
Page 7: Maintenance
To open the drain tap pull the lever down to vertical. Pic. 4. To seal the drain tap push the lever up to horizontal. Pic. 5. NOTE: Remember to seal the drain tap before starting the OPEN air inflator. PIC. 5 CLOSED BLACKRIDGE 1HP AIR INFLATOR... -
Page 8: Safety Valve
Pic 7. If the safety valve does NOT work in this manner, STOP the air inflator immediately and have the air inflator checked / PULL TO CHECK serviced by an authorised service facility. BLACKRIDGE 1HP AIR INFLATOR... - Page 9 Smart Marketing Group for options. If these tips do not work please have your unit checked by an authorised service centre. Call SMART MARKETING GROUP PTY. LTD. for your closest centre: AUSTRALIA: 1300 660 457 NEW ZEALAND: 0800 474 876 BLACKRIDGE 1HP AIR INFLATOR...
-
Page 10: Specific Safety Instructions
Never run this air inflator without the air filter and rubber Always follow the instructions relating to the tools attached to stopper(s) being correctly fitted. this air inflator. Never use an extension cord with this air inflator always use a longer air hose. BLACKRIDGE 1HP AIR INFLATOR... -
Page 11: Complete Warranty Statement
Products presented for repair may be replaced by refurbished products of the same type rather than being repaired. Refurbished parts may be used to repair the products. BLACKRIDGE 1HP AIR INFLATOR... - Page 12 Keep the power cord away from heat, oil, solvents work area, especially when using tools designed for sanding or and sharp edges. Regularly check the plug and cord and if spraying liquids. damaged have it replaced by an authorised service facility. BLACKRIDGE 1HP AIR INFLATOR...
-
Page 13: Fire Precautions
Remove adjusting keys and wrenches Form the habit of always checking to see that any adjusting keys or wrenches have been removed from the air inflator or attached air tools before operating. BLACKRIDGE 1HP AIR INFLATOR... -
Page 14: Personal Safety
Stay Alert Watch what you are doing, use common sense and never operate an air inflator when you are under the influence, tired, drinking alcohol, taking drugs or if taking medication that causes drowsiness. BLACKRIDGE 1HP AIR INFLATOR... -
Page 15: Parts Diagram
Part No. Air Filter 95 BRAF Rubber Handle Grip 95 BRTHG Exhaust Tube 95 BRETS Outlet Fitting 95 BROFN Pressure Gauge - Tank 95 BRPG Safety Valve 95 BRSPV Cushion Foot 95 BRCF Drain Tap 95 BRDT BLACKRIDGE 1HP AIR INFLATOR... - Page 16 1HP AIR INFLATOR MODEL NO. BR500 - PLU: 590729 For service, spare parts or product information, please contact: SMART MARKETING GROUP PTY. LTD. AUSTRALIA: 1300 660 457 NEW ZEALAND: 0800 474 876 04066 02/20...
