Summary of Contents for Avallon AWBC241GGFD
- Page 1 USER’S GUIDE Installation, Operation, and Maintenance for your product. Built-In Wine and Beverage Cooler Model – AWBC241GGFD www.avallon.com V2.2-01082018...
- Page 2 Important Safety Information Improper handling can cause serious damage to the Avallon wine and beverage refrigerator and / or injury to the user. This wine and beverage refrigerator is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the rating label located on the rear panel of the unit for electrical and other technical data related to this unit.
- Page 3 GENERAL SAFETY • To prevent back and other types of injuries, use at least two people to move and install the wine cooler. • This appliance is not intended for use by persons, including children, with reduced physical, sensory, or mental capabilities, unless they have been given supervision or instruction concerning the use of the appliance by the person(s) responsible for their safety.
-
Page 4: Table Of Contents
Increasing the Temperature……………………………………………………………………………………………………………………………………………….8 Decreasing the Temperature………………………………………………………………………………………………………………………………………………8 Interior Light……………………………………………………………………………………………………………………………………………………………………….8 Internal Light……………………………………………………………………………………………………………………………………………………………………… Constant Mode………………………………………………………………………………………………………………………………………………………………….. 9 Automatic Mode………………………………………………………………………………………………………………………………………………………………… 9 Door Ajar Alarm…………………………………………………………………………………………………………………………………………………………………. Defrosting………………………………………………………………………………………………………………………………………………………………………….. Normal Sounds…………………………………………………………………………………………………………………………………………………………………… Cleaning and Maintenance…………………………………………………………………………………………………………………………………………………. INTERIOR CLEANING…………………………………………………………………………………………………………………………………………………………… EXTERIOR CLEANING………………………………………………………………………………………………………………………………………………………….. Preparing Your Wine and Beverage Refrigerator for Storage……………………………………………………………………………………………… Troubleshooting…………………………………………………………………………………………………………………………………………………………………. Specifications……………………………………………………………………………………………………………………………………………………………………… Avallon Product Warranty………………………………………………………………………………………………………………………………………………….. -
Page 5: First Time Operating Instructions
First Time Operating Instructions: Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep track of all included parts and pieces before discarding packaging materials. It is advised that you keep the original box and packaging materials in case you need to move or ship the appliance in the future. Allow the unit to stand for at least 24 hours before you use it;... -
Page 6: Introduction
Introduction Thank you for purchasing your Avallon wine and beverage refrigerator. Avallon is dedicated to developing products that will enhance your lifestyle with superior quality and distinctive features. Please visit www.avallon.com for more information on your product and other Avallon products. -
Page 7: Parts Identification
Parts Identification Carbon Filter A built-in carbon filter protects your wine and beverages by acting as a natural barrier against harmful odors. Internal Fan This is an air-cooled unit equipped with an internal fan that maintains a consistent internal temperature. -
Page 8: Installing Your Wine And Beverage Refrigerator
Note: The carbon filter should be replaced every 3 - 6 months depending on the unit’s exposure level to odor. If the unit is placed in a kitchen, regular replacement every three (3) months is ideal. Tip: Gather the model and serial number from the product label and write them down before installing the wine and beverage cooler. -
Page 9: Built-In Installation
Built-in Installation A recessed installation will allow you to install the wine and beverage cooler under a counter or in a kitchen cabinet provided the clearance space requirements around the wine and beverage cooler are followed. It is necessary to allow adequate ventilation space around the unit (make sure there is at least some ventilation room for the back of the unit). -
Page 10: Leveling
LEVELING: The wine and beverage refrigerator should be installed on a firm and level surface that will be able to support the entire weight of a fully loaded unit. It is important for the refrigerator to be leveled in order to work properly. -
Page 11: Installing The Shelves
INSTALLING THE SHELVES: Left Zone 1. Open the door completely. 2. Push the shelf tracks affixed to the walls of the inner cabinet to the rear of the unit so that the tracks are fully seated inside the cooler compartment. 3. -
Page 12: Operation
Right Zone 1. Open the door completely. 2. Make sure the shelf is pushed back completely. 3. Lift either the left or right side of the shelf to create a 45° angle from its original position. Make sure not to lift either side of the shelf too hard as it may come in contact with the inner wall mount. 4. -
Page 13: Using Your Control Panel
USING YOUR CONTROL PANEL: Each independently controlled temperature zone – right and left – has a temperature range of 39° F to 65° F. Each zone contains its own control panel. Power Button Press and hold this button down for three seconds to power your unit on. Once pressed, the “Run” indicator light will illuminate to indicate the unit is on and running. -
Page 14: Internal Light
Warning: Allow at least 24 hours for your wine and beverage cooler to run before storing your beverages to allow the temperature to acclimate. Whether your wine and beverage cooler can reach the actual set temperature depends on the ambient environmental conditions. Internal Light This refrigerator is equipped with top and side internal lights that can be set to a blue or white color. -
Page 15: Defrosting
Defrosting Note that under most refrigerating settings, the unit will automatically defrost under most ambient conditions. However, on colder settings, some frost may build up. Additionally, the more humid the ambient conditions, the more frost may build up. Keep the door closed as much as possible and avoid opening the door unnecessarily to minimize frost build-up. -
Page 16: Preparing Your Wine And Beverage Refrigerator For Storage
Preparing Your Wine and Beverage Refrigerator for Storage If the wine and beverage refrigerator will not be used for a long time, or is to be moved to another place, it will be necessary to defrost the unit and dry the interior. 1. - Page 17 ISSUE POSSIBLE CAUSE SOLUTION The wine and beverage cooler is Certain sounds are normal Read the “Normal Sounds” making strange noises. section. The unit is not level or is touching Check to make sure the cooler is another appliance. level and that it is not in contact with another appliance or furniture.
-
Page 18: Specifications
Specifications Dual Zone Built-In French Door Wine and Beverage DESCRIPTION OF PRODUCT Cooler MODEL AWBC241GGFD VOLTAGE / FREQUENCY AC 115 / 60 Hz AMPERAGE 1.5 A INPUT POWER 130 W COLOR Black Cabinet with Stainless Steel Doors STORAGE CAPACITY 21 Bottles and 64 Cans* REFRIGERANT R600a, 1.41 oz. -
Page 19: Avallon Product Warranty
Avallon Product Warranty...
