TI00126R/09/EN/14.18
71404948
2018-05-31
Заказывайте на сайте: www.tinnova.ru/endress_hauser/ || Эл. почта: info@tinnova.ru
Products
Technical Information
T13, T14 and T15
Explosion proof RTD assemblies in thermowells
with spring loaded insert and enclosure for process
industry
Application
• Heavy duty applications
• The sensor assemblies can be used in process industries such as:
– Chemicals
– Petrochemical
– Refineries
– Offshore platforms
• Measuring range: –200 to 600 °C (–328 to 1 112 °F)
• Protection class: IP66/67
Head transmitter
All Endress+Hauser transmitters are available with enhanced accuracy and reliability
compared to directly wired sensors. Easy customizing by choosing one of the
following outputs and communication protocols:
• Analog output 4 to 20 mA
• HART
®
®
• PROFIBUS
PA
• FOUNDATION Fieldbus™
Field transmitter
Temperature field transmitters with HART® or FOUNDATION Fieldbus™ protocol for
highest reliability in harsh industrial environments. Backlit display with large
measured value, bargraph and fault condition indication for ease of reading.
Your benefits
• FM/CSA XP Class I, Div. 1 approved temperature assemblies for maximum safety
• One source shopping for temperature measurement solutions. World class
transmitter with integrated sensor offering for heavy process industry applications
• Remove and install straight out of the box
• Improved galvanic isolation on most devices (2 kV)
• Simplified model structure: Competitively priced, offers great value. Easy to order
and reorder. A single model number includes sensor, thermowell and transmitter
assembly for a complete point solution
• All iTEMP transmitters provide long-term stability ≤ 0.05% per year
Solutions
Services
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Endress+Hauser T13
Summary of Contents for Endress+Hauser T13
- Page 1 • Measuring range: –200 to 600 °C (–328 to 1 112 °F) • Protection class: IP66/67 Head transmitter All Endress+Hauser transmitters are available with enhanced accuracy and reliability compared to directly wired sensors. Easy customizing by choosing one of the following outputs and communication protocols: •...
-
Page 2: Function And System Design
T13, T14 and T15 Function and system design Measuring principle Resistance thermometer (RTD) These resistance thermometers use a Pt100 temperature sensor according to IEC 60751. The temperature sensor is a temperature-sensitive platinum resistor with a resistance of 100 Ω at 0 °C (32 °F) and a temperature coefficient α... -
Page 3: Family Of Temperature Transmitters
They offer a high degree of flexibility, thereby supporting universal application with low inventory storage. The iTEMP transmitters can be configured quickly and easily at a PC. Endress+Hauser offers free configuration software which can be downloaded from the Endress+Hauser Website. More information can be found in the Technical Information. -
Page 4: Power Supply
Benefits are: dual sensor input, highest reliability in harsh industrial environments, mathematic functions, thermometer drift monitoring and sensor back-up functionality, corrosion detection. Galvanic isolation Galvanic isolation of Endress+Hauser iTEMP transmitters Transmitter type Sensor TMT181 PCP Û = 3.75 kV AC TMT182 HART®... - Page 5 T13, T14 and T15 Head mounted transmitter TMT8x (dual input) Sensor input 1 Sensor input 2 Bus connection and supply voltage RTD 3-wire RTD 4- and 3-wire (black) (black) white white white (green) Display connection A0029556-EN Field mounted transmitter Sensor 1...
- Page 6 T13, T14 and T15 Terminal block mounted 3-wire single R1 = Red1 R3 = Red3 Outside screw W5 = White5 2 x 3-wire single 4-wire single R1 = Red1 B5 = Black5 R3 = Red3 R2 = Red2 B6 = Black6...
-
Page 7: Wire Specifications
T13, T14 and T15 Grounding The device must be connected to the potential equalization. The connection between the housing and the local ground must have a minimum cross-section of 4 mm (13 AWG) . All ground connections must be secured tightly. -
Page 8: Performance Characteristics
RTD assembly T15 without thermowell Construction High temperature range Low temperature range Response time for the sensor assembly without transmitter. Response time examples for RTD assemblies with thermowell T13 and T14 Construction Stepped thermowell Tapered thermowell Straight thermowell (¾") High temperature range... - Page 9 In addition to the measurement current, the size of the measurement error is also affected by the temperature conductivity and flow velocity of the process. This self- heating error is negligible when an Endress+Hauser iTEMP temperature transmitter (very small measurement current) is connected.
-
Page 10: Installation Instructions
• Minimum immersion length per ASTM E644, ΔT ≤ 0.05 °C (0.09 °F): For temperature assemblies with themowell (T13 and T14) the minimum immersion is the depth to which the thermowell is immersed in the medium, measured from the tip. To minimize errors from... -
Page 11: Shock And Vibration Resistance
T13, T14 and T15 Terminal head Temperature in °C (°F) With mounted head –20 to 70 °C (–4 to 158 °F) transmitter and display With mounted field • Without display: –40 to 85 °C (–40 to 185 °F) transmitter • With display and/or integrated overvoltage protection module: –40 to +80 °C (–40 to +176 °F) -
Page 12: Mechanical Construction
XA Immersion length RTD sensor Drill depth of thermowell Overall insert length For T13 thermowells with ½" NPT and 1" process thread length and ¾" hex length dimensions, spring loaded sensor assemblies must be used with the thermowells. Endress+Hauser Заказывайте на сайте: www.tinnova.ru/endress_hauser/ || Эл. почта: info@tinnova.ru... - Page 13 T13, T14 and T15 All thermowells are marked with a material ID, CRN (Canadian Registration Number) and heat number. Dimensions of T13 E (nominal dimension) Process Shape of ⌀Q connection thermowell 63.5 mm (2.5 in) Material: Steel or 316SS 76.2 mm (3 in) or ½"...
- Page 14 T13, T14 and T15 E (nominal dimension) Flange size ⌀Q, tapered version Immersion length RTD sensor = thermowell drilled length X = A = U + 50.8 mm (2 in) + T Overall insert length X = A + E...
- Page 15 Can be used to a limited extent up to 800 °C (1472 °F) for low compressive loads and in non-corrosive media. Please contact your Endress+Hauser sales team for further information. Process connection The process connection is the means of connecting the thermometer to the process. The following...
- Page 16 For ambient temperatures with head transmitter installed, see the ' E nvironment' section. As a special feature, Endress+Hauser offers terminal heads with optimized terminal accessibility for easy installation and maintenance. Some of the specifications listed below may not be available on this product line.
- Page 17 T13, T14 and T15 TA30H Specification • Flameproof (XP) version, explosion-protected, captive screw 125 (4.92) cap, available with one or two cable entries • Degree of protection: IP 66/68, NEMA Type 4x Encl. Ex-version: IP 66/67 • Temperature: –50 to +150 °C (–58 to +302 °F) for rubber seal without cable gland (observe max.
-
Page 18: Certificates And Approvals
• Gold plated terminals to avoid corrosion and additional measurement errors Certificates and approvals CE Mark The device meets the legal requirements of the EC directives if applicable. Endress+Hauser confirms that the device has been successfully tested by applying the CE mark. Endress+Hauser... -
Page 19: Other Standards And Guidelines
QUYX8.E225237 and QUYX2.E225237 except for TMT84 PROFIBUS® PA. CSA/FM T13, T14 with blue connection head or field housing FM XP DIP Class I, II, III Div. 1+2, Grp. A-G FM XP NI DIP Class I, II, III Div. 1+2, Grp. A-G CSA XP DIP Class I, II, III Div. - Page 20 T13, T14 and T15 Accessories Various accessories, which can be ordered with the device or subsequently from Endress+Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
- Page 21 DeviceCare is the tool developed by Endress+Hauser for the configuration of Endress+Hauser devices. All smart devices in a plant can be configured via a point- to-point or point-to-bus connection. The user-friendly menus enable transparent and intuitive access to the field devices.
- Page 22 E+H-specific diagnostic command. For details, see "Technical Information", TI00073R/09/en Documentation Brief operating instructions - explosion proof RTD assemblies • T13 with thermowell, KA00236R/24/EN • T14 with flanged thermowell, KA00237R/24/AE • T15 KA00238R/24/EN Technical Information temperature transmitter iTEMP • HART® TMT82, TI01010T/09/EN •...
