Summary of Contents for Safety Vision 43M
- Page 1 USER GUIDE...
- Page 2 This material is confidential and the property of Safety Vision. It is shared with your company for the sole purpose of helping you with the operation of the described equipment.
-
Page 3: Table Of Contents
43M USER GUIDE Contents Safety And Installation Instructions Features Monitor Controls Mirror Monitor Installation Connection Operation Instructions Cleaning And General Maintenance Cleaning Ventilation Object and Liquid Entry Servicing Specifications FCC Compliance Statement... -
Page 4: Safety And Installation Instructions
43M USER GUIDE Safety And Installation Instructions • Secure the monitor in such a way that it cannot become loose under any circumstances (sudden braking, accidents) and cause injuries to the occupants of the vehicle. • Do not attach the monitor in an area that may be used by an airbag, as this could cause injury if airbags are deployed. -
Page 5: Features
43M USER GUIDE Features • The 4.3” screen can be set to display in the left, middle, or right side of the mirror monitor. • Combines normal rear view mirror and rear vision monitor. • Clips over 70% of existing GM, Ford, and Toyota vehicles original rear view mirror studs. -
Page 6: Monitor Controls
43M USER GUIDE Monitor Controls 1 - Auto Dimmer Automatic brightness control sensor. 2 - MENU • Contrast Control To adjust the contrast color for the desired best picture, press the MENU button and select CONTRAST in the on-screen display. Use the (+) and (-) buttons to increase/decrease the picture contrast. - Page 7 43M USER GUIDE • Normal/Mirror Image Setting Press the MENU button and select MIR1 OFF in the on-screen display. Use the (+) and (-) buttons to select a Mirror Image or Normal Image to be displayed for Camera 1 (V1). Repeat these steps for Camera 2 (V2).
-
Page 8: Mirror Monitor Installation
43M USER GUIDE Mirror Monitor Installation Remove the original rear view mirror from the vehicle. 2. Adjust the angle of the mirror monitor by rotating the ball joint on the bracket to the best position. 3. Unscrew the silver lug, slide the... -
Page 9: Connection
43M USER GUIDE Connection • Connect the RED wire to Caution: positive (12V or 24V DC) power • Disconnect the ground terminal terminal which is powered of the vehicle’s battery BEFORE with the ignition key is in the making the connection to avoid ACC position. -
Page 10: Operation Instructions
43M USER GUIDE Operation Instructions When the ignition key is in the ACC or ON position, power is supplied to the monitor and the status LED light will display solid red. Press the CAM Select button or shift the vehicle into reverse gear to activate the monitor. -
Page 11: Specifications
43M USER GUIDE Specifications DISPLAY SIZE BRIGHTNESS 4.3 in 400 cd/m2 ASPECT RATIO ON-SCREEN DISPLAY CONTROL 16:9 (4:3 LCD display) Contrast, Brightness, Color, Normal/ Mirror Image, CAM Select RESOLUTION CONTROL BOX 480(h) × 272(v) Integrated VIEWING ANGLE POWER SUPPLY 50(U) / 70 (D) / 70(L) / 70 (R) -
Page 12: Fcc Compliance Statement
43M USER GUIDE FCC Compliance Statement NOTE This device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 13 CORPORATE HEADQUARTERS 6100 W. Sam Houston Pkwy. N. Main: 713.896.6600 Houston, TX 77041-5113 Toll Free: 800.880.8855 www.safetyvision.com Fax: 713.896.6640 Copyright © 2019 Safety Vision, LLC All Rights Reserved.
