- Page 2 What’s in the Box? • 2 Color CCD side cameras w/infra-red weather proof cameras • 1 Color CCD w/infra-red weather proof camera • 1 DIGITAL 7" TFT LCD color monitor with universal mount/stand and wire • 1-66' Camera cable for Backup camera •...
-
Page 3: Table Of Contents
Table of Contents Introduction...................4 Safety Information..............5-7 Before Beginning Installation ............8 Installation Guide................9 Wiring Camera & Monitor ............10-11 Installation Diagram ..............12 Installing the Monitor ..............13 Monitor Operation ..............14 Splitting & Splicing ..............15 Positioning ................. Multiplexer ..................17 Monitor Dimensions ..............18 Monitor Specifications ...............19 Rear Camera Dimensions............20... -
Page 4: Introduction
Introduction Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System. With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle. -
Page 5: Safety Information
Safety Information Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applicable local traffic and motor vehicle regulations as it pertains to this product. - Page 6 Safety Information INSTALLTION • While installing the Rear View System be careful with • Electric shock or product the wire positioning in order malfunction may occur if to avoid wire damage this product is installed incorrectly. • The Rear View System should only be used when the vehi- •...
-
Page 7: Safety Information
Safety Information If you have questions about this product, contact: Customer Service: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. -
Page 8: Before Beginning Installation
Before Beginning Installation Before Beginning Installation Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. -
Page 9: Installation Guide
Installation Guide Camera 1. Attach camera bracket close to rear marker lights, centered on vehicle. 2. Attach camera to bracket using screws provided and adjust the angle. Cable 1. Be sure to position the cable properly. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather elements, do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. -
Page 10: Wiring Camera & Monitor
Wiring Camera & Monitor • When installing a ONE (1) cable into vehicle (be careful camera setup, connect camera not to kink cable) and fit extension cable from the rear grommet into hole. Apply view camera to port # labeled sealant around grommet to “backup”... -
Page 11: Wiring Camera & Monitor
Wiring Camera & Monitor • Audio works on two ports of • There is a built-in voltage multiplexer and positive triggers regulator for our systems which must be triggered for audio to can handle 12-24 volts real operate. Port labeled “backup” consumption is 10 to 30 Volts. -
Page 12: Installation Diagram
Installation Diagram On Select Models Figure 1.1 Figure 1.2 Figure 1.3 Figure 1.4 Connection of U Bracket Connection of Flushmount Bracket REAR VIEW SAFETY... -
Page 13: Installing The Monitor
Installing the Monitor 20m Extension Cable Monitor Camera 2 10m Extension Cable Video Out 20m Extension Cable 3 Amp Fuse Camera 3 1. DC12V-24V (red) 2. Ground (black) 3. Port #3 (blue) 4. Port #2 (white) 5. Port #1 (yellow) Camera 1 Reverse With Confidence ™... -
Page 14: Monitor Operation
Monitor Operation DOWN CAMERA ARROW SELECTION MENU/ SELECTION ARROW BUTTON POWER ROTATION ON / OFF IMAGER (Exit when in MENU mode) • To turn on the monitor, press “ON” button. • To adjust brightness, press “MENU” 1 time and use arrows •... -
Page 15: Splitting & Splicing
Splitting & Splicing Installing & Splitting Embedded Monitor Installing sun shield: Put shade cover on the display. Installing back cover: Put the monitor with shade cover in the back cover (only for embedded monitor) Splitting back cover: Hold monitor with 2 hands and detach with fingers, as indicated by arrows. -
Page 16: Positioning
Positioning Rear & Side Cameras Positioning REAR VIEW SAFETY... -
Page 17: Multiplexer
Multiplexer Port #1 Port #2 Port #3 or DVD Backup Reverse With Confidence ™... -
Page 18: Monitor Dimensions
Monitor Dimensions Some Models 7” 5 25” Rotation Imager with sun shade Menu/ (Exit in Camera Power Selection Down Menu Selection Arrow On/Off Button Arrow Mode) power video select down/up menu mirror/normal image REAR VIEW SAFETY... -
Page 19: Monitor Specifications
Monitor Specifications TFT LCD Digital Monitor Screen Size 7” Dot Resolution x 480 Display Format 16:9 / 500:1 Display Brightness 400cd/m Viewing Angle U:50° / D:60° / R:70° Video Input 3 channel Video Source 1Vp-p, 75 Power Supply DC 12V-24V (+/- 10%) Power Consumption Operating Temperature -30°C ~ +80°... -
Page 20: Rear Camera Dimensions
Rear Camera Dimensions Rear Camera 3” 3 25” REAR VIEW SAFETY... -
Page 21: Rear Camera Specifications
Rear Camera Specifications Camera 1/4” Sharp® Color CCD Picture Elements 250,000 pixels Gamma Correction r=0.45 to 1.0 Image Sensor 600 TV lines PAL:500h x 582v, NTSC: 510h x 492v 2.1mm Lens View Angle 130° Sync System Internal Synchronization Infrared distance 50 Feet (18 Infrared IR) Usable Illumination 0 Lux (IR On) -
Page 22: Side Camera Dimensions
Side Camera Dimensions Side Camera REAR VIEW SAFETY... -
Page 23: Side Camera Specifications
Side Camera Specifications Camera 1/4” Sharp® Color CCD Picture Elements 250,000 pixels r=0.45 to 1.0 Gamma Correction 420 TV lines PAL:500h x Image Sensor 582v NTSC: 510h x 492v Lens 2.1mm View Angle 120° Sync System Internal Synchronization Infrared distance 30 Feet (9 Infrared IR) Usable Illuminatiom 0 Lux (IR On) -
Page 24: Troubleshooting
Troubleshooting Monitor Display Blue Screen & Displays No Signal • Do a hard reset, unplug all • Verify that the blue positive cables and power cables from trigger on power harness is multiplexer (silver box) leave put to power 12v+. out for 1 minute and then If the problem still persists, re-connect them. -
Page 25: Warranty
Warranty One Year Warranty Rear View Safety, Inc. warrants this product against material defects for a period of one year from date of purchase. We reserve the right to repair or replace any such defective unit at our sole discretion. Rear View Safety, Inc. -
Page 26: Disclaimer
Disclaimer Rear View Safety and/or its affiliates does not guarantee or promise that the user of our systems will not be in/part of an accident or otherwise not collide with an object and/or person. Our systems are not a substitute for careful and cautious driving or for the consistent adherence to all applicable traffic laws and motor vehicle safety regulations. - Page 27 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 BETTER CAMERAS. BETTER SERVICE. IT’S OUR GUARANTEE.
