2. Connection of AV receiver/amplifier and PC

2.1 Connection diagram

You can select the following 3 methods.
Also connect the display monitor for OSD.
a) Connect the Ethernet cross cable between Ethernet port of PC and Ethernet port of AV
Receiver/Amplifier. (refer to 3)
PC
b) Connect the Ethernet straight cable between Ethernet port of PC and Ethernet port of Hub (or
Router w/o DHCP server). And connect the Ethernet straight cable between Ethernet port of
Hub (or Router w/o DHCP server) and Ethernet port of AV Receiver/Amplifier. (refer to 4)
PC
C) Connect the Ethernet straight cable between Ethernet port of PC and Ethernet port of
Router( with DHCP server). And connect the Ethernet straight cable between Ethernet port of
Router( with DHCP server) and Ethernet port of AV Receiver/Amplifier. (refer to 5)
PC
Ethernet cross cable
HUB or
Router(w/o DHCP
server)
Ethernet Ethernet
straight straight
cable
Router
With
DHCPserver
Ethernet Ethernet
straight straight
cable
AV Receiver
/Amplifier
AV Receiver
/Amplifier
cable
AV Receiver
/Amplifier
cable
Page 5 / 18
Display
Display
Display
