Canon Paper Deck-V1 Circuit Diagram
Hide thumbs
Also See for Paper Deck-V1:
- General timing chart/general circuit diagram (12 pages) ,
- Portable manual (42 pages) ,
- Service manual (90 pages)
Related Manuals for Canon Paper Deck-V1
Summary of Contents for Canon Paper Deck-V1
- Page 1 Circuit Diagram Paper Deck Paper Deck-V1 Feb 21 2005...
- Page 3 IMPORTANT This documentation is published by Canon Inc., Japan, to serve as a source of reference for work in the field. Specifications and other information contained herein may vary slightly from actual machine values or those found in advertising and other printed matter.
-
Page 5: Table Of Contents
Contents 1 Deck Driver PCB..............................1 Deck Driver PCB (1/7)............................1 Deck Driver PCB (2/7)............................2 Deck Driver PCB (3/7)............................3 Deck Driver PCB (4/7)............................4 Deck Driver PCB (5/7)............................5 Deck Driver PCB (6/7)............................6 Deck Driver PCB (7/7)............................7... -
Page 7: Deck Driver Pcb
1 Deck Driver PCB Deck Driver PCB (1/7) +24V FU01 +24V +24V DECK_OPEN_SW <FROM 2/7,4/7> ZD02 ZD04 ZD01 ZD03 HIGH DOWN RESETB <FROM 2/7> DECK_DW/UP <FROM 2/7> DECK_UP_DTC <FROM 2/7,4/7> UPPER_LIM <FROM 4/7> DECK_LOW_LIM <FROM 2/7,5/7> DECK_LIFT_ON <FROM 2/7> F-1-1... -
Page 8: Deck Driver Pcb (2/7)
Deck Driver PCB (2/7) VSS1 VDD4 DECK_OPEN_SW (TX0) <FROM 4/7> RX15 (TX1) PAPER_DTC <FROM 4/7> RX14 (TX2) DECK_UP_DTC <FROM 4/7> RX13 (TX3) DECK_FEED_DTC <FROM 4/7> TX31 (TX4) DECK_PULL_DTC <FROM 4/7> TX30 (TX5) PICK_SL_DTC <FROM 4/7> TX29 (TX6) DECK_FEED_M_LOCK <FROM 5/7> RX12 (TX7) PAPER_TOP_DTC... -
Page 9: Deck Driver Pcb (3/7)
Deck Driver PCB (3/7) S-CLK <TO 2/7> M-CLK <TO 2/7> +24V RXEND <TO 2/7> RXDATA <TO 2/7> TXLOAD <TO 2/7> TXDATA +24V <TO 2/7> DCOL SCOL RXOUTEN IPKS SEMT <TO 2/7> TIMC INVI HC14 F-1-3... -
Page 10: Deck Driver Pcb (4/7)
Deck Driver PCB (4/7) +24V PICK_SL_DTC J13P <TO 2/6> J12P LED_ON (LED_ON) <FROM 2/6> PICK_UP_SL J13P J12P PICK_UP_SL <FROM 2/6> J13P (DECK_OPEN_SW) J12P DECK_OPEN_SW <TO 1/6,2/6> J13P J12P DECK_FEED_DTC DECK_FEED_DTC <TO 2/6> J12P +24V J13P J12P PAPER_DTC PULL_CL_ON <TO 2/6> (PAPER_DTC) J13P J12P... -
Page 11: Deck Driver Pcb (5/7)
Deck Driver PCB (5/7) +24V (DECK_OPEN_SL) DECK_OPEN_SL <FROM 2/7> J10P PAPER_TOP_DTC <TO 2/7> (PAPER_TOP_DTC) J10P J10P DECK_MOUNT_DTC <TO 2/7> (DECK_MOUNT_DTC) J10P PAPER_VOLUME <TO 2/7> (PAPER_VOLUME) J10P J10P DECK_OPEN_DTC <TO 2/7> (DECK_OPEN_DTC) J10P DECK_LOW_LIM <TO 1/7,2/7> (DECK_LOW_LIM) J10P LIFT_M+ J10P (LIFT_M+) <FROM 1/7>... -
Page 12: Deck Driver Pcb (6/7)
Deck Driver PCB (6/7) +24V IC01 RESETB MODE CLOCK RESETB VREF <FROM 3/7> M-CLK <FROM 2/7> DECK_FEED_M_HOLD <FROM 5/7> DECK_FEED_M_ON <FROM 2/7> F-1-6... -
Page 13: Deck Driver Pcb (7/7)
Deck Driver PCB (7/7) JP10 JP11 JP12 JP13 JP14 JP15 JP16 JP17 JP18 JP19 JP20 JP21 JP22 JP23 JP24 JP25 JP26 JP27 JP28 JP29 JP30 JP31 JP32 JP33 JP34 JP35 JP36 JP37 JP38 JP39 JP40 JP41 JP42 JP43 JP44 JP45 JP46 JP47 JP48... - Page 15 Feb 21 2005...
