Universal Bluetooth Handsfree Kit with DSP
Contents
____________________________________________________________
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Switching On/Off. . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Pairing to a Mobile Phone . . . . . . . . . . . . . . . . . . . . . . .3
Indicator Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Hands-free Profile . . . . . . . . . . . . . . . . . . . . . . . . . . .4
SuperTooth II Operations. . . . . . . . . . . . . . . . . . . . . .4
Button Functions Matrix . . . . . . . . . . . . . . . . . . . . . .5
SuperTooth II Operations. . . . . . . . . . . . . . . . . . . . . .6
Button Functions Matrix . . . . . . . . . . . . . . . . . . . . . .7
A. PRODUCT OVERVIEW
SuperTooth II is equipped with Bluetooth and Digital Signal Processor
which allow wireless communications on devices such as cellular phones.
This is designed to be a totally portable wireless handsfree kit which will
enable the user to communicate freely without holding the phone. This will
work on any Bluetooth cellular phones available provided that they respect
the Bluetooth protocol.
1 Swivel Arm
2 Reject Button
3 Headphone Jack
4 Speaker
5 Charger Input
6 Accept / End Button
7 Microphone
8 Bluetooth Indicator
9 Charge Indicator
10 Volume Control
.
.
.
. . . . . . . . . . . . . . . . . . . . . .6
1
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Supertooth II and is the answer not in the manual?

Questions and answers

Summary of Contents for Euro CB Supertooth II

  • Page 1: Table Of Contents

    Hands-free Profile ......4 SuperTooth II Operations..... .4 Button Functions Matrix .

  • Page 2: Supertooth Ii

    The Bluetooth indicator[8] will glow (blue blink). This indicates that the kit is ready (standby mode). Note: At first use, the user has to pair SuperTooth II with his phone (refer to Section E PAIRING TO A MOBILE PHONE.) Power off: Flip down the Swivel Arm to 0º...

  • Page 3: Pairing To A Mobile Phone

    0000. To connect, you need to short press the Accept / End Button[6]. (In your phone) Go back to Bluetooth> Paired devices> highlight the name of this kit (SuperTooth II) > press Options > then press Connect). If pairing has been successful, the SuperTooth II is now ready to use.

  • Page 4: Indicator Status

    2. Execute Voice dial: Short press Accept/ End Button[6]. 3. A beep/short tone will then be heard on the SuperTooth II prompting the user to say the voice tag of a contact to call. 4. Say the voice tag. The voice will be played back to you (audio on kit) then the phone will dial the number automatically.

  • Page 5: Button Functions Matrix

    Answer a Call: When the phone receives a call, ring tone will be on the SuperTooth II alone, or both on the SuperTooth II and on the phone (depending on your phone model). Just short press Accept/End Button[6] to answer the call.

  • Page 6: Headset Profile

    2. Execute Voice dial: Short press Accept/ End Button[6]. 3. A beep/short tone will then be heard on the SuperTooth II prompting the user to say a voice tag of a contact to call. 4. Say the voice tag. The voice will be played back to you (audio on kit) then the phone will dial the number automatically.

  • Page 7: Button Functions Matrix

    Audio Transfer : from Phone to SuperTooth II (SuperTooth II initiated): Short press the Accept/ End Button[6]. J. Button Functions Matrix (Headset Profile) Accept / End Accept / End Reject Button Reject Button Button Button (Short press) (Long press) (Short press)
