A-61
Digital Piano
Owner s Manual
V
M
I
irgin
usical
nstruments

Advertisement

Table of Contents
loading

Related Manuals for Artesia A-61

Summary of Contents for Artesia A-61

  • Page 1 A-61 Digital Piano Owner s Manual irgin usical nstruments...
  • Page 3 Precaution Thank you for purchasing this digital instrument. For correct operation and safety, please read the manual carefully and keep it for future reference. Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 4 Thank you for choosing the Artesia A-61 Digital Piano Your portable 61 note piano not only contains leading and innovative technology but it also is developed by and for musicians of all playing levels. Featuring a natural balanced, weighted keyboard action and an advanced Acousta tone generation sound technology, that will provide you with a rich performing and playing experience.

  • Page 5: Table Of Contents

    Contents Control Panel ................Getting Started ................ Selecting a Voice ..............Demo Songs ................Select the Demo Song ............Stop the Demo Song ............DSP Reverb and Chorus Buttons ........... Layer Mode ................To Adjust the Volume of Main Voice in Layer ......

  • Page 7: Control Panel

    Control Panel POWER SUSTAIN Jack MASTER VOLUME LINE OUT(R) Jack LINE OUT(L)(MONO) Jack METRONOME Button TEMPO Button PHONES Jack REVERB Button POWER Jack POWER Jack CHORUS Button LED DISPLAY VOICES Select USB TO HOST Jack...

  • Page 8: Getting Started

    Getting Started Turn on the power Before playing turn the power on by pressing the POWER switch, the panel LED's will turn on. POWER Setting the Auto Power On/Off Function If there is no playing activity for 30 minutes your piano has an auto turn off function.
  • Page 9 It is the Audio Interface that is used to control the USB-MIDI, and allows you to play recorded music from your laptop, tablet or smartphone through the A-61 sound delivery system. So you can play along with your favorite songs.
  • Page 10 Sustain Pedal The foot pedal included with your digital piano will cause piano key sounds to decay slowly as if they were being held down. The jack will auto-detect the polarity of the sustain pedal. SUSTAIN NOTE Ensure the piano is turned off before connecting the pedal. Otherwise, it will affect the piano set up Function.

  • Page 11: Selecting A Voice

    Selecting a Voice The piano has 8 built-in voices, which include several pianos as well as other instruments. These digitally-sampled musical instrument sounds may be selected one at a time, or layered to produce two voices at once. To select an instrument voice press the appropriate Voice Select button on the right side of the front panel.

  • Page 12: Demo Songs

    Demo Songs There are 8 demo songs in the piano. Each demo song will demonstrate a different instrument voice. Here's how you can select and play the demo songs. Select the Demo Song The demo songs may be played by pressing the [REVERB] and [CHORUS] buttons together simultaneously.

  • Page 13: Dsp Reverb And Chorus Buttons

    Reverb and Chorus Buttons The Reverb and Chorus effects may be applied to some instrument voices individually and will be retained even when the power is turned off. REVERB CHORUS To apply the effect, press either button. The button will light and the effect will be heard when the piano is played.
  • Page 14 To exit the [REVERB] or [CHORUS] function, press the [REVERB] or [CHORUS] button again. Play the keyboard to hear the new setting with the sound selected.

  • Page 15: Layer Mode

    Layer Mode In Layer mode two voices may be played simultaneously, each at different selected volumes, if desired. To enter the Layer mode, press and hold the direct voice select button to select the MAIN sound, then press the button for the LAYER sound, and release. Both the buttons and LED will turn on while layered.

  • Page 16: To Adjust The Volume Of The Layer Voice

    The volume can be changed from 0-127, where C6=127 and C1=0. Pressing a key will play the C3 note pitch of the currently selected voice sound at the volume corresponding to the key value. See the Appendix for the value ranges. To exit the Voice Volume function, press the [METRONOME] and [TEMPO] buttons at the same time again.
  • Page 17 Press a key will play C3 of the currently selected layered sound at the volume corresponding to the key value. Press the [METRONOME] and the [TEMPO] again to exit the Function mode.

  • Page 18: Metronome

    Metronome Press the metronome button to turn the metronome on. FUNCTION When the Metronome button is activated its LED will turn on and you METRONOME TEMPO will hear the click through the speakers. Metronome Volume Press the [METRONOME] and [TEMPO] buttons together to enter the Function mode.

  • Page 19: Tempo

    Tempo The tempo of the metronome may range from 20 to 280 beats per minute (BPM). FUNCTION METRONOME TEMPO To change the tempo, press and hold the button for 3 seconds to change the setting. The LED will blink to the current tempo speed. Press a key on the keyboard to select a desired tempo.

  • Page 20: Mastertunning

    Function Mode In the Function Mode the keys on the keyboard are used for selecting the Function to be edited. To enter the Function Mode, press the [Metronome] and [Tempo] buttons at the same time. Function Key Assignments Please refer to pages 25 - 28 for information about the Function Assignment values.

  • Page 21: Functions

    Pressing any key from C3 and up will play the C3 note but at Pitch settings proportionately so that its possible to tune up by a whole semitone. The user can determine the correct tuning setting. LED display will be the selected values.

  • Page 22: Eq Adjustment

    EQ Adjustment To change the sound of your piano's amplifier you can adjust the EQ to add more Bass or to add or remove some of the Treble. To Change the Bass Response 1. Press the [METRONOME] and [TEMPO] Buttons together to enter the Function mode.
  • Page 23 3. The Treble EQ can be changed by pressing white piano keys only from the A1 piano key to D5 piano key. Pressing the F3 Piano Key sets the Treble EQ to its center point EQ Setting. Pressing the A1 Piano Key will reduce the Treble response by -12dB. Pressing the D5 Piano Key therefore increases the Treble response by 12 dB.

  • Page 24: Midi Functions

    MIDI Functions MIDI Channels MIDI Out channel values range from 1 to 16. To change the MIDI Out Channel Value: While in the Function Mode press the A 2 Key the amount of times that correspond to the MIDI Out Channel that you desire. The LED display will show the MIDI channel value.

  • Page 25: Midi Panic Key

    your computer) without playing the internal sounds of this piano. You may also find other occasions (such as when you are using MIDI sequencing software on your computer) where it is useful to turn the Local Off. Press the [METRONOME] and the [TEMPO] Buttons together to enter the Function mode.
  • Page 26 5) allows the user to activate the automatic stop or Press the Panic Key (A Panic Mode, that will send out the general MIDI reset messages such as all note off, etc. Once Panic reset has been completed, the Piano will automatically exit the Function mode.

  • Page 27: Factory Reset

    Factory Reset Performing a Factory Reset will clear all memory and restore all functions to their factory default settings, just like they were when you used this piano for the first time. 1. Turn the Power Off. 2. Hold down the [METRONOME] and the [TEMPO] buttons while powering on the piano. FUNCTION METRONOME TEMPO...

  • Page 28: Appendix

    Appendix MIDI Implementation Chart F u n c t i o n T r a n s m i t t e d R e c o g n i z e d R e m a r k s Basic Default 1-16...
  • Page 29 Parameter adjusting instructions According to chart shown below, choose corresponding key to set the desired values. Voice Layer Metro. Reverb Chorus Treble Bass Tempo Tune Transpose × × × × × × × × × × × × × × ×...
  • Page 30 Layer Metro. Voice Reverb Chorus Treble Bass Tuning Tempo Transpose × × × × × × × × × × × × × × × × × × × × × × × × × × × × × × ×...
  • Page 31 Layer Metro. Voice Reverb Chorus Treble Bass Tempo Tuning Transpose × × × × × × × × × × × × × × × × × × × × × × × × × × × Note: X= No value available for this particular Function on this key. Resetting Value: Voice Layer...

  • Page 32: Advanced Function Keyboard Chart

    Advanced Function Keyboard Chart EQ TREBLE EQ TREBLE EQ BASS EQ BASS PANIC PANIC AUTO POWER LOCAL CHANNEL MERTO. TYPE AUTO POWER MERTO. VOL LOCAL CHANNEL LAYER VOL MERTO. TYPE MAIN VOL MERTO. VOL TOUCH HIGH2 LAYER VOL TOUCH HIGH1 MAIN VOL TOUCH NORM2 TOUCH NORM1...

  • Page 33: Specifications

    Specifications Keyboard: 61 weighted velocity-sensitive keys Display: Multi - Function LED Display Voice: Polyphony: Layer, Transpose,Sustain,Volume, Tune Voice Control: On/off, Level, Time signature Metronome: Pedal Response: Sustain Reverb, Chorus, Bass EQ, Treble EQ Effect: Demo Songs: Channels 1-16, Local On/Off; USB MIDI MIDI &...
  • Page 36 Virgin Musical Instrument Company Inc P O Box 2908 La Mesa, CA 91943 PH: 619 244-0006 E-mail: info@virginmi.com www.virginmi.com...
