Operation Modes; Bluetooth Mode; Radio Mode; Mp3 Player Mode - Sven PS-210 User Manual

ENG

OPERATION MODES

Bluetooth mode

• Wireless data transfer via the Bluetooth protocol enables to connect speaker system to
compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as
walls or other electronic devices can interfere with the signal transfer.
• Turn on the speakers in Bluetooth mode – press the button h repeatedly until the
button i blinks white short.
• It is necessary to select the search mode of devices with Bluetooth on a signal source
(telephone, notebook, smartphone, etc.). "SVEN PS-210", massage will be displayed on
the screen which is to be connected to*.
• When connection is successful, there will be a short beep and the indication of the
search mode on speaker system is over**.

Radio mode

To improve radio reception, connect USB-microUSB cable (included) to the input f .
• Turn on the speaker system – press button h several times until, the radio mode will
turn on. Long-term pressing button j activates auto search mode. After scanning
completion, the first scanned radio station will start to operate automatically. With buttons
g and k select a desired radio station.
МР3 player mode
Attention! The file system of a micro SD or USB flash carrier is FAT32. Maximum
volume is 32 GB. It is not recommended to use the micro SD Ultra Speed.
• Insert the USB flash or micro SD carrier into appropriate slot. If the speaker system is in
turned on position, the playback will start automatically. Playback/Pause modes are
switched over with the help of the button j. Tracks can be controlled by buttons g
(previous track) and k (next track).

The use in the wired mode (AUX)

• Speaker system can be used as an external device for amplifying any audio source with
a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack to the
audio output AUX c .

Connecting an additional speaker

It is poddible to connect an additional speaker to the model "SVEN PS-210":
• Turn on both speakers (long press button i). On both speakers, the button i will
flash white light flashes.
• On one of the speakers, press and hold the button h until a beep sounds, then release
it. The speakers will connect with each other. On both speakers, the button i will light
steadily.
* You might have to enter "0000" code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search mode
activation is not obligatory. Choose the item name "SVEN PS-210" and the "connect" command on
the source.
4
Portable Speaker System
with Bluetooth and FM-radio
