User's Manual
Note. At the subsequent inclusion of both speakers, they will be connected automa-
tically.
The use in the wired mode (AUX)
• Speaker system can be used as an external device for amplifying any audio source with
a 3.5 mm output mini-jack. To do this, connect speaker system with a mini-jack to
mini-jack signal cable to the audio output AUX c.
Socket
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Frequency range, Hz
Output power (RMS), W:
Membrane, mm
Bluetooth supported profiles
Radius of operation Bluetooth, m
Battery capacity, mA * h
Power supply
Weight, g
Dimensions, mm
Notes. Technical specifications given in this table are supplemental information and cannot give
occasion to claims. Technical specifications and package contents are subject to change without
notice due to the improvement of SVEN production.
Mobile
PC
device
Mini-jack to mini-jack
signal cable
USB to micro USB Power cable
USB jack
Fig. 2. Connection diagram
Value
speaker: 120 – 20 000; microphone: 50 – 16 000
12 (2 × 6)
Ø 50
HSP, HFP, A2DP, AVRCP
up to10
1500
USB/DC5
700
192 × 86 × 86
PS-210
USB
DC 5V
AUX
micro SD
Technical support is on www.sven.fi.
ENG
5
