DATE
ISSUE
2004/06
ISSUE1.0
2004/08
ISSUE1.1
REVISED HISTORY
CONTENTS OF CHANGES
Initial Release
Cover Design Change
REMARK

Advertisement

Table of Contents
loading

Related Manuals for LG LSP-345

Summary of Contents for LG LSP-345

  • Page 1 REVISED HISTORY DATE ISSUE CONTENTS OF CHANGES REMARK 2004/06 ISSUE1.0 Initial Release 2004/08 ISSUE1.1 Cover Design Change...

  • Page 3: Table Of Contents

    LGE CDMA Fixed Wireless Telephone LSP-345 CONTENTS 1 Important Information...............9 Safety Information ....................9 Optimal Phone Performance ................9 Care and Service....................10 Safety Information .....................11 2 Introduction ..................14 Front View of the Telephone ..............14 LCD Display ..................... 15 Installation ....................16 Installation Steps..................
  • Page 4 LSP-345 LGE CDMA Fixed Wireless Telephone 4.3.2 Hot Line Time....................27 4.3.3 Auto Time-out....................27 4.3.4 Speed Dial (enable / disable) ...............28 4.3.5 Key-tone Length...................28 Security Features ..................29 4.4.1 Set Lock Mode .....................29 4.4.2 Clear Calls....................29 4.4.3 Clear Memory....................30 4.4.4 Emergency Call....................30 4.4.5...
  • Page 5 LGE CDMA Fixed Wireless Telephone LSP-345 7.3.4 Erasing a Sent Message ................50 MSG Ringer ..................... 51 8 Other Functions ................52 Redial ....................... 52 Finding Last Call History ................52 Hook Switch ..................... 52 Flash Key ....................52 Safe Mode....................52 9 Storing Phone Number ..............53...
  • Page 6 LGE CDMA Fixed Wireless Telephone Highlights Congratulations on your purchase of the LSP-345 Fixed Wireless Telephone. This telephone has been designed to operate on the latest digital mobile communications technology. This technology has greatly enhanced voice clarity and can provide various advanced features.

  • Page 7: Important Information

    LGE CDMA Fixed Wireless Telephone LSP-345 Important Information Safety Information Warning To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Do not use this product near swimming pools or other water bodies.

  • Page 8: Care And Service

    LSP-345 LGE CDMA Fixed Wireless Telephone Use only the battery, antenna and AC power supply provided by LGE. Using any other type will invalidate the warranty. Only authorized personnel should service the phone and its accessories. Faulty installation or service can be dangerous and may invalidate the warranty.

  • Page 9: Safety Information

    Do not use with car battery. It may cause electric shock, fire, breakdown or transformation. For safety use, use only adapter approved by LG. To all problems arising from not following this guide, LG does not bear responsibility. WARNING Ex) LSP-345 (LG Power Adapter Source : DC 9.6V / 1A)
  • Page 10 Before using plug, check with available power voltage. Inaccurate power voltage may cause fire and damage. Ex) LSP-345 Input Voltage : 100-250V. Do not plug many power cords in outlet. It may cause fire or electric shock. Do not remodel the power cord or disassemble. If power cord or plug is impaired, do not use it.
  • Page 11 It may explode or catch fire by electrolyte. WARNING Use only LG-approved battery or adapter. If not, it may cause explosion or short. LG does not bear responsibility for the danger. When you disconnect the power cord of any accessory, grasp and pull the...

  • Page 12: Introduction

    LSP-345 LGE CDMA Fixed Wireless Telephone Introduction 2.1 Front View of the Telephone Menu / Softkey 1: Activate MENU state Message : Activate SMS state End : Deactivate a state – No store a value Recall / Softkey 2 : Activate RECALL state / Choose next state...

  • Page 13: Lcd Display

    LGE CDMA Fixed Wireless Telephone LSP-345 2.2 LCD Display The LCD shows icons on the top of the LCD screen. Different indicator appears based on the phone's operating mode. RSSI indicator : Indicates the signal strength in the service area.

  • Page 14: Installation

    You should follow each step carefully as shown below in order to guarantee proper operation of CDMA Fixed Wireless Telephone. STEP I. Check Components Fixed Wireless Terminal is supplied with the following standard unit and accessories; 1. LSP-345 Main Unit with Handset -1EA- 2. Dipole Antenna -1EA- 3.
  • Page 15 LGE CDMA Fixed Wireless Telephone LSP-345 If it is good, beep tone is heard. If it is not good(Booting fails or beep tone is not heard), you have to connect the adapter or backup battery, again. Please observe the following matters to get better voice quality;...

  • Page 16: Installation Steps

    LSP-345 LGE CDMA Fixed Wireless Telephone 2.4 Installation Steps Please follow the below procedure to install the unit properly. Connect Base- Connect the handset to the antenna to the TNC handset connector. connector (Turn right). Bend the antenna up Open the battery right.

  • Page 17: Basic Operation

    LGE CDMA Fixed Wireless Telephone LSP-345 Basic Operation 3.1 Making a Call If user press ' ' button after dialing the number, the terminal make a call immediately. 1. Pick up the handset or press button. 2. Listen for dial tone.

  • Page 18: Receiving A Call

    LSP-345 LGE CDMA Fixed Wireless Telephone Correcting dialing mistakes 1. Press Clear button shortly to erase the most recent digit. 2. Press and hold Clear button for at least one second. If the phone is locked, enter the Lock Code If the call did not go through, press the hook switch and dial again.

  • Page 19: Missed Call Message

    LGE CDMA Fixed Wireless Telephone LSP-345 3.5 Missed Call Message If a call is received and not answered for user’s absence, you are informed that you have missed a call. The latest missed Missed 1 call call time and number of missed call is displayed. Press [OK] to...

  • Page 20: List Of Menu State

    LSP-345 LGE CDMA Fixed Wireless Telephone List of Menu State Main Menu Sub-Menu Setting Value Default 1. Ring Volume 4 steps 1. Volume / Ring 2. Key Volume 4 steps +silent 3. Ear Volume 4 steps 4. Ring Type 10 types 1.

  • Page 21: Volume / Ring

    LGE CDMA Fixed Wireless Telephone LSP-345 4.1 Volume / Ring This menu allows you to adjust the various different volumes. 4.1.1 Ring Volume The received tone when you receive a call can be adjusted. From the MENU MAIN MENU 1. Press [MENU] + 1(VOLUME/RING)+ 1(Ring Volume) 1:VOLUME / RING In on-hook state.

  • Page 22: Ring Type

    LSP-345 LGE CDMA Fixed Wireless Telephone 4.1.4 Ring Type You can select the various ring types. 1. Press [MENU] + 1(VOLUME/RING) + 4(Ring Type) in on- hook state. RING TYPE 2. Select a desired ring type with Volume left/right button or Sare Jahan Se [NEXT].

  • Page 23: Additional Features

    LGE CDMA Fixed Wireless Telephone LSP-345 4.2 Additional Features 4.2.1 Wake-up 4.2.1.1 Time This function allows you to adjust Wake-up. MAIN MENU 1. Press [MENU] + 2(ADDITIONAL) + 1(Wake-up ) + 1 1:VOLUME / RING (Time) 2:ADDITIONAL in the on - hook state.

  • Page 24: Minute Alert

    LSP-345 LGE CDMA Fixed Wireless Telephone 4.2.2 Minute Alert Alerts you every minute during a call. 1. Press [MENU] + 2(ADDITIONAL) + 2(Minute Alert) in on – hook State. MINUTE ALERT 2. Select On or Off by [NEXT] or Volume left/right button.

  • Page 25: Dial Features

    LGE CDMA Fixed Wireless Telephone LSP-345 4.3 Dial Features 4.3.1 Hot Line 1. Press [MENU] + 3 (DIAL FEATURES) + 1(Hot Line) in on – hook state. DIAL FEATURES 1:Hot Line 2:Hot Line time 2. Select On or Off by [NEXT] or Volume left/right button and press [OK] to select.

  • Page 26: Speed Dial (Enable / Disable)

    LSP-345 LGE CDMA Fixed Wireless Telephone 4.3.4 Speed Dial (enable / disable) 1. Press [MENU] + 3 (DIAL FEATURES) + 4(Speed Dialing) SPEED DIALING in on – hook State. Enable 2. Select Enable or Disable by [NEXT] or Volume left/right...

  • Page 27: Security Features

    LGE CDMA Fixed Wireless Telephone LSP-345 4.4 Security Features 4.4.1 Set Lock Mode This function prevents your phone from being used without permission. Possible settings are ON/OFF. The OFF means that the phone is not locked. ON sets the phone locked immediately.

  • Page 28: Clear Memory

    LSP-345 LGE CDMA Fixed Wireless Telephone 4.4.3 Clear Memory When you want to delete phonebook memory, you can erase all phonebook memory. 1. Do the above step1 and 2 of 4.4.1. 2. Press 3(Clear Memory). CLEAR WHOLE BOOK 3. Select “Yes” and press [OK] using [NEXT] or Volume...

  • Page 29: Restriction Call Service

    LGE CDMA Fixed Wireless Telephone LSP-345 4.4.5 Restriction Call Service This function is a convenient feature which enables user to restrict using any phone number. To forbid using any phone number, user must set the number in deny edit. Can’t use any phone number(max 32digits) started with the number saved in deny edit.

  • Page 30: Permit Memory

    LSP-345 LGE CDMA Fixed Wireless Telephone 4. Select “No restriction” ,” Restriction” or “Emergency Restrict Set Only ” using [NEXT] or Volume left/right button and press Restriction [OK]. [OK] [NEXT] Below 4.4.5.2 and 4.4.5.3 function can be used when the Restrict set is set to “Restriction”.

  • Page 31: Deny Memory

    LGE CDMA Fixed Wireless Telephone LSP-345 4.4.5.3 Deny Memory You couldn’t call any phone numbers saved in deny edit. You can save 10 deny phone numbers. 1. Do the above step 1~2 of 4.4.5.1. 2. Press 5(Restrict Call) and 3(Deny Memory).

  • Page 32: Functions While In A Call

    LSP-345 LGE CDMA Fixed Wireless Telephone 5 Functions while in a call 5.1 Ear Volume You may adjust ear volume while you are in a call. Time: 0:23 1234567 [MENU] [MUTE] The Volume left/right button on the right side of the phone can EAR VOLUME be used to adjust ear volume.

  • Page 33: Memo

    LGE CDMA Fixed Wireless Telephone LSP-345 5.3 Memo You can save numbers while in a call. 1. Press [MENU] and 1(MEMO) while in a call. IN_CALL MENU 1:MEMO 2:MIC LEVEL 2. Enter a number using keypad. QUIT 3. Press [ADD] to save and exit. Or press [QUIT] to exit.

  • Page 34: Transmitting Your Own Number

    LSP-345 LGE CDMA Fixed Wireless Telephone 5.5 Transmitting your own number This function is a convenient feature which enables you to transmit your own phone number while in a call through press one key. (For example, sending your phone number when you pages.) 1.

  • Page 35: Searching, Editing & Dialing

    LGE CDMA Fixed Wireless Telephone LSP-345 Searching, Editing & Dialing 6.1 Retrieving Last Call History 1. Press [RECALL] and 1(FROM LAST CALL). RECALL 1:FROM LAST CALL 2:FROM MEMORIES 2. Select a number or a name in the last call list by Volume 1234567 left/right button and press [VIEW].
  • Page 36 LSP-345 LGE CDMA Fixed Wireless Telephone Enter a desired memory location (01~99: 2 digits) or press [NEXT] to choose a desired memory location Auto=01 and press [OK]. NEXT The phone number is stored in the displayed memory location. The phone will display a message asking to keep your Make Secret? number as secret or not.

  • Page 37: Retrieving Phone Number By Name

    LGE CDMA Fixed Wireless Telephone LSP-345 6.2 Retrieving Phone Number by Name 1. Press [RECALL] and 2(From Memories). FROM MEMORIES 2. Press 1 button to retrieve phone number by name. 1:By Name 2:By Address 3. Enter the name that you want to look for and press [FIND].

  • Page 38: Retrieving Phone Number By Address

    LSP-345 LGE CDMA Fixed Wireless Telephone 6.3 Retrieving Phone Number by Address 1. Press [RECALL] and 2(FROM MEMORIES) Lookup Location? 2. Press 2 button to retrieve a phone number by address. 3. Enter a memory address to retrieve phone number.

  • Page 39: Retrieving Phone Number By Number

    LGE CDMA Fixed Wireless Telephone LSP-345 Erasing process You might press [ERASE] at the above step 3. Select “Yes” using [NEXT] or Volume key. ERASE ? Press [OK] to delete. [OK] [NEXT] 6.4 Retrieving Phone Number by Number 1. Press [RECALL] and 2(FROM MEMORIES).

  • Page 40: Fast Searching

    LSP-345 LGE CDMA Fixed Wireless Telephone 6.5 Fast Searching 1. Press [RECALL] button. RECALL 1:FROM LAST CALL 2:FROM MEMORIES 2. Press [RECALL] button again. 01:ABC 02:ACG [VIEW] [ERASE] You see the whole phone number list in the memory location and you can find the number by scrolling the...

  • Page 41: Sms (Short Message Service)

    LGE CDMA Fixed Wireless Telephone LSP-345 SMS (Short Message Service) Messaging, Paging, and Voice mail features are available when your phone is turned on. Using Message button allows you to access messages for viewing on the LCD screen or to send a message.

  • Page 42: Voice Message

    LSP-345 LGE CDMA Fixed Wireless Telephone 4. Press [ERASE] to erase a message. FR#:5678 Hello Press [OK] to complete erasing process. [OK] [ERASE] When you scroll received MSGs, you can use Volume left/right key. ERASE ? In other words, if you push Volume left key, the arrow...

  • Page 43: Erasing All Received Message

    LGE CDMA Fixed Wireless Telephone LSP-345 7.1.3 Erasing all Received Message 1. Press MESSAGE button and 1(MSG RECEIVED). MSG RECEIVED 2. Press 3(Clear All). 3:Clear All 3. Select “No” or “Yes” using [NEXT] or Volume key. ERASE All? Press [OK] to delete.

  • Page 44: Message Sending

    LSP-345 LGE CDMA Fixed Wireless Telephone 7.3 Message Sending When sending message, you can select set priority among Normal, Emergency and Urgent. 7.3.1 Sending a New Message 1. Press MESSAGE button and 2(MSG SENDING). SMS MENU 1:MSG RECEIVED 2:MSG SENDING 2.

  • Page 45: Sending The Sent Message Or Message After Editing The Sent Message

    LGE CDMA Fixed Wireless Telephone LSP-345 7. Select type for setting priority among Normal/Emergency Set Priority ? /Urgent. Normal Set the priority. Press [OK] to send the message. [OK] [NEXT] 7.3.2 Sending the sent Message or Message after editing the Sent Message 1.
  • Page 46 LSP-345 LGE CDMA Fixed Wireless Telephone 7. Select Yes/No to store Message. Press [OK]. Store Message? [OK] [NEXT] 8. Select type for setting priority among Normal / Set Priority ? Emergency /Urgent. Normal Set the priority. Press [OK] to send the message.

  • Page 47: Sending The Received Message Or Message After Editing The Received Message

    LGE CDMA Fixed Wireless Telephone LSP-345 7.3.3 Sending the Received Message or Message after editing the Received Message 1. Press MESSAGE button and 2(MSG SENDING). MSG SENDING 3:Received MSG 2. Press 3(Received MSG) to see a received text message 4:Clear All list.

  • Page 48: Erasing A Sent Message

    LSP-345 LGE CDMA Fixed Wireless Telephone 7. Select Yes/No to store Message. Press [OK]. Store Message? [NEXT] [OK] 8. Select type setting priority among Set Priority ? Normal/Emergency Urgent. Normal Set the priority. Press [OK] to send the message. [OK] [NEXT] 7.3.4 Erasing a Sent Message...

  • Page 49: Msg Ringer

    LGE CDMA Fixed Wireless Telephone LSP-345 7.4 MSG Ringer You can select the various ring types. 1. Press [Message] + 4(MSG RINGER) in the idle state. MSG RINGER Select a desired ring type with [NEXT] or Volume button. RING1 Press [OK] button.

  • Page 50: Other Functions

    LSP-345 LGE CDMA Fixed Wireless Telephone Other Functions 8.1 Redial Pick up the handset or press button and Redial button to redial last outgoing number. 8.2 Finding Last Call History Press Redial button in on-hook state to see your last telephone 1234567 numbers.

  • Page 51: Storing Phone Number

    LGE CDMA Fixed Wireless Telephone LSP-345 Storing Phone Number 9.1 Storing/Editing Phone Numbers 9.1.1 Storing Phone Numbers Frequently used phone numbers can be stored on the memory locations (01~99: 2 digits) and you can make a call by pressing memory location number in off-hook state.
  • Page 52 LSP-345 LGE CDMA Fixed Wireless Telephone You can see a confirming message. was stored in 01 Also you can see a condition of used memory. - MEMORY - used : 01 empty : 98 To enter a character You can enter English character in editing mode.

  • Page 53: Erasing Stored Phone Numbers

    LGE CDMA Fixed Wireless Telephone LSP-345 9.1.2 Erasing Stored Phone Numbers When a phone number is stored in a memory location, you can erase the stored phone number. 1. Press [RECALL] + 2(FROM MEMORIES) + 3 (By Lookup Number? Number) and enter a number of the desired memory location to erase.

  • Page 54: Finding Stored Phone Numbers

    LSP-345 LGE CDMA Fixed Wireless Telephone 9.2 Finding Stored Phone Numbers You can see all the list of stored phone numbers in memory list and if you forgot the memory location, can find it in sequence. And You can place a call with the phone number.

  • Page 55: Speaker Phone

    LGE CDMA Fixed Wireless Telephone LSP-345 Speaker Phone This function is a convenient feature which enables you to call using speaker phone button in on- hook state. 11 General Information Main Unit Item LSP-345 Tx Frequency Digital : 824 ~ 849 MHz...
  • Page 56 LSP-345 LGE CDMA Fixed Wireless Telephone Battery Item Description Capacity 3.6V Ni-MH Talk duration time 2 Hours Standby duration time 24 Hours Charging duration time Trickle, 24 Hours...

  • Page 57: Fcc Rf Exposure Information

    LGE CDMA Fixed Wireless Telephone LSP-345 FCC RF Exposure Information Finding Stored Phone Numbers WARNING! The antenna used for this transmitter must not exceed 2.5dBi and must be installed to provide a minimum separation distance of 20 cm from all persons.
