MS-7660 Manboard
5. Poston the coolng set onto the re-
tenton mechansm.
Hook one end of the clp to hook
first.
7. Fasten down the lever.
Important
• Manboard photos shown n ths secton are for demonstraton only. The appearance
of your manboard may vary dependng on the model you purchase.
Whle dsconnectng the Safety Hook from the fixed bolt, t s necessary to keep an
•
eye on your fingers, because once the Safety Hook s dsconnected from the fixed
bolt, the fixed lever wll sprng back nstantly.
En-8
6. Then press down the other end of the
clp to fasten the coolng set on the
top of the retenton mechansm.
Locate the Fx Lever and lft up t.
8. Attach the CPU Fan cable to the CPU
fan connector on the manboard.
