MFJ -1756 Instruction Manual

6 meter ground plane antenna

Advertisement

Quick Links

MFJ-1756 Instruction Manual
MFJ-1756 6 METER GROUND PLANE ANTENNA
INTRODUCTION
The MFJ-1756 Ground Plane Antenna features a DC grounded element and a ground
isolated radial system for improved performance.
The ground isolated radial system, unique to the MFJ-1756 antenna, reduces undesirable
feedline and supporting structure radiation by eliminating common mode current paths.
This unique system improves transmission by producing a much cleaner pattern with
more signal at desired angles, and also reduces conducted noise reaching the antenna over
the outside of the feedline or antenna support. It also insures that the length of the
feedline or support does not change the antenna's resonant frequency or SWR.
The MFJ-1756 is easily cut for the desired area of the six meter band.
impedance air insulated matching stub provides convenient adjustment of base impedance
(a normal ground plane is much less than 50 ohms) allowing adjustment to a perfect 1:1
SWR. Power capability is 1000 watts RF continuous.
CHOOSING A LOCATION FOR THE ANTENNA
WARNING:
Improper
hazardous!
before attempting to assemble, install or operate
this product!
it is out of the reach of adults as well as
children. High power transmitting devices produce
voltages that can cause severe burns or other
injuries.
For the best performance on receiving and transmitting, mount this antenna in a clear
location at least a few feet above or 20 feet away from buildings, towers, feedlines, utility
wires, and other antennas. While your own ingenuity and particular circumstances will
determine the final mounting method, we will pass along some rules that can not be
neglected.
Never mount this antenna in a location that will permit unsuspecting people to come in
contact with the radials or any other part of the antenna.
Never mount this antenna where a mechanical failure might allow the antenna to contact
power lines or other utility wires.
Always ground the feed line at the point where it enters a building to a good earth ground
for lightning protection.
installation
Read
these
Always mount this antenna so that
6 Meter Ground Plane Antenna
and
assembly
instructions
thoroughly
A rugged low
can
be
1

Advertisement

loading

Summary of Contents for MFJ MFJ-1756

  • Page 1 It also insures that the length of the feedline or support does not change the antenna's resonant frequency or SWR. The MFJ-1756 is easily cut for the desired area of the six meter band. A rugged low...
  • Page 2: Parts List

    As you unpack this antenna, you should find the following items. Before attempting to install this antenna, check the parts bag to insure that all hardware is accounted for. In the event anything is missing, please contact MFJ Enterprises, Inc. immediately. 1 MFJ-1756 Instruction Manual...
  • Page 3: Assembly Procedure

    MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna ASSEMBLY PROCEDURE Locate the base of the antenna (Figure 1) to begin the assembly. Figure 1 Antenna base. Step 1: To attach the matching hairpin stub to the antenna base (Refer to Figure 2): A.
  • Page 4 MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna Step 2: Insert a radial through the two rear most holes on the left and right sides of the bottom of the base. Refer to Figure 3 and the holes labeled A. Push the radial through both holes until one end extends 1/4 inch pass the second hole.
  • Page 5 MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna Step 4: Insert the plastic bushings into each of the 1/2" round holes in the back of the antenna base. The bushings are to remain flush with the base on both sides. See Figure 4.
  • Page 6 MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna Figure 5 Antenna base with stainless steel plate assembly shown. Step 6: To install the antenna to your mast: A. Remove the nuts, washers and saddle from the U bolt. See Figure 6.
  • Page 7 MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna Figure 7 U bolt assembly with fiberglass plates. D. Install the other fiberglass plate through the U bolt from the front of the antenna base. Place the lock washers over the U bolt and hand thread the nuts on the bolt. Tighten the nuts securely with the 7/16"...
  • Page 8: Tuning The Antenna

    MFJ-1756 Instruction Manual 6 Meter Ground Plane Antenna TUNING THE ANTENNA After the antenna base with radials has been secured to the mast, refer to Chart 1 to tune the antenna to the desired frequency. Locate the radiator. This is the 54 3/4" hollow tube that is threaded on the inside at one end.
  • Page 9: Technical Assistance

    If the manual does not reference your problem or your problem is not solved by reading the manual, you may call MFJ Technical Service at 601-323-0549 or the MFJ Factory at 601-323-5869. You will be best helped if you have your unit, manual and all information on your station handy so you can answer any questions the technicians may ask.
