- Page 1 Installer manual RS16.P 24 Vdc control unit for sliding gate ACTO 404D...
-
Page 2: Table Of Contents
RS16.P Contents: Page 1 - Product characteristics ........................................ 1 2 - Example of installation ........................................ 1 3 - Description of the terminal blocks ....................................2 4 - Connecting accessories ......................................3 5 - Changing the programmable parameters ................................... 5 6 - Trimmer functions ........................................6 7 - Functions of the buttons ...................................... -
Page 3: Product Characteristics
RS16.P 1 Product characteristics Control unit for governing sliding gear motors at 24 Vdc with a maximum power of 80 W for gates of maximum length 6 m and 400 kg in weight, equipped with integrated magnetic limit switches on the board, encoder (used for obstacle detection) integrated receiver at 433 MHz and integrated battery charger. -
Page 4: Description Of The Terminal Blocks
RS16.P 3 Description of the terminal blocks F1 (5x20) T 1.6A F1 (5x20) T 1.6A F1 (5x20) T 1.6A Terminal Description Rated data Neutral Earth 120÷230 Vac Phase Photo-test or gate open warning light positive 24 Vdc 120 mA Accessories negative... -
Page 5: Connecting Accessories
RS16.P 3.1 Description of output function Accessories power supply: Permanent 24 V DC output. 0-11 Blinking: 24 Vdc output powered when the gate is moving. 0-17 Photo-test or gate open warning light: 24 V DC output for signalling gate status or performing the safety test:... - Page 6 RS16.P 4.2 Photocells and photocells when closing Normally closed contact (when the photocells are not engaged the PHC LED must be on), if not used then jumper between COM. and PHC, you must observe the polarity of the power supply for the photocells:...
-
Page 7: Changing The Programmable Parameters
RS16.P 4.4 Sensitive edge 51 52 62 63 61 4.5 Stop push button 52 51 62 63 64 61 5 Changing the programmable parameters OPENING APERTURA APERTURA The control panel is programmed by default with the following parameters: - automatic closing:... -
Page 8: Trimmer Functions
RS16.P 5.2 Reversing the opening direction 1. While the gate is stationary and not closed, press and hold PRG for 2 s; the flashing light comes on and remains steadily lit to indicate that program- ming is in progress. The gate closes. -
Page 9: Led Functions
RS16.P 9 LED functions Status Description Mains power supply not present Mains power supply present 1 blink Saving a new remote control 2 blinks Saving a remote control already in memory 3 blinks Deleting a remote control PHC PHO STP... - Page 10 RS16.P 11 Troubleshooting Problema Cause Solution The automation system does not No mains supply Check the power line switch work Blown fuse Replace blown fuse with others of the same value Control and safety inputs not working Check the diagnosis LEDs (61, 62, 63 must be on)
- Page 11 RS16.P EC DECLARATION OF CONFORMITY (Declaration of incorporation of partly completed machinery Annex IIB Directive 2006/42/EC) No.:ZDT00434.00 The undersigned, representing the following manufacturer Elvox SpA Via Pontarola, 14/A - 35011 Campodarsego (PD) Italy herewith declares that the products CONTROL BOARD - RS SERIES Articles RS16.P...
- Page 12 Viale Vicenza, 14 36063 Marostica VI - Italy RS16.P installer EN 00 1804 www.vimar.com...
