Novopro GoboSphere Instruction Manual page 4

Main Menu
To select any of the menu options, press the MENU button to select the mode required. Once you have made a selection then
press ENTER to confirm. Use the UP and DOWN buttons to choose the desired menu option.
LED display
A001
A1 1-15
A2 1-9 (1-9 colour change speed)
A3 1-9 (1-9 colour change speed)
A4 1-9 (1-9 colour change speed)
A5 1-9 (1-9 colour change speed)
A6 1-9 (1-9 colour change speed)
S1
S2
8 Channel DMX control
Channel DMX
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
6 0-255
7 0-255
8 0-255
DMX address setting
When controlling the unit (or units) with a DMX controller, each one must be set with a specific DMX address. You can choose to
set all units with the same DMX address or you can set every unit with its own DMX address. If all units are set with the same DMX
address all units will be synchronised and operate in the same way, you cannot control each unit separately. If you set each unit
with a different DMX address, they will receive the DMX signal from their own DMX address. You will now be able to control each
unit individually. The DMX address that you set for each unit must be determined by the number of channels. This unit has 8
channels, therefore you should set the starting address of the first unit to 1, the second unit must then be set to 9 (1+8), the third
unit must be set to 17 (9+8) and so on.
Technical Specifications
DMX512 control channels: 8 Channels
DMX512 input & output connection: 3 pin XLR
Modes: DMX512 / Auto / Sound-to-Light / Master/Slave / Remote control
LEDs: 8 x 3w RGBW CREE LEDs plus 4 x 3w RGBW LEDs
Power supply: IEC mains / AC 220-240V 50/60Hz / Fuse: 3A / Power consumption: 40w
Dimensions (WxDxH): 220 x 220 x 288mm
Weight: 2Kg
Due to continuous product development, specifications and appearance are subject to change.
Function description
DMX address 001-512
Colour change
A1 5 red, green, blue, white
A1 7 blue, white
A1 8 green, blue
A1 11 green, white
A1 12 green, blue, white
A1 13 red, blue, white
A1 14 red, green, white
A1 15 red, green, blue
2 colour jump change
Function
Master dimmer
Red dimming
Green dimming
Blue dimming
White dimming
Strobe
Rotation
Auto program
A1 1 red
A1 2 green
A1 3 blue
A1 4 white
A1 6 red, green
A1 9 red, white
A1 10 red, blue
Jump change
Static change
Strobe change
Auto
Strobe sound
Sound
Motor
-
SP1-SP9 motor speed
SP1-SP9 motor speed
SP1-SP9 motor speed
SP1-SP9 motor speed
SP1-SP9 motor speed
SP1-SP9 motor speed
-
-
