SELF-PRIMING PUMPS
FEATURES
Pedestal Pump
Pump Type:
Epoxy Plastic
Body:
Neoprene, Nitrile, Viton* or EPDM
Impeller:
Mechanical, Carbon-on-Ceramic, or
Shaft Seal:
Tungsten Carbide; Nitrile or Viton
1" NPT External
Ports:
Epoxy Plastic Covered Stainless
Shaft:
Steel
7.0 lb (3.2 kg) Approx.
Weight:
VARIATIONS AVAILABLE
MODEL NO.
DESCRIPTION
Standard Pressure, Neoprene
30520-1001
Impeller, Carbon Seal
Standard Pressure, Nitrile Impeller,
30520-1003
Carbon Seal
Standard Pressure, Viton Impeller,
30520-1004
Carbon Seal
High Pressure, Neoprene Im pel ler,
30520-1011
Carbon Seal
High Pressure, Nitrile Impeller,
30520-1013
Carbon Seal
High Pressure, Viton Impeller,
30520-1014
Carbon Seal
Standard Pressure, Neoprene
30520-1101
Impeller, Tungsten Carbide Seal
Standard Pressure, Nitrile Impeller,
30520-1103
Tungsten Carbide Seal
Standard Pressure, Viton Impeller,
30520-1104
Tungsten Carbide Seal
High Pressure, Neoprene Impeller,
30520-1111
Tungsten Carbide Seal
High Pressure, Nitrile Impeller,
30520-1113
* Viton is a trademark of E.I. Du Pont de Nemours and Company.
MODELS 30520-1XXX
Tungsten Carbide Seal
High Pressure, Viton Impeller,
30520-1114
Tungsten Carbide Seal
APPLICATIONS
WARNING
!
Explosion hazard. Do not pump gasoline,
solvents, thinners or other flammable liquids.
To do so can cause an explosion resulting in
injury or death.
INDUSTRIAL: Circulating and transferring corrosive liq-
uids. Re turn ing spilled liquids to process, transferring foam-
ing solutions with entrained air, such as soaps and deter-
gents. Sampling and pilot plant installations. Handles pure
solutions, acids, alkalies, photo chemi cals, dyes, deter-
gents, waxes, gels, solutions with suspended solids and
emulsions.
METAL PLATING: Filtration of plating solutions. Filling and
emptying vats. Adding chemicals for pH balance.
PHARMACEUTICAL: Processing lab solutions, medicines,
lotions and preparations. Filtering pharmaceutical solutions.
AGRICULTURAL: Transferring liquid fertilizers, herbicides
and pesticides.
OPERATING INSTRUCTIONS
1. INSTALLATION – Pump may be mounted in any
position. The rotation of the pump shaft determines
the location of the pump's intake and discharge
ports. (Refer to dimensional drawing.) Pump is
normally assembled at factory for clockwise rotation
(looking at end cover). If counter clockwise rotation
