It is important to keep the radio's antenna a safe distance from the user. To meet the
requirements of FCC part 2.1091 for radio frequency radiation exposure, the following
information must be provided to the end user:
"In order too comply with FCC RF exposure requirements, this device must be operated
in such a way that a minimum 20cm separation distance is maintained between the
antenna, and all persons, during normal operation."
The installer of this radio equipment must ensure that the antenna is located or pointed such
that it does not emit RF fields in excess of Health Canada limits for the general population;
consult Safety Code 6, obtainable from Health Canada.
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (EIRP) is not more than that required for
successful communication.

Approved Antennas

Two antenna port connections (for diversity) are provided. The radio uses SMT Ultra Miniature
Coax Connector, Hirose, CL331-0471-0-10 (U.FL-R-SMT). An adaptor cable or interface board
is used to connect to the approved antennas.
The following antennas are approved for use with this module:
Frequency Bands
Type Gain
Omni 2
Omni 2
Omni 2
Omni 2
Omni 2
Omni 3
Omni 4
Omni 4
Omni 4
Omni 5
Omni 5
Omni 5
Omni 6
Omni 6
Omni 6
Omni 6,8
Patch 8
Patch 8,9
Parabolic 29
ProSoft Technology, Inc.
September 6, 2007
Connector Freq
SMA-RP 2.4,5.2,5.8
F-RP 2.4,5.2,5.8
RP-SMA 2.4
RP-SMA 2.4
RP-SMA 2.4
N 2.4
N 2.4
N 2.4
N 2.4
RP-SMA 2.4
RP-SMA 2.4
RP-SMA 2.4
N 2.4
N 2.4
N 5.8
N 2.4,5.8
N 2.4
N 2.4,5.8
N 5.8
RLX-IHW-OEM ? 802.11a, b, g
Part#
A2505S-OA
-
A2402S-OA
A2402S-OS
A2402S-OSLP
A2403NJ-OCD
A2404NBHB-O
A2404NBHW-O
A2404NJ-OC
A2405S-OA
A2405S-OM
A2405S-OS
A2406NJ-OC
A2406NJ-OCD
A5006NJ-OC
A2506NJ-OC
A2408NJ-DP
A2508NJ-DP
A5829NJ-DB
Industrial Hotspot
