Description

The 1100R Wireless Repeater provides increased communication range when used with the 1100 Series Wireless
Receivers. Up to eight repeaters can be installed on a wireless system.
Repeater provides built-in survey capability to allow for single-person installations, eliminating the requirement for
an external survey kit. For added security, an internal case tamper switch is provided.

Compatibility

The 1100R Repeater operates with the XR500 Series Command Processor™ panels or XR100 Series Command
Processor™ panels using the 1100X, 1100XI or 1100XH Receiver or with the XRSuper6, XR20, and XR40 Command
Processor™ panels using the 1100D, 1100DI or 1100DH Receiver.

What is Included

The 1100R Wireless Repeater includes the following items:
• One Model 1100R Repeater
• One Lithium Polymer Rechargeable Battery
• One Model 376 DC Power Supply
• Zone name and number label
• Serial number label
• Hardware pack

Serial Number

For your convenience, an additional pre-printed serial number label is included. Prior to installing the device,
record the serial number or place the pre-printed serial number label on the panel programming sheet. This number
is required during programming. As needed, use the zone name and number label to identify a specific repeater.

Programming the Transmitter in the Panel

Refer to the XR500 Series Programming Guide (LT-0679), XR100 Series Programming Guide (LT-0896), or the
XRSuper6/XR20/XR40 Programming Guide (LT-0305) as needed. Program the device as a zone in Zone Information
during panel programming. At the Serial Number: prompt, enter the eight-digit serial number, including leading
zeros. Continue to program the zone as directed in the panel programming guide.
Note: When a receiver is installed, powered up, or the panel is reset, the supervision time for transmitters is reset.
If the receiver has been powered down for more than one hour, wireless transmitters may take up to an additional
hour to send a supervision message unless tripped, tampered, or powered up. This operation extends battery life for
transmitters. A missing message may display on the keypad until the transmitter sends a supervision message.

Selecting the Proper Location (LED Survey Operation)

The 1100R provides a survey capability to allow one person to confirm communication with the receiver while the
cover is removed.

Battery Only Startup

The 1100R provides the option to power up using the Lithium battery for survey operation. Briefly short the Battery
Start pads together to power up. Refer to Figure 1.

Survey LEDs

The 1100R automatically begins establishing communication at power up so there is no need to fault the tamper
switch. The 1100R Green Survey LED turns on steady when communication with the receiver is established. The
1100R Red Survey LED turns on steady when communication cannot be established with the receiver. Communication
is faulty when the Green and Red LEDs alternate flashing. Relocate the repeater until the Green LED turns on steady
indicating communication has been established.
INST ALLA TION GUIDE
1100R Wireless Repeater
Using the on-board LEDs, the 1100R Wireless
