- Page 1 Fingerprint Access Control Integration Host User’s Manual KX-DR01 V1.0.0...
-
Page 2: Table Of Contents
Table of Contents Overview...................... 0 Device Structure and Installation ..............1 System Structure ..................3 System Structure..................... 3 Device Port ..................... 3 Function Setting ................... 5 Login ....................... 5 User Management ................... 5 4.2.1 Add User ....................6 4.2.2 Add Super Password ................7 4.2.3 Delete User ................... - Page 3 Important Safeguards and Warnings Please read the following safeguards and warnings carefully before using the product in order to avoid damages and losses. Note: Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric shock. Do not install the device at position exposed to sunlight or in high temperature.
-
Page 4: Overview
1 Overview The Fingerprint Access Control Integration Host integrates card reading, config and execution functions. Its has a neat appearance for medium to high-end clients such as commercial building, corporation and intelligent community. It has: Touch keyboard + LCD display, TCP/IP protocol. ... -
Page 5: Device Structure And Installation
2 Device Structure and Installation Device appearance and dimension are shown as in Figure 2- 1 and Figure 2- 2. Unit is mm. Figure 2- 1 Figure 2- 2... - Page 6 Fingerprint Access Control Integration Host installation is shown as in Figure 2- 3. Figure 2- 3 Installation step: Step 1. Fix installation bracket in the hole on 86 box via screw A as to fix the bracket on wall (if no 86 box or you cannot fix it well, then use screw B to fix the bracket on wall, but you must embed expansion nut at the corresponding position in wall before doing so).
-
Page 7: System Structure
3 System Structure 3.1 System Structure The device and card reader, alarm device, access control PC and etc. compose a system as in Figure 3- 1. Figure 3- 1 3.2 Device Port Device port of the host is shown in Figure 3- 2. - Page 8 Figure 3- 2 Port Note Door lock COM end Door lock NC end Door lock NO end Door sensor detection Connect to GND PUSH Press unlock button BELL- Door bell output BELL+ Alarm output 2 （ 5V level switch ） ， OUT2- connect to voltage not over 12V OUT2+...
-
Page 9: Function Setting
4 Function Setting 4.1 Login Login interface step: Step 1. Plug in power, device is going to boot up. Step 2. Press 【√】 button, screen displays admin password. Step 3. Input admin password, and press 【√】 button to enter homepage. Default password is “88888888”. -
Page 10: Add User
Card Type Note cannot unlock. When you add card, system will ask if set card password, period and term of validity. Black list When you swipe card on black list and enters, it wanrns service personal. When you add card, system will ask if set card password, period and term of validity. -
Page 11: Add Super Password
New User Card No. Card Type Normal （Guest） Use Time Step 3. Use key to input card no. or place card at swiping area to scan. Step 4. Press【√】key to select card type. Step 5. Press 【←】key to delete default data, input use time, and press 【√】.System shows added password and period interface as follows. -
Page 12: Delete User
Add Super Pwd Pwd input ****** Confirm ****** 4.2.3 Delete User You can delete a single user, or all users. To delete a single user: Step 1. In user management interface, press 【↑】 or 【↓】 key to select delete user, and press 【√】... -
Page 13: Add More Master Card
Delete Super Pwd Super Password System asks if to delete it or not. Step 4. Press OK and press【√】key to delete. To delete all super passwords: Step 1. In delete super password interface, press 【↑】or 【↓】 key to select delete all super passwords, and press 【√】... - Page 14 period. For example, set period 1, and the Monday to Sunday setup are in Chart 4- 2. Period Monday 0800-2200 (valid period: 08:00 to 22:00) Tuesday 0800-2200 (valid period: 08:00 to 22:00) Wednesday 0800-2200 (valid period: 08:00 to 22:00) Thursday 0800-2200 (valid period: 08:00 to 22:00) Friday 0800-2200 (valid period: 08:00 to 22:00)
- Page 15 To set holiday period: Step 1. In time period setup page, press【↑】 or【↓】 key to select holiday period, and press【√】key. Step 2. Input period, and press 【√】key. Input any number between 0~127, such as 1. Step 3. Modify start time, end time and swiping period, and press 【√】key. Holiday Period Setup Holiday Start：...
-
Page 16: Master Card
To set NO period: Step 1. In time setup interface, press 【↑】 or 【↓】key to move up and down, select NO period, and press 【√】key. Step 2. Input period no., and press 【√】key as follows. NO Period Setup Period No. System prompts setup is successful. -
Page 17: Door Lock Time
Unlock Mode Setup Card Password Fingerprint Card/Fwd/FP ○ Card+Pwd √ Card+FP 4.3.4 Door Lock Time Door lock time setup includes hold time and over time setup. Step 1. In A&C setup, press【↑】 key or 【↓】key, select door lock time setup and press 【√】key. -
Page 18: Door Status Setup
Door Timed Out When A&C open time is over Door Over time, it will generate an alarm. Door timed out alarm requires setup of door over time, please refer to Ch 4.3.4. Chart 4- 3 To set alarm: Step 1. In A&C interface, press 【↑】 key or 【↓】 key, select alarm setup, and press 【√】 key. -
Page 19: System Settings
4.4 System Settings 4.4.1 Local Setup You can set data, admin password and voice mail. You also can export all data, restore default settings. 4.4.1.1 Date Setup It sets current system date and time. Step 1. In system settings page, press 【↑】 or 【 ↓】 key, select date setup, and press 【√】 key. -
Page 20: Communication Setup
4.4.1.3 Talk Volume You can set device audio volume. Step 1. In local setup interface, press 【↑】 key or 【↓】 key, select talk volume setup, and press 【√】 as follows. Talk Volume Setup Step 2. Press 【↑】key or 【↓】key, you can adjust volume. 4.4.1.4 Export All Data You can export device card data, alarm data to a USB disk. -
Page 21: Mode
IP Setup IP： 172.7.10.33 Sub Mask： 255.255.255.0 Gateway： 172.7.0.0 System prompts setup is successful. 4.4.3 Mode The device suppers two work mode, including “this device as controller and “this device as card reader”. This device as controller: the device is used as an A&C controller for unlock operation. -
Page 22: Card History
4.5.1 Card History To view card swiping record: Step 1. In homepage, press 【↑】key or 【↓】key, select system info, and press 【√】 key. Step 2. Press 【↑】key or 【↓】key, select card history, and press 【√】key. Step 3. Press 【↑】key or 【↓】key, user can view card swiping history, including swiping time, card no., method, status and etc. -
Page 23: Local Info
4.5.3 Local Info To view local info: Step 1. In homepage, press 【↑】 or 【 ↓】 key, select local info, and press 【√】 key. You can view version, MAC, IP, Card Quantity, Super Password Quantity, Card History and Alarm History in the shown interface. Note: ...
