Summary of Contents for Firetide HotPort 3203
- Page 1 Hardware Installation Guide HotPort HotPort 3203-Public Safety Outdoor Wireless Mesh Node...
- Page 3 Manual Revision 1.3 Copyright Notice ©2003-2005 Firetide, Inc. All rights reserved Trademarks Firetide, the Firetide logo, Instant Mesh Networks, HotPort are trademarks of Firetide, Inc. All other trademarks are the property of their respective owners. Firetide Instant Mesh Networks iii...
- Page 4 Software fails to materially conform to the documentation tive of the cause of action, even if Firetide has been advised of and an authorized Firetide reseller is notified in writing of such the possibility of such damages.
- Page 5 Safety Instructions The HotPort 3203 outdoor wireless mesh node must be installed by a qualified professional such as a licensed electri- cian. Failure to install this equipment properly may result in equipment damage and personal injury or death. Explanation of Graphic Symbols...
- Page 6 POWER LINES CAN BE LETHAL • If anything such as a wire or pole does come in contact with Do not install the HotPort 3203 outdoor mesh node where possi- a power line, DON’T TOUCH IT OR ATTEMPT TO MOVE IT. In- ble contact with power lines can be made.
-
Page 7: Table Of Contents
Firetide HotPort 3203 Outdoor Wireless Mesh Node ........ -
Page 8: Firetide Hotport 3203 Outdoor Wireless Mesh Node
5 GHz for maximum capacity and minimal interference from While operating at 5 GHz, the HotPort 3203’s radio can cover dis- 2.4 GHz devices. tances up to 2600 ft (800 m). This long reach between HotPort Units designed for operation on the 4.9 GHz Public Safety band... -
Page 9: Example Networks/Applications
Try to place HotPort nodes in areas where access by unauthorized individuals is restricted (such as on a roof- • To ensure a safe installation of the HotPort 3203, follow the top, a tall pole, and so on). After you mount the HotPort, you appropriate electrical and building codes (such the Nation- can secure it by placing a lock on the mounting bracket. -
Page 10: Power Options
Ethernet devices, such as access points or surveillance cameras. Use of these ports is optional. Both ports 1 and 2 on a HotPort 3203 can provide Power over Ethernet (PoE) functionality to Powered Devices (PD) connected to these ports. A Powered Device can receive data and the power to process the data from the HotPort 3203, which functions as Power Sourcing Equipment (PSE) in this configuration. -
Page 11: Hotport 3203 Installation
HotPort 3203 Installation This hardware installation guide describes how to install the HotPort 3203 safely. The HotPort is intended to be installed by trained technical professionals. Be sure to read and understand all installation and safety instructions before proceeding with the installa- tion. -
Page 12: Building A Firetide Mesh Network
It is not recommended to install your HotPort network in a linear, point-to-point configuration. The Firetide network protocol is HotPort 3203 outdoor mesh nodes have omni-directional antennas optimized for two- and three-dimensional topologies. that radiate in a broad circular pattern perpendicular to the anten- na shaft. -
Page 13: Staging Considerations
Port 3203: 9. Install the antenna and wireless devices higher than the 1. Set up your HotPort 3203 in a lab with all other HotPort units HotPort 3203. Having the HotPort 3203 at a location lower (any combination of HotPort 3203 nodes and HotPort 3100 se- than the antenna will provide easy access to the HotPort ries nodes) using the two provided dual-spectrum antennas. -
Page 14: Preparing The Site For Mounting
Weatherproofing earth ground. The two Ethernet ports on the bottom of the HotPort 3203 fea- • Grounding rods should be copper and between 6 - 8 ft ture circular, watertight IP67-rated connectors. Use the included (1.8 m –... -
Page 15: Mounting The Antenna
However, do not at- and coverage. tempt to splice or shorten the antenna cable. • The antenna can be mounted directly to the HotPort 3203 or Note: Do not mount the HotPort antenna within 3 ft (0.9 m) of directly to a pole. - Page 16 Note: If a longer coax cable is required, contact your local distributor to obtain a 50 ohm RP-TNC (Reverse-Polarity TNC) cable. In order to maintain proper system operations, there cannot be more than 8 dB of insertion loss between the HotPort 3203 and the antenna.
- Page 17 High-Gain Antenna Assembly for HotPort 3203 Firetide Instant Mesh Networks 11...
-
Page 18: Mounting The Enclosure
Mounting the Enclosure The HotPort 3203 enclosure should be mounted securely to a wall/wood structure or a pole approximately 1.5” (37 mm) to 2” (50 mm) in diameter. You can also mount the enclosure to a wall, light poles, and irregularly shaped poles. -
Page 19: Pole Mounting
Pole Mounting You can mount the HotPort 3203 to a pole using U bolts. The section below describes how to mount the enclosure to a 1.5” (37 mm) or 2” (50 mm) pole. Using U Bolts 1. Position the pole mounting bracket against the pole. Insert the U bolts from behind the pole and through the pole mounting bracket. -
Page 20: Using Mounting Straps
Using Mounting Straps For poles with diameters larger than 2” (50 mm), horizontal poles, irregularly shaped poles, or lighting lamps, you can use mounting straps to mount the HotPort 3203 enclosure. 1. Position the universal mounting bracket against the pole. -
Page 21: Installing The Sunshield
You can install the provided sunshield on the enclosure to help protect it from the elements. 1. Align the four holes in the sunshield with the four risers on the enclosure. 2. Use the provided four machine screws to attach the sunshield to the enclosure. Firetide Instant Mesh Networks 15... -
Page 22: Connecting The Power
There are three ways to provide power to the HotPort 3203: • AC: Connect the provided power supply to an AC power out- let and then to the HotPort 3203. This option allows you to provide power to up to two peripheral devices connected to the HotPort 3203. -
Page 23: Connecting Power Over Ethernet
3. Insert the male RJ-45 connector on the constructed Ether- net cable into the female-to-female Ethernet coupler. You can provide power to a HotPort 3203 by connecting Power Sourcing Equipment (PSE) to Ethernet port 1 on the HotPort 3203. In this configuration, the HotPort 3203 receives its power from the PSE. -
Page 24: Connecting An External Battery Backup System Or Solar Power
Connecting an External Battery Backup System or Solar Power The HotPort 3203 can be powered directly via a DC power source Optionally, battery backup systems can be powered and charged of the proper input rating. See the Power section of Appendix C via a solar panel array. -
Page 25: Connecting Peripherals
21W. You can to connect the peripheral to the Ethernet transition cable/ RJ-45 use either port on the HotPort 3203 to connect peripherals. Fol- male connector kit. low the instructions in the above section to connect peripheral To connect a peripheral device: devices that will receive their power from the HotPort. -
Page 26: Starting Up And Connecting To The Mesh
If you do not have an indoor HotPort, connect a workstation run- ning the HotView software to the HotPort 3203 via an Ethernet cable and Ethernet transition cable/RJ-45 connector kit (see the “Connecting Peripherals” section for more information on cable connections). -
Page 27: Appendix A Contacting Firetide
Dealer Provided Technical Support and Warranty Services If you need additional technical assistance that is not available on our web site, please contact your Firetide dealer directly. All authorized Firetide dealers are trained and authorized to provide technical support and warranty services for our products and have qualified technical staff available to help you build and maintain... -
Page 28: Appendix B Connectors
Appendix B Connectors HotPort 3203 Ethernet Transition Cable Pin Descriptions Circular, Watertight IP66-Rated Connector and Port Pin Descriptions Connector Pin # Wire Color Port Pin # White/Orange Orange White/Green Blue White/Blue Green White/Brown Brown Drain Wire Drain Wire RJ-45 Connector Pin Descriptions... -
Page 29: Power Transition Cable Pin Descriptions
Power Transition Cable Pin Descriptions The following section describes the pinout for the indoor-rated power supply power transition cable. The power to HotPort 3203 is 12 to 24 VDC, up to 2A. The HotPort can provide 12–48 VDC power (PoE) to devices connected to it. -
Page 30: Appendix C Specifications
Firetide offers a range of recommended antennas. Contact the Regulatory Agency Certifications factory for details. US FCC ID REP-3200-2. Contact your Firetide dealer for product Network ports availability and certifications for other countries. • Dual 10/100 Mbps Ethernet ports with circular, watertight... - Page 32 © HPOHWI002 101705 2005 Firetide, Inc. All rights reserved...
