Summary of Contents for Sharper Image Baby Bath OQ005
- Page 1 Baby Bath ™ Thermometer + Wireless Baby Monitor OQ005 Instructions Read and save these instructions. OQ005 IM_v1 1105-PB 0216.indd 1 2/17/06 1:51:53 PM...
-
Page 2: Table Of Contents
Table of Contents Baby Bath Thermometer ............5 ™ This is Not a Toy ................5 Warnings ...................5 Precautions ................6 General Instructions ..............7 Front of the Product ...............7 Back of the Product..............8 Batteries .................9 Power On/Off ................9 Basic Functions ..............10 Technical Specifications ............13 Baby Monitor with Indoor Temperature ........14 Precautions ................14 Warnings .................16... - Page 3 Table of Contents Back View – “Parent” Unit ...........18 LCD – “Parent” Unit ............19 Front View – “Baby” Unit .............20 Back View – “Baby” Unit .............21 Power Requirements ............22 Neck Lanyard – “Parent Unit ..........24 Power On/Off ..............25 Setup ...................25 Selecting Channels –...
- Page 4 Table of Contents Setting the Alarm..............29 Feeding Timer ..............30 Backlight ................31 Reset ..................32 Specifications ...............32 Statement of FCC Compliance ..........34 FCC Label Compliance Statement ........35 OQ005 IM_v1 1105-PB 0216.indd 4 2/17/06 1:51:54 PM...
-
Page 5: Baby Bath Thermometer
Baby Bath Thermometer This is Not a Toy Product is tested and is in compliance with toy safety standard EN71. IT IS NOT meant to be used as A TOY and is not suitable for children under 3 years. Please retain this instruction manual for future reference. Warnings •... -
Page 6: Precautions
Precautions This unit is engineered to provide you with years of satisfactory service, if you handle it carefully. The following are precautions that should be observed: • Do not clean the unit with abrasive or corrosive materials. This may scratch the plastic parts and corrode the electronic circuit. •... -
Page 7: General Instructions
Precautions • Due to continuing improvements, actual product may differ slightly from the product described herein. • The technical specifications for this product and the contents of the instruction manual are subject to change without notice. General Instructions Front of the Product 1. -
Page 8: Back Of The Product
Front of the Product 3. The LCD also shows the temperature in °C or °F. 4. MEMORY button sets the user-defined temperature range. It also disables the alarm sound. 5. Low-battery indicator Back of the Product 1. The RESET button returns all the settings to default values. 2. -
Page 9: Batteries
Batteries 1. Remove the screws. (When you first remove the product from its packaging, the screws will already be loose.) 2. Once loose, pull the two sections apart, or to remove the base, insert a blunt instrument into the groove. 3. -
Page 10: Basic Functions
Basic Functions Temperature Ranges To obtain a temperature reading, place the unit in the water. The unit has three preset temperature ranges to indicate when the bath water is cold, comfortable or hot. Comfort Color Temperature Temperature Level Range °F Range °C Cold 32.0°F - 89.9°F... - Page 11 Basic Functions Temperature Unit To change the display measurement unit, slide the °C/°F switch to the desired setting. User-defined Temperature Range The default comfort temperature range for the baby’s bath water is 90°F to 100°F (32°C to 37°C). To set a new water-temperature range to the desired level: 1.
- Page 12 Basic Functions Notes: • To display the user-defined water temperature, press MEMORY. • The unit defines the temperature + or – 3.6°F (+ or – 2°C) of the temperature stored. For example, if the temperature re- corded is 80.6°F (27°C), any reading below 77°F (25°C) appears on the LCD as Cold and any reading above 84.2°F (29°C) appears on the LCD as Hot.
-
Page 13: Technical Specifications
Technical Specifications Type Description Display Temperature Range 32°F to 122°F (0°C to 50°C) Temperature Resolution +/– 0.1°C (0.2°F) Measurement Unit User-selectable °F/°C Unit Dimensions (H x W x D) Approximately 3" x 3" x 1" Unit Weight 3.88 ounces Batteries 2 AAA (UM-4) 1.5V OQ005 IM_v1 1105-PB 0216.indd 13 2/17/06 1:52:01 PM... -
Page 14: Baby Monitor With Indoor Temperature
Baby Monitor with Indoor Temperature Precautions This unit is engineered to give you years of satisfactory service, if you handle it carefully. Here are a few precautions: • Do not immerse the unit in water. • Do not cover the ventilation holes. Ensure items that are nearby, such as newspapers, tablecloths, curtains, blankets, beddings, etc., cannot accidentally cover the ventilation holes. - Page 15 Precautions • Remove the batteries before storing the product for a long time. Do not mix new and old batteries. Note: The technical specifications for this product and the contents of the instruction manual are subject to change without notice. CAUTION: To reduce the risk of electric shock, do not expose this appliance to rain or moisture.
-
Page 16: Warnings
Warnings • This product should only be operated by an adult and should not to be used as a toy for children. • This product is not intended and should not be used as a replacement for responsible adult supervision; it only acts as a support for your child-caring purpose. -
Page 17: General Instructions
General Instructions Front View – “Parent” Unit : Turns the unit on and off; activates backlight. 2. Sound Light Indicators: Shows the sound level received from the “baby” unit. 3. +/– : Increases and decreases volume; changes setting value; activates and disables alarm. 4. -
Page 18: Back View - "Parent" Unit
Back View – “Parent” Unit 1. AC Adapter Jack 2. Table Stand 3. RESET Button 4. Lanyard Holes 5. °C/°F Selection OQ005 IM_v1 1105-PB 0216.indd 18 2/17/06 1:52:03 PM... -
Page 19: Lcd - "Parent" Unit
LCD – “Parent” Unit 1. Connection / Signal Icon 2. Low Battery on the “Baby” Unit 3. Battery Status on the “Parent” Unit 4. Voice Activation Sensitivity Level 5. Alarm Icon 6. Feeding Timer Icon 7. Indoor Temperature 8. Clock / Alarm / Timer 9. -
Page 20: Front View - "Baby" Unit
Front View – “Baby” Unit 1. Microphone / : Turns the unit on and off; searches for channel. : Turn the night-light on and off. 4. Night-light 5. LED Indicator: Flashes during data transmission. OQ005 IM_v1 1105-PB 0216.indd 20 2/17/06 1:52:05 PM... -
Page 21: Back View - "Baby" Unit
Back View – “Baby” Unit 1. AC Adapter Jack 2. Table Stand 3. Battery Compartment 4. RESET Button OQ005 IM_v1 1105-PB 0216.indd 21 2/17/06 1:52:06 PM... -
Page 22: Power Requirements
Power Requirements “Baby” Unit The adapter should be used at all times. Insert one end of the adapter into the unit, then plug the other end into a wall outlet. The 3 AAA (UM-4 1.5V) batteries (purchase separately) are for backup use only. - Page 23 Power Requirements “Parent” Unit This unit uses a rechargeable battery pack (3 AAA/UM-4 NiMH). Insert the rechargeable battery pack by connecting the end of the wire into the indentation located at the bottom right of the battery compartment. To recharge the battery, connect the adapter into the unit, then plug the other end into a wall outlet.
-
Page 24: Neck Lanyard - "Parent Unit
Power Requirements An animated battery icon indicates that it is charging. steadily appears when the battery is fully charged. Before first use, charge the batteries for 12 hours and press RESET. After the first charge, you only need to charge the unit until the battery icon indicates that it is fully charged. -
Page 25: Power On/Off
Power On/Off To turn either unit on or off, press and hold Setup 1. Insert batteries and plug in adapters. 2. Turn the “Baby” unit on, then turn on the “Parent” unit. 3. Place the two units close to each other for five seconds. This allows the units to “recognize”... -
Page 26: Selecting Channels - "Baby" Unit
Selecting Channels – “Baby” Unit If there is interference or transmission trouble between the two units, press the button on the “Baby” unit. Night-Light – “Baby” Unit To turn the night-light on and off, press the button. Volume To change the volume (0-5), press the +/– button on the “Parent”... -
Page 27: Sound Light Indicators
Sound Light Indicators The sound light indicators on the “Parent” unit can alert you visu- ally to a baby’s sound. The louder the sound received from the “Baby” unit, the more the lights are on. Connection Signal Status The connection icon shows you the status of the signal between the two units. -
Page 28: Temperature Display
Temperature Display The “Baby” unit measures the surrounding temperature. If “---” is shown, the “Baby” unit cannot transmit the temperature reading. Slide the °C/°F switch, located in the battery compartment of the “Parent” unit, to the desired setting. Clock/Alarm To toggle between the clock and the alarm display, press the MODE button. -
Page 29: Setting The Alarm
Set Clock/Voice-Activation Sensitivity Level Level Sensitivity Maximum High Medium Note: The voice-activation sensitivity feature increases/decreases the level of sound the “Parent” unit emits. When set to 0, all sounds, regardless of level, can be heard on the “Parent” unit. Setting the Alarm 1. -
Page 30: Feeding Timer
Setting the Alarm 4. To change the setting, press + or –. To quickly scroll through the numbers, press and hold + or –. 5. To confirm a setting and move on to the next one, press MODE. The setting sequence is hours, then minutes. To Activate or Deactivate the Alarm When in Alarm display, press + or –. -
Page 31: Backlight
Feeding Timer 3. To increase or decrease the time in 30-minute intervals, press + or –. To quickly scroll through the numbers, press and hold + or –. 4. To confirm, press Timer Functions • To start/stop/retrieve the last setting, press the •... -
Page 32: Reset
Reset To return either unit to the default settings, insert a blunt stylus into the RESET hole, located in the battery compartment of each unit. Specifications Type Description Clock Time 12- or 24-hour format Alarm 2 minutes Feeding Timer 30 minutes to 24 hours RF Frequency 2.4GHz Transmission Range... - Page 33 Specifications Power Description “Baby” Unit 6V DC 200mA AC adapter/ 3 x 1.5V UM-4/AAA batteries “Parent” Unit 6V DC 200mA AC adapter/ 3.6V NiMH rechargeable battery pack Measurements Description Dimensions – Both Units Approximately 4" x 2 " x 2" (H x W x D) (96 x 63 x 40 mm) Weight –...
-
Page 34: Statement Of Fcc Compliance
Statement of FCC Compliance FCC Compliance Statement WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 36 What The Sharper Image Will Do The Sharper Image will repair any defects in materials or workmanship. In the event repair is not possible, The Sharper Image will either replace this product with one of similar features and price, or refund the full purchase price of the product, whichever you prefer.
