Figure 3-1 Installing the TR-in-FE Module
Post-Installation Checks
This section describes the LEDs and basic checks used
to verify your installation, and to ensure that the
Switch and TR-in-FE Module operate correctly.
Token Ring-in-Fast Ethernet Module
Rx
Tx
Tx
Far End Status
Link Status
Rx
Reset
Console Port
9600,8,1,N
3C510630
LED Summary
This section describes the LEDs that provide status
and troubleshooting information.
LEDs on the Switch are described in Table 3-1.
LEDs on the TR-in-FE Module are described in
Table 3-2.
Post-Installation Checks
3-3
