- Page 1 YO U R GU I D E TO O P ERATI NG TH E ULT I M AT E P OWE R REC LI NER...
- Page 3 Following are helpful hints and important safety information regarding the use and care of your Comfort Recliner ™ . Please review this instruction manual thoroughly before using your power Comfort Recliner ™ . This product is intended for household / residential use only.
-
Page 4: Important Safety Instructions
The leg rest folds down when closing and could possibly cause injury to a child. Always leave the power Comfort Recliner™ in an upright and closed position when not in use. Keep hands and feet clear of mechanism. Only the occupant should operate it. -
Page 5: Power Cord Safety
THE CORD OUT OF REACH OF CHILDREN. Figure 1 Take care when moving the power Comfort Recliner™ that the power cord is not under the base or legs of the Comfort Recliner™, or it may get damaged. Never operate the power... - Page 6 In the event that something obstructs the footrest, it will stay partially open via springs located on both sides of the power Comfort Recliner™, even if the motor continues to the fully closed position. In the Event of an Obstruction: •...
- Page 7 Do not race, play with, or abuse the power Comfort Recliner™ mechanism. • Never operate the power Comfort Recliner™ if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water.
- Page 8 Comfort Recliner™ there are additional safety instructions to be followed. DANGER! Risk of physical injury: The power Comfort Recliner™ has a control that is located remotely from the battery that must be secured before servicing. (See Figure 2)
- Page 9 (See Figure 2) WARNING! Only use an identical replacement battery supplied by your local American Leather ® retailer. The battery is matched to the charging system in the power Comfort Recliner™. Use of a non-identical battery could cause risk of burns, fire, electric shock, or injury to persons.
- Page 10 U SE R MA I N TE N A N C E IN ST R UCT I ON S Unplug the outlet cord before cleaning the power Comfort Recliner™. If the power Comfort Recliner™ is equipped with an optional battery, also unplug the master power cord from the control box before cleaning or performing maintenance.
-
Page 11: Overload Protection
Recliner™ may then be used normally. STORAGE If the power Comfort Recliner™ will not be used for an extended period of time, remove the cord from the power socket and wall outlet and store the cord out of reach of children. - Page 12 FOOTREST & BAC K R E C LI NE The footrest has infinite stopping positions, independent from the power Comfort Recliner™ back recline. To raise the footrest, press the raised area of the front toggle switch located next to the USB port. If you are sitting in the power Comfort Recliner™, this is the farthest button from the...
-
Page 13: Adjusti N G H E A D R E St
When standing behind the power Comfort Recliner™, you can change the angle by pressing forward on the outside of the headrest. However, if you are already sitting and want to adjust the angle, place both hands on the back of the headrest and pull forward to your desired position. - Page 14 OPTI O N A L BATTE RY P OWER The purchase of the optional battery for use in the power Comfort Recliner™ allows the power Comfort Recliner™ to be operated either with the cord plugged into the wall, or with battery power only. This allows you to float the power Comfort Recliner™...
- Page 15 Comfort Recliner™ is plugged in or not. If the power Comfort Recliner™ is plugged in for recharging, the automatic power selector system will provide power to charge the battery and operate the power Comfort Recliner™...
- Page 16 Unplug the power socket from the rear of the power Comfort Recliner™. Tip the power Comfort Recliner™ onto its back as shown in Figure 5. Because of the power Comfort Recliner™ weight and size, a second person is recommended to assist in this task.
- Page 17 Disconnect both battery cord plugs. (See figure 6) Figure 6 Remove the two screws holding the battery to the tray. (See Figure 7) Remove battery from the power Comfort Recliner™. Remove Screws Figure 7...
- Page 18 Place the power Comfort Recliner™ in the upright position and plug the cord back into the power socket at the back of the power Comfort Recliner™. Then plug the other end of the power cord into the wall outlet. Look under the footrest at the battery; the LED at the front of the battery will be flashing AMBER when it is charging and solid GREEN when it is fully charged.
- Page 20 (172910) V12.2018...
