The P3-35 is a 2 or 3 channel amplifier with Dolby Digital® decoding. It is designed to be used with either a Bluetooth, analog,
or digital input from a TV or other audio source. With a digital input, it automatically senses Dolby Digital and PCM and switches
modes. The P3-35 takes the input signal from an audio source, decodes it and outputs either a 2 or 3 channel amplified signal
to a sound bar or set of speakers. When set in the 2 channel mode, it will take a stereo or multi-channel signal and mix it down
to 2 output channels (left and right). When set in the 3 channel mode, it will take a stereo or multi-channel signal and mix it into
3 output channels (left, right and center). In either mode there is a sub out option.
BOX CONTENTS
1- Amplifier in Weatherproof Box
1- Bluetooth® antenna
1- 32 V, 3.75 A power supply
1- Six-pin Euroblock connectors
1- Three-pin Euroblock connectors
1- Mini Screw Driver
TABLE OF CONTENTS
Page 1
Page 2
Page 3
Page 4
Weatherproof Box Installation Instructions
(Continued)
Page 5
Warning
Phase Technology products must be installed by a professional audio installer/contractor . For safety and for
optimum audio performance, installer must follow all directions issued by Phase Technology .
Install Instructions For :
P3-35 Outdoor
Advertisement
Table of Contents
Related Manuals for Phase Technology P3-35
Summary of Contents for Phase Technology P3-35
- Page 1 P3-35 Outdoor The P3-35 is a 2 or 3 channel amplifier with Dolby Digital® decoding. It is designed to be used with either a Bluetooth, analog, or digital input from a TV or other audio source. With a digital input, it automatically senses Dolby Digital and PCM and switches modes.
- Page 2 1. For digital connections, connect an optical cable from your 2. For analog connections, connect a cable from your analog source to the optical input on the P3-35. Set dip switch 6 in source to the analog input using a stereo 1/8”mini-jack. Set SPEAKER CONNECTIONS the down position.
- Page 3 There are two modes the P3-35 can operate in; Standby and Sleep. Setting the P3-35 in the standby mode disables the auto- WEATHERPROOF BOX INSTALLATION INSTRUCTIONS on input signal sensing. In this mode the P3-35 can only be turned on by pressing the Volume control On/Off switch or through RS232 control.
- Page 4 Standby: Green Blinking NOTE P3-35’s that are shipped to the EU market meet the following requirements. The power consumption of the product in networked standby is less than 3W. The power consumption of the product in standby mode is less than 0.5W.
