OS‐440  Set‐Up Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the OS-440 and is the answer not in the manual?

Questions and answers

Related Manuals for Phase Technology OS-440

Summary of Contents for Phase Technology OS-440

  • Page 1 OS‐440  Set‐Up Guide ...
  • Page 2 ATTENTION OS-440 USERS: The OS-440 smart amplifier is currently in BETA status, and some features may not be fully available or activated. Firmware updates may be required to access certain functions.
  • Page 3 WIFI/BLUETOOTH SOURCE LED:  POWER LED:   Solid yellow LED when OS‐440 is booting  OPTICAL SOURCE LED:  Solid green LED when    Blinking yellow & red LED when OS‐440 is updating.  powered & in use. Solid cyan LED  Blinking red LED when OS‐440 is in protect mode.  indicating optical   Blinking green LED  Solid purple LED when in Wi‐Fi D mode. input mode. when on standby.  Blinking green LED when unconnected in Wi‐Fi Network mode. ANALOG SOURCE LED:   RCA INPUT PORTS:  Solid green LED when connected in Wi‐Fi Network  Solid white LED  Ports for RCA mode. indicating RCA analog  analog input. Blinking blue LED when in Bluetooth pairing mode. input mode. ...
  • Page 4 Section 1:  How To Configure Your OS‐440 On Bluetooth  1. To  configure  your  OS‐440  for Bluetooth use,  press  the  source  button  on  your  OS‐440  until the source  cycles  to  Wi‐Fi/Bluetooth.   The  Source  LED  will  blink  blue  until  a  device  is paired. 2. In your mobile device settings, turn Bluetooth On and select the OS‐440 to pair with.  Unless previously renamed, the OS‐440 will be named MSE_Audio_OS440XXXXXX where the Xs are unique to your device.  Once paired, the source LED will be solid blue. DONE...
  • Page 5 Section 2: How to Connect a Hardwired Device to your OS-440 1. Physically plug in your source device via RCA (analog) connection or Optical (digital) connection. 2. Press the source select button to light the appropriate input you are using; analog or optical.
  • Page 6 Section 3:  How To Configure Your OS‐440 for Wi‐FiDirect (offline) 1. Verify that the Source Wi-Fi LED is purple, if not, quickly press the source button on your OS-440 twice to initiate Wi-Fi D mode. This will take a few moments. 2. Note: The Source Wi-Fi LED will change to yellow while the device is changing to Wi-Fi D mode. The Source Wi- Fi LED will change to purple to indicate that the OS-440 is now in Wi-Fi D mode.

  • Page 7: Section 4: Troubleshooting

    • If the Bluetooth connection appears to cut in and out, or drops out completely; • First make sure that the mobile device is not also connected to the OS-440 in WiFi Direct mode, WiFi may need to be turned off.
