Fuse assignment
Fuse Designation
2
Front windshield wipers
3
Power windows
4
Engine components, interior blower motor
5
LED daytime running lights, front fog lamps
6
Right standing light/taillight, license plate illumination
7
Left standing light/taillight
8
Engine components, stationary air conditioner
9
Engine components, brake system, ESM
10
Engine components, electric expansion valve (battery)
Coolant pump 1 and 2
11
ESP control unit
12
Left multifunction control lever functions, switch panel
functions, data link connector, mirror heater, ATA, rain
sensor/light sensor (LHD only), additional instruments,
central locking, instrument cluster, TPM (USA only),
brake/turn signal light switching (USA only)
15
Electric drive safety circuit, pyrofuse
17
Rear windshield wiper (coupé only)
18
ESP control unit, EPS control unit, restraint system, Airbag
On/Off indicator lamp, turn rate sensor, steering angle
sensor
Introduction of smart fortwo electric drive (3rd Generation) • Model Series 451
SAM control unit
Amps Color
25 A White
20 A Yellow
25 A White
10 A Red
7.5 A Brown
7.5 A Brown
25 A White
7.5 A Brown
15 A Blue
25 A White
10 A Red
15 A Blue
15 A Blue
10 A Red
