Summary of Contents for ITV DLK642
- Page 1 Access Control Panel DLK642 Installation Manual ® DLK642 A C C E S S C O N T R O L P A N E L...
- Page 2 Integrated Technical Vision Ltd http://www.itvsystems.com.ua...
- Page 3 It is recommended, for the staff intended for sales and installation of DLK642 access control panel, to take instruction courses conducted by ITV company.
-
Page 4: Table Of Contents
Contents Preface........................5 Features........................5 Specifications......................5 Terms........................7 What's inside......................9 Controls and connections on board................11 Control Panel Operation..................12 Main Mode ....................12 Alarm Mode ....................13 Free Pass Mode ..................14 Blocked Mode ..................14 Mounting........................15 Wiring........................15 Limited Warranty.....................20 Integrated Technical Vision Ltd http://www.itvsystems.com.ua... -
Page 5: Preface
Features Preface DLK642 is an access control panel which operates as totally stand-alone unit with a fully distributed database. All valid card numbers, time zones and relay pulse times are loaded to control panel memory. The panel can control access into two doors with no dependency on a central computer system. - Page 6 Specifications • Voltage ripple 500 mV @ 12 V • Power consumption: • Standby current 80 mA@ 12V • Maximal current 130 mA@ 12V • Environmental requirements: • Operation temperature 0 °С … +55 °С; • Relative Humidity 80% relative at +35°С; •...
-
Page 7: Terms
ID to another person after passing into the premises. If this function is on, DLK642 tracks an ID position – Inside or Outside the premises. On any attempt to pass in the same direction twice DLK642 denies access and stores “Access Denied, Antipassback”... - Page 8 RTE button may be used for remote door opening as well. Schedules DLK642 is capable to store up to 250 time zones. 250 week schedules can be combined from these time zones. Moreover DLK642 can store several “floating” schedules, based on a period different to a week.
-
Page 9: What's Inside
A + B- GND + EB Z7 GND Z8 -PW R+ TM NC1 C1 NO1 NC2 C2 NO2 SA BEL б) Figure1. a). General view of DLK642, b) DLK642 with front cover off 1 - LEDs, 2 - built-in reader,... - Page 10 What's inside Wiring Configurations External reader Z6 GN D Z4 GN D Z2 GN D Z1 GN D + ER BZ D1 D0 GN RD PCB of built-in reader Panel's PCB A + B- GN D + EB Z7 GN D Z8 -PW R+ TM N C1 C1 N O1 N C2 C2 N O2 SA BEL Bell Locks or strikes...
-
Page 11: Controls And Connections On Board
Controls and connections on board Controls and connections on board Terminals' assignment i t c p i r i l p i t c y l l y l l y l l y l l y l l t s i t s i ) n i http://www.itvsystems.com.ua... -
Page 12: Control Panel Operation
Control Panel Operation Jumpers and LED RST - Reset jumper - S3, S4, S6 - Jumpers for RS-485 load selection - S5 - Tamper - BAT - Real-time clock power switch - S8, S9 - Reader mode (Wiegand/Special reader) setting jumpers - VL1 - Live function indicator Jumper BAT should be shorted before installation and broken during transportation and storage. -
Page 13: Alarm Mode
Control Panel Operation Access Denial Access may be denied for the following reasons (LED lights red): - Panel is not downloaded (LED does not light or blink) - ID is not enrolled (red LED and buzzer switch on for a second) - ID time expired (red LED and buzzer switch on for a second) - Access is prohibited at the present moment/day (red LED and buzzer switch on for a second) -
Page 14: Free Pass Mode
Control Panel Operation Free Pass Mode Sometimes situations arise when a door should be open for free pass to everyone, e.g. in case of fire, earth quake or any other disaster. For such cases the panel has Free Pass mode. In this mode reader LED blinks green and yellow alternately. -
Page 15: Mounting
Mounting Mounting Design and view of DLK642 access control panel allow to mount it directly at a door and use built-in reader and keypad. It should be stationed at access point at a height, convenient for all users. While mounted on metal surface, reading range decreases. - Page 16 Inputs wiring DLK642 has eight EOL inputs. All inputs are programmable - see details in Golden Gate manual. After reset to factory defaults all inputs become unas- signed and not supervised. All inputs supervise shortage and break. EOL usage is mandatory.
- Page 17 Wiring RTE button RTE button resistor resistor Request To Exit (RTE) button is to be button for for access used in case of single-sided door. In this access point A point B case door opens on depressing of RTE button. RTE button may be used for remote door opening - for secretary or guard to open a door, for instance.
- Page 18 Power unit Locking devices DLK642 has two relay outputs with C form contacts. Operation time of this outputs may be programmed from 1 to 255 sec. That allows to -PWR+ TM NC1 C1 NO1 NC2 C2 NO2 SA BEL control practically any type of locking device.
- Page 19 Wiring RS-485 Interface RS-485 Interface is used for networking of the system components - PC and panels. The range of RS-485 bus is up to 1200 meters. The number of panels is up to 32. RS-485 port is protected against overvoltage (60V) and B- GND + EB crosspolarity.
-
Page 20: Limited Warranty
Limited Warranty Limited Warranty Integrated Technical Vision Ltd. warrants that for a period of eighteen months from the date of purchase, the product shall be free of defect in materials and workman- ship under normal use and that in fulfilment of any breach of such warranty, Integrated Technical Vision Ltd.
